Oracle 22-24 Hummer EV 5in Roof Mount Curved Light Bar w/ Brackets
Oracle 22-24 Hummer EV 5in Roof Mount Curved Light Bar w/ Brackets
A$1,472.81
IN STOCK! Est Ship 3-5 days.
This item is IN STOCK at one of our warehouses or distribution centres, the ETA is the approximate time required to prepare your order for dispatch.
We accept
Description
The ORACLE LED Light bar for the Hummer EV features a unique Low-Profile design which reduces wind noise and does not block the factory cab clearance lights. The brackets are CAD-designed specifically for this application for easy installation. The LED Light bar features an amazing 22,200 Lumens brightness which projects over 2,000 ft distance! Designed to match the curvature of the Hummer windshield, this light bar stands out from some of the other generic light bar options on the market in both Quality and Performance.
Product Overview
The ORACLE LED Light bar for the Hummer EV features a unique Low-Profile design which reduces wind noise and does not block the factory cab clearance lights. The brackets are CAD-designed specifically for this application for easy installation. The LED Light bar features an amazing 22,200 Lumens brightness which projects over 2,000 ft distance! Designed to match the curvature of the Hummer windshield, this light bar stands out from some of the other generic light bar options on the market in both Quality and Performance.
Features and Benefits
- Hummer Bracket Specifications: Material: Cast Aluminum, Finish: Black Powder Coat, Fitment: Hummer EV (All), Rubberized Base Gaskets
- High-Powered Lighting 36x 7W LED Main Light
- Selectable Amber or White Clearance Lights
- Precision LED Reflector-Facing Technology
- Electronic Thermal Management
- Innovative Patent-Pending Design
- Designed and Engineered in the USA
- LED Lifespan 50,000+ Hours
- Raw Lumen Light Output: 22,200LM
- Effective Lumen Light Output: 18,800LM
- Total Wattage: 252 Watts
- Total Amp Draw: 16 Amps @12V DC
- Beam Angle: 50° Driving Beam
- Max Projection Distance: 1Lux@460M
- Color Temperature: 5500K-6000K
- Advanced Optic Design for Optimal Visibility
- Outer Housing Material: Polycarbonate
- Lamp Housing Material: 6030 Aluminum
- Reflector Material: Plated Polycarbonate
- Lens: Material: Lexan Polycarbonate
- Lamp Finish: Polyester Powder Coat
- Stainless Steel Anti-Fog Breather Valves
- Molded IP68 Waterproof Connectors
- Waterproof Rating: IP69 Ingress Protection
- In the Box: (1) 2022-2024 Hummer EV 50" Roof Mount Curved Light Bar, (2) Mounting Brackets, Mounting Hardware & Weather Gasket
Product Details
| Add-On: | N/A |
|---|---|
| Base Color: | Black |
| Base Diameter: | 55.5 |
| Base Length: | 56.62 |
| Base Material: | Aluminum |
| Brightness: | 22000 |
| Color: | Black |
| DOT Approved: | No |
| Description: | Oracle 22-24 HUmmer EV 5in Roof Mount Curved Light Bar w/ Brackets |
| Electronic Thermal Management: | Yes |
| Housing Color: | Black |
| Housing Design: | 6030 Aluminum |
| Housing Finish: | Powder Coated |
| Housing Material: | Aluminum |
| Housing Shape: | Rectangle |
| Install Note: | DIY Install- No Fabrication/ Modification Required |
| Lens Color: | Clear |
| Lens Diameter: | 48.05 |
| Lens Length: | 50 |
| Lens Material: | Polycarbonate |
| Lens Width: | 40.5 |
| Light Beam Pattern: | Driving |
| Light Quantity: | 36 |
| Light Selection: | Selectable Amber or White Clearance Lights |
| Light Type: | High-Powered Lighting 36x 7W LED Main Light |
| Mount Type: | Mounts using supplied brackets |
| Mounting Hardware Included: | Yes |
| Part Number: | orl6923-023 |
