Description

IMPORTANT NOTICE: Must be used with stock spindles. Cars that have 2 rear upper control arms will require an additional StrongArm. Includes front upper and lower control arms, front and rear sway bars, rear control arms and panhard bar and rear shocks.

RideTech 1965-66 Impala air suspension systems are designed specifically for 1965-66 Chevy B-Body cars. They provide an ultra-low show stance, while maintaining excellent ride quality and handling.

RideTech 1965-66 Impala air suspension system features and notes:

* Upper StrongArms: feature corrected ball joint angles for the tall spindles, and the upper ball joint has been moved back to allow for additional caster setting—which improves high-speed stability and steering feel. (Upper StrongArms are powdercoated black and fully assembled with ball joints, bushing, and cross shafts; ready for installation)
* Lower StrongArms: feature a double sheer lower mount for increased strength. They're powdercoated black, fully assembled with ball joints, bushing, and cross shafts; ready for installation.
* HQ Series Shockwaves: utilize an impact forged aluminum body and monotube design to deliver excellent ride quality and handling (they also allow fine-tuning of the ride quality and handling; the rebound knob is located at top of shock for underhood access).
* Hyperco springs are used to provide a consistent spring rate
* Front and rear MucleBars: help reduce body roll (includes the PosiLink end links to provide immediate engagement between the chassis and control arms)
* Rear StrongArms: provide added strength to help get the power to the pavement (upper arm and panhard bar utilize R-joint technology to deliver smooth operation and reduce roll bind)
* HQ Series rear shocks: utilize an impact forged aluminum body and monotube design to deliver excellent ride quality and handling
* Rear CoolRide system simply bolts in place of stock springs

Important note: To complete your air suspension system, a RideTech compressor system is required/recommended.

Note: Must be used with stock spindles. Some cars have two rear upper control arms and will need additional StrongArm.

Product Overview

Ridetech 65-66 Impala Air Suspension System

Product Details

Description:	Ridetech 65-66 Impala Air Suspension System

This is a group bundle consisting of:

Image	Qty	SKU	MFR SKU	UPC	Description
	1x	rid11296698	11296698	840123505088	Ridetech 65-66 Impala StrongArm Rear Upper
	1x	rid11289000	11289000	840123505040	Ridetech 65-70 Impala Panhard Bar
	1x	rid11284499	11284499	840123505019	Ridetech 65-70 Impala StrongArm Rear Lower Arms
	1x	rid11289100	11289100	840123502339	Ridetech 65-70 Impala MUSCLEbar with Posi-Links Front
	1x	rid11289102	11289102	840123502346	Ridetech 65-70 Chevrolet Impala MuscleBar w/ Posi-Links Rear
	1x	rid11283699	11283699	840123504999	Ridetech 65-70 Impala StrongArm Upper Front
	1x	rid11284610	11284610	840123505026	Ridetech 65-70 Impala Rear CoolRide Kit
	1x	rid11282899	11282899	840123504944	Ridetech 65-70 Impala StrongArm Front Lower
	1x	rid11283001	11283001	840123504951	Ridetech 65-70 GM Impala HQ Series Shockwaves Front Pair

Bundled group items may ship from multiple locations and could have slightly longer transit times if parts are sourced from different warehouses.

Images in this listing may include individual and/or group shots of the products included in the bundle. Please refer to the table to see a breakdown of what is included. Click on a SKU to see individual item details.

For details on the individual components in this bundle, click here.

Data: v4.2 - Upd: 2026-10-14 17:17:28

Specifications

Product Attributes - Brand

RideTech

Product Attributes - Manufacturer's Part Number

11290298

Product Attributes - Part Type

Suspension Kits, Air Springs

Product Attributes - Product Line

RideTech 1965-66 Impala Air Suspension Systems

Product Attributes - UPC

840123505071

Product Attributes - Ride Height

Lowered

Product Attributes - Air Spring Suspension Kit Type

ShockWave/CoolRide

Product Attributes - Air Springs Included

Yes

Product Attributes - Air Compressor Included

No

Product Attributes - Air Line Included

No

Product Attributes - Frame Brackets Included

Yes

Product Attributes - Gauges Included

No

Product Attributes - Leveling Switch Included

No

Product Attributes - Links Included

Yes

Product Attributes - Shocks Included

Yes

Product Attributes - Welding Required

No

Product Attributes - Mounting Hardware Included

Yes

Product Attributes - Quantity

Sold as a kit.

Product Attributes - Notes

Must be used with stock spindles. Cars that have 2 rear upper control arms will require an additional StrongArm. Includes front upper and lower control arms, front and rear sway bars, rear control arms and panhard bar and rear shocks.
