Description

RideTech 1964-67 GM A-Body air suspension systems are specifically designed for the 1964-1967 GM "A" Body Platform to create modern drivability with an ultra-low show stance. Some kits may vary, depending on your application. (Note: Control system not included. To complete your air suspension system, a RideTech compressor system is recommended.)

RideTech 1964-67 GM A-Body air suspension system features and notes:

* RideTech Tall Spindles: induce more negative camber gain to maximize tire contact patch during cornering (also offer a 2 in. pin drop which allows for the use of longer shocks, creating more suspension travel)
* Upper StrongArms: feature corrected ball joint angles for the tall spindles. The upper ball joint has been moved back to allow for additional caster setting, which improves high-speed stability and steering feel (offset slugs are also available for additional caster)
* Lower StrongArms: feature a double sheer lower mount for increased strength (also, the dropped lower shock mount increases suspension travel, and the lower ball joint has been moved forward to increase caster settings—while keeping the wheel centered in the wheel opening)
* Injection molded Delrin bushings with PTFE reduce deflection and stiction on both upper and lower StrongArms
* HQ Series Shockwaves: utilize an impact forged aluminum body and monotube design to deliver excellent ride quality and handling—and allow fine-tuning of the ride quality and handling (rebound knob is located at top of shock for underhood access)
* Front MuscleBar: helps reduce body roll and creates room for wider front tires (includes the PosiLink end links to provide immediate engagement between the chassis and control arms)
* Rear MuscleBar included
* Rear StrongArms: provide added strength to help get the power to the pavement—and utilize R-joint technology to combine the best qualities of low-friction movement, lateral stability, full range articulation, and quiet operation into one special bearing that is as home on the street as it is on the racetrack

Product Overview

Ridetech 64-67 GM A-Body Air Suspension System

Product Details

Description:	Ridetech 64-67 GM A-Body Air Suspension System

This is a group bundle consisting of:

Image	Qty	SKU	MFR SKU	UPC	Description
	1x	rid11227299	11227299	840123502124	Ridetech 64-77 GM A-Body and 78-88 GM G-Body Rear Upper R-Joint Assembly
	1x	rid11236699	11236699	840123504593	Ridetech 64-67 GM A-Body StrongArms Rear Upper
	1x	rid11224499	11224499	840123504395	Ridetech 64-72 GM A-Body StrongArms Rear Lower
	1x	rid11239120	11239120	840123502285	Ridetech 64-67 GM A-Body Front MuscleBar
	1x	rid11009300	11009300	840123500052	Ridetech 67-69 GM F-Body 68-74 X-Body 64-72 A-Body Tall Spindles Pair
	1x	rid11239122	11239122	840123502292	Ridetech 64-67 GM A-Body Rear MuscleBar
	1x	rid11223699	11223699	840123504371	Ridetech 64-72 GM A-Body StrongArms Front Upper
	1x	rid11222899	11222899	840123504364	Ridetech 64-72 GM A-Body StrongArms Front Lower
	1x	rid11233001	11233001	840123504524	Ridetech 64-67 GM A-Body HQ Series ShockWaves Front Pair
	1x	rid11225401	11225401	840123504401	Ridetech 64-72 GM A-Body ShockWaves Rear System HQ Series

Bundled group items may ship from multiple locations and could have slightly longer transit times if parts are sourced from different warehouses.

Images in this listing may include individual and/or group shots of the products included in the bundle. Please refer to the table to see a breakdown of what is included. Click on a SKU to see individual item details.

For details on the individual components in this bundle, click here.

Data: v4.2 - Upd: 2026-10-14 17:17:28

Specifications

Product Attributes - Brand

RideTech

Product Attributes - Manufacturer's Part Number

11230298

Product Attributes - Part Type

Suspension Kits, Air Springs

Product Attributes - Product Line

RideTech 1964-67 GM A-Body Air Suspension Systems

Product Attributes - UPC

840123504494

Product Attributes - Ride Height

Lowered

Product Attributes - Air Spring Suspension Kit Type

ShockWave

Product Attributes - Air Springs Included

Yes

Product Attributes - Air Compressor Included

No

Product Attributes - Air Line Included

No

Product Attributes - Frame Brackets Included

Yes

Product Attributes - Gauges Included

No

Product Attributes - Leveling Switch Included

No

Product Attributes - Links Included

Yes

Product Attributes - Shocks Included

No

Product Attributes - Welding Required

No

Product Attributes - Mounting Hardware Included

Yes

Product Attributes - Quantity

Sold as a kit.

Product Attributes - Notes

Includes front upper and lower control arms, front sway bar, front spindles and rear control arms.
