Injen SuperNano Web Air Filter 4in Flange ID 6in Twist Lock Base / 7.75in Media Height / 4in Top
Injen SuperNano Web Air Filter 4in Flange ID 6in Twist Lock Base / 7.75in Media Height / 4in Top
A$270.33
Available from MFR.
This item is available from the manufacturer's distribution centre. The dispatch timeframe shown is an estimate based on historical order processing and release times for this part. This item is not held in our own warehouse, and actual dispatch timing may vary depending on manufacturer workload and logistics at the time of ordering.
We accept
Description
With a rich history in racing and the street performance, Injen Technology has proven itself as a leader in filtration engineering and technology. Lab tested and race proven, Injen's air filter line features state of the art designs and performance. All SuperNano-Web air filters feature a proprietary media that includes a high-flow base media with a highly efficient Nano membrane applied on top. This allows our SuperNano-Web media to flow the maximum amount of air, all while protecting your valuable engine from harmful dirt and debris. Injen SuperNano-Web air filters are completely cleanable with a light blast of compressed air and requiring no oil to function properly, you'll never have to worry about your MAF sensor becoming dirty from over oiling your air filter again!
Product Overview
With a rich history in racing and the street performance, Injen Technology has proven itself as a leader in filtration engineering and technology. Lab tested and race proven, Injen's air filter line features state of the art designs and performance. All SuperNano-Web air filters feature a proprietary media that includes a high-flow base media with a highly efficient Nano membrane applied on top. This allows our SuperNano-Web media to flow the maximum amount of air, all while protecting your valuable engine from harmful dirt and debris. Injen SuperNano-Web air filters are completely cleanable with a light blast of compressed air and requiring no oil to function properly, you'll never have to worry about your MAF sensor becoming dirty from over oiling your air filter again!
Features and Benefits
- Direct Fit for many Injen intakes and/or universal applications
- Twist Lock base for use on select Evolution intake systems
- Fully serviceable Injen SuperNano-Web dry air filter
- Dry filtration media: no oil required for maximum performance
- Conical Air Filter Shape
- Flange Inside Dimensions: 4.00in
- Flange Height: 1.00in
- Base Outside Diameter: 6.00in Twist Lock
- Media Height: 7.75in
- Overall Height 9.25in +/- .150in
- Top Outside Dimensions: 4.0in
- Top Style: Closed Top
- Stainless steel band clamp with inner protective liner
- Deep pleats for maximum airflow and efficiency
- Made in Pomona California, USA
- Injen Technology Limited Lifetime Warranty
Product Details
| Air Filter Shape: | Round Conical |
|---|---|
| Base Outside Diameter: | 6.0 |
| Description: | Injen SuperNano Web Air Filter 4in Flange ID 6in Twist Lock Base / 7.75in Media Height / 4in Top |
| Filter Oil (Grams): | Dry - No Oil |
| Flange Angle: | 0 |
| Flange Center To Flange Center: | N/A |
| Flange Inside Diameter: | 4.00 |
| Flange Length: | 1.00 |
| Flange Offset: | 0 |
| Gasket Or Seal Included: | No |
| Grade Type: | Performance |
| Marine Approved: | No |
| Media Height: | 7.75 |
| Media Type: | SuperNano-Web Dry |
| Neck Flange: | Yes |
| Overall Filter Height: | 9.25 +/- 0.150 |
| Panel Filter Length: | N/A |
| Panel Filter Width: | N/A |
| Part Number: | injX-1134-BB |
| Pleat Count: | 50 |
| Pleat Height: | 7.25 |
| Prop 65 (C, R or CR): | CR |
| Prop 65 - Short Label: | prop65_warning.jpg |
| Prop 65 Yes/No: | Yes |
| Reusable: | Yes |
| Stud/Insert on Filter Top: | No |
| Title: | Injen Technology SuperNano-Web Air Filter |
| Top Material: | Plastic |
| Top Outside Diameter: | 4 |
| Top Style: | Closed |
| Twist Lock Base: | Yes |
| Vacuum Nipple: | No |
| Washable: | No |
Part Type
Engine Air Filter
Features
- Base Outside Diameter: 6.00in Twist Lock
- Conical Air Filter Shape
- Deep pleats for maximum airflow and efficiency
- Direct Fit for many Injen intakes and/or universal applications
- Dry filtration media: no oil required for maximum performance
- Flange Height: 1.00in
- Flange Inside Dimensions: 4.00in
- Fully serviceable Injen SuperNano-Web dry air filter
- Injen Technology Limited Lifetime Warranty
- Made in Pomona California, USA
- Media Height: 7.75in
- Overall Height 9.25in +/- .150in
- Stainless steel band clamp with inner protective liner
- Top Outside Dimensions: 4.0in
- Top Style: Closed Top
- Twist Lock base for use on select Evolution intake systems
Specifications
- Product Attributes - Brand
- Injen
- Product Attributes - Manufacturer's Part Number
- X-1134-BB
- Product Attributes - Part Type
- Air Filter Elements
- Product Attributes - Product Line
- Injen Performance Nanofiber Dry Air Filter Elements
- Product Attributes - UPC
- 00843115029203
- Product Attributes - Air Filter Type
- Dry
- Product Attributes - Air Filter Style
- Conical flanged
- Product Attributes - Inlet Flange Inside Diameter (in.)
- 4.00
- Product Attributes - Air Filter Height (in.)
- 9.25
- Product Attributes - Air Filter Top Measurement
- 4.000 in. diameter
- Product Attributes - Air Filter Bottom Measurement
- 6.000 in. diameter
- Product Attributes - Air Filter End Cap Material
- Plastic
- Product Attributes - Air Filter End Cap Color
- Black
- Product Attributes - Filter Material
- Synthetic/Steel mesh
- Product Attributes - Filter Color
- Blue
- Product Attributes - Quantity
- Sold individually.
- Product Attributes - Notes
- Features a Twist Lock base for use with select Evolution intake systems. The 9.25 in. height listing is overall.
Reference Information
| Brand Name/s | Injen |
|---|---|
| StreetFX SKU | injX-1134-BB |
| SFX Item ID | 4243811 |
| Supplier Item Code | 4243811 |
| Manufacturer SKU | X-1134-BB |
| Manufacturer UPC | 843115029203 |
| Alternative References | 4in, 6in, 7.75in |
