Oracle 4 LED Omni-Directional Emergency Strobe - Blue
Oracle 4 LED Omni-Directional Emergency Strobe - Blue
A$171.48
Special Order. Contact for ETA.
This item is out of stock in our warehouse and partner distribution centres. In some cases, this may be due to not having live inventory feeds available for all suppliers. Please contact us before ordering if you need to meet a specific deadline.
We accept
Description
Only 7/8 inches in height, the ORACLE SMD Omni-Directional Emergency Strobe is perfect for most applications where size and intensity are important. This sleek self-contained LED requires only a one inch hole in any style head light, cornering light or tail light assembly. Can also be mounted on the outside of your vehicle as well. Product Features:- 10 flash patterns, includes a synchronized feature for alternating and synced flashing of multiple LED Lights. - Includes power, pattern and synchronization wires. - 4 LED Version and 9 LED Version available. - 10-16VDC Operation. - IP65 Rating. - Omni-directional LED Light mounts in any position. - Available in White, Blue, and Red. - Meets SAE J1113-41 Class 5. - No need for separate lamp drivers, flashers, ballast or power supplies to install. - LED Dimensions:1 1/2" W X 7/8" H - Driver Dimensions:4 3/4" L X 15/16" W X 7/16" H - Overall length: 160" or 13.3 ft. Wiring Explanation: - Red Wire - Power - Black Wire - Constant Ground - White Wire - Sync Wire used to sync other SMD Emergency Strobes - Yellow Wire- Used to select different modes, simple switch is needed Mode Explanation: - Steady On - Mode Cycle - SOS - 2 Round Burst - 3 Round Burst - 4 Round Burst - Fast Flash Steady - Fast Flash Burst - Fast Flash Burst + 12 SOS Flashes - Fast Flash Burst + 6 SOS Flashes Package includes: 1 x LED Light with driver 2 x Screws 1 x Gasket
Product Overview
Only 7/8 inches in height, the ORACLE SMD Omni-Directional Emergency Strobe is perfect for most applications where size and intensity are important. This sleek self-contained LED requires only a one inch hole in any style head light, cornering light or tail light assembly. Can also be mounted on the outside of your vehicle as well. Product Features:- 10 flash patterns, includes a synchronized feature for alternating and synced flashing of multiple LED Lights. - Includes power, pattern and synchronization wires. - 4 LED Version and 9 LED Version available. - 10-16VDC Operation. - IP65 Rating. - Omni-directional LED Light mounts in any position. - Available in White, Blue, and Red. - Meets SAE J1113-41 Class 5. - No need for separate lamp drivers, flashers, ballast or power supplies to install. - LED Dimensions:1 1/2" W X 7/8" H - Driver Dimensions:4 3/4" L X 15/16" W X 7/16" H - Overall length: 160" or 13.3 ft. Wiring Explanation: - Red Wire - Power - Black Wire - Constant Ground - White Wire - Sync Wire used to sync other SMD Emergency Strobes - Yellow Wire- Used to select different modes, simple switch is needed Mode Explanation: - Steady On - Mode Cycle - SOS - 2 Round Burst - 3 Round Burst - 4 Round Burst - Fast Flash Steady - Fast Flash Burst - Fast Flash Burst + 12 SOS Flashes - Fast Flash Burst + 6 SOS Flashes Package includes: 1 x LED Light with driver 2 x Screws 1 x Gasket
Features and Benefits
- Meets SAE J1113-41 Class 5
Product Details
| Add-On: | N/A |
|---|---|
| Adjustable Strobe: | Yes |
| Bulb Technology: | LED |
| Contents: | (1x) LED Light with driver, (2x) Screws, (1x) Gasket |
| Description: | Oracle 4 LED Omni-Directional Emergency Strobe - Blue |
| Dimensions: | Overall length: 160in. |
| Drilling Required: | Yes |
| LED Color: | Blue |
| Light Colors: | Blue |
| Part Number: | orl3507-002 |
| Prop 65 (C, R or CR): | CR |
| Prop 65 - Long Label: | Warning: This product contains chemicals known to the State of California to cause cancer or birth defects or other reproductive harm. For more information: www.P65Warnings.ca.gov |
| Prop 65 - Short Label: | WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov |
| Prop 65 - Warning: | Warning - Both Cancer and Reproduction.JPG |
| Prop 65 Yes/No: | Yes |
| Street Legal: | No |
| Title: | 3507-002 - ORACLE 4 LED Omni-Directional Emergency Strobe - Blue |
| Wire Gauge Measurement: | 18 |
| Wiring Harness Length: | 13.3 |
Application Summary
Universal
Part Type
Strobe Light
Features
- Meets SAE J1113-41 Class 5
Specifications
- Add-On:
- N/A
- Adjustable Strobe:
- Yes
- Bulb Technology:
- LED
- Contents:
- (1x) LED Light with driver, (2x) Screws, (1x) Gasket
- Description:
- Oracle 4 LED Omni-Directional Emergency Strobe - Blue
- Dimensions:
- Overall length: 160in.
- Drilling Required:
- Yes
- LED Color:
- Blue
- Light Colors:
- Blue
- Part Number:
- orl3507-002
- Prop 65 (C, R or CR):
- CR
- Prop 65 - Long Label:
- Warning: This product contains chemicals known to the State of California to cause cancer or birth defects or other reproductive harm. For more information: www.P65Warnings.ca.gov
- Prop 65 - Short Label:
- WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
- Prop 65 - Warning:
- Warning - Both Cancer and Reproduction.JPG
- Prop 65 Yes/No:
- Yes
- Street Legal:
- No
- Title:
- 3507-002 - ORACLE 4 LED Omni-Directional Emergency Strobe - Blue
- Wire Gauge Measurement:
- 18
- Wiring Harness Length:
- 13.3
Reference Information
| Brand Name/s | Oracle Lighting |
|---|---|
| StreetFX SKU | orl3507-002 |
| SFX Item ID | 4580719 |
| Supplier Item Code | 4580719 |
| Manufacturer SKU | 3507-002 |
| Manufacturer UPC | 350700220131 |
| Alternative References | OCL3507-002 |
Compatibility
Universal
