Wilwood Hat-BB Front 1.45in Offset (Backside) 5 x 5.50 - 8 on 7.00in
Wilwood Hat-BB Front 1.45in Offset (Backside) 5 x 5.50 - 8 on 7.00in
A$300.08
Available from MFR.
This item is available from the manufacturer's distribution centre. The dispatch timeframe shown is an estimate based on historical order processing and release times for this part. This item is not held in our own warehouse, and actual dispatch timing may vary depending on manufacturer workload and logistics at the time of ordering.
We accept
Description
GT Series Big Brake Short Offset hats are precision machined from premium aluminum alloys for high strength and attention to minimized weight. Hats in this category feature threaded rotor mount holes for use with standard through-hole mount rotors. Threaded hole hats may also be used with T-Nuts or bobbins designed for use with specially machined slotted hole dynamic mount rotors. When used in conjunction with matched Wilwood rotor hardware kits, GT hats provide solid, reliable performance in the most demanding conditions. Short Offset Hats are for narrow space applications with offsets often less than 1.00". They are available for most rotor bolt patterns in a variety of four and five lug wheel patterns.
Part Type
Brake Rotor Hats
Specifications
- Product Attributes - UPC
- 889545042160
- Product Attributes - Brand
- Wilwood Disc Brakes
- Product Attributes - Quantity
- Sold individually.
- Product Attributes - Part Type
- Brake Rotor Hats
- Product Attributes - Product Line
- Wilwood GT Series Big Brake Hats
- Product Attributes - Brake Rotor Hat Type
- 5/16-18 in. threaded hole
- Product Attributes - Brake Rotor Hat Color
- Black powdercoated
- Product Attributes - Brake Rotor Hat Material
- Aluminum
- Product Attributes - Manufacturer's Part Number
- 170-13313
- Product Attributes - Brake Rotor Hat Bolt Circle
- 8 x 7.00 in.
- Product Attributes - Brake Rotor Hat Offset (in.)
- 1.45
- Product Attributes - Brake Rotor Hat Clearance I.D. (in.)
- 5.90
- Product Attributes - Brake Rotor Hat Face Thickness (in.)
- 0.30
- Product Attributes - Brake Rotor Hat Center Hole I.D. (in.)
- 4.67
- Product Attributes - Brake Rotor Hat Stud Hole Diameter (in.)
- 0.64
Reference Information
| Brand Name/s | Wilwood |
|---|---|
| StreetFX SKU | wil170-13313 |
| SFX Item ID | 4406815 |
| Supplier Item Code | 4406815 |
| Manufacturer SKU | 170-13313 |
| Manufacturer UPC | 889545042160 |
| Alternative References | 1.45in, 7.00in |