| Prop 65 - Long Label: | Warning: This product contains chemicals known to the State of California to cause cancer or birth defects or other reproductive harm. For more information: www.P65Warnings.ca.gov |
| Prop 65 Yes/No: | Yes |
| Protection Type: | Under/Over Voltage and Reverse Polarity Protection |
| Relay Included: | No |
| Street Legal: | Yes |
| Switch Included: | No |
| Technology: | Precision LED Reflector-Facing Technology |
| Terminal Quantity: | 4 |
| Terminal Type: | Lead Wire |
| Title: | 6923-023 - Off-Road Lighting |
| Voltage: | 12 |
| Wattage: | 252 |
| Wire Gauge Measurement: | 16 |
| Wire Quantity: | 4 |
| Wiring Harness Included: | Yes |
| Wiring Harness Length: | 36 |
Part Type
Light Bar
Features
- Advanced Optic Design for Optimal Visibility
- Beam Angle: 50° Driving Beam
- Color Temperature: 5500K-6000K
- Designed and Engineered in the USA
- Effective Lumen Light Output: 18,800LM
- Electronic Thermal Management
- High-Powered Lighting 36x 7W LED Main Light
- Hummer Bracket Specifications: Material: Cast Aluminum, Finish: Black Powder Coat, Fitment: Hummer EV (All), Rubberized Base Gaskets
- In the Box: (1) 2022-2024 Hummer EV 50" Roof Mount Curved Light Bar, (2) Mounting Brackets, Mounting Hardware & Weather Gasket
- Innovative Patent-Pending Design
- Lamp Finish: Polyester Powder Coat
- Lamp Housing Material: 6030 Aluminum
- LED Lifespan 50,000+ Hours
- Lens: Material: Lexan Polycarbonate
- Max Projection Distance: 1Lux@460M
- Molded IP68 Waterproof Connectors
- Outer Housing Material: Polycarbonate
- Precision LED Reflector-Facing Technology
- Raw Lumen Light Output: 22,200LM
- Reflector Material: Plated Polycarbonate
- Selectable Amber or White Clearance Lights
- Stainless Steel Anti-Fog Breather Valves
- Total Amp Draw: 16 Amps @12V DC
- Total Wattage: 252 Watts
- Waterproof Rating: IP69 Ingress Protection
Specifications
- Add-On:
- N/A
- Base Color:
- Black
- Base Diameter:
- 55.5
- Base Length:
- 56.62
- Base Material:
- Aluminum
- Brightness:
- 22000
- Color:
- Black
- DOT Approved:
- No
- Description:
- Oracle 22-24 HUmmer EV 5in Roof Mount Curved Light Bar w/ Brackets
- Electronic Thermal Management:
- Yes
- Housing Color:
- Black
- Housing Design:
- 6030 Aluminum
- Housing Finish:
- Powder Coated
- Housing Material:
- Aluminum
- Housing Shape:
- Rectangle
- Install Note:
- DIY Install- No Fabrication/ Modification Required
- Lens Color:
- Clear
- Lens Diameter:
- 48.05
- Lens Length:
- 50
- Lens Material:
- Polycarbonate
- Lens Width:
- 40.5
- Light Beam Pattern:
- Driving
- Light Quantity:
- 36
- Light Selection:
- Selectable Amber or White Clearance Lights
- Light Type:
- High-Powered Lighting 36x 7W LED Main Light
- Mount Type:
- Mounts using supplied brackets
- Mounting Hardware Included:
- Yes
- Part Number:
- orl6923-023
- Prop 65 - Long Label:
- Warning: This product contains chemicals known to the State of California to cause cancer or birth defects or other reproductive harm. For more information: www.P65Warnings.ca.gov
- Prop 65 Yes/No:
- Yes
- Protection Type:
- Under/Over Voltage and Reverse Polarity Protection
- Relay Included:
- No
- Street Legal:
- Yes
- Switch Included:
- No
- Technology:
- Precision LED Reflector-Facing Technology
- Terminal Quantity:
- 4
- Terminal Type:
- Lead Wire
- Title:
- 6923-023 - Off-Road Lighting
- Voltage:
- 12
- Wattage:
- 252
- Wire Gauge Measurement:
- 16
- Wire Quantity:
- 4
- Wiring Harness Included:
- Yes
- Wiring Harness Length:
- 36
Reference Information
| Brand Name/s | Oracle Lighting |
|---|---|
| StreetFX SKU | orl6923-023 |
| SFX Item ID | 4581503 |
| Supplier Item Code | 4581503 |
| Manufacturer SKU | 6923-023 |
| Manufacturer UPC | 810030398929 |
| Alternative References | 5in |
