MSD Pro-Billet Tach Drive Distributors for 1963-1974 CORVETTE - 8572 Distributor, Drive, Magnetic Trigger, Mechanical, Vacuum Advance, Chevy, Big/Small Block, Each
MSD Pro-Billet Tach Drive Distributors for 1963-1974 CORVETTE - 8572 Distributor, Drive, Magnetic Trigger, Mechanical, Vacuum Advance, Chevy, Big/Small Block, Each
A$1,432.72
IN STOCK! Est Ship 4-7 days.
This item is IN STOCK at one of our warehouses or distribution centres, the ETA is the approximate time required to prepare your order for dispatch.
We accept
Description
If your racecar, Corvette, or race Corvette requires a distributor with a mechanical tach drive, these Pro-Billet Tach Drive distributors from MSD are what you need. Their race-proven magnetic pickup delivers precise trigger signals to your MSD ignition every time one of the reluctor's precision paddles pass by. This reluctor assembly is connected to an oversized steel shaft for increased strength and endurance, and is responsible for triggering the magnetic pickup. Inside the stout billet 6061-T6 aluminum housing, a sealed ball bearing and long sintered bushing guide the 0.500 in. steel shaft for high-rpm accuracy. Just above the reluctor is an adjustable mechanical advance assembly that lets you tailor a timing curve to match your engine's needs. This assembly is TIG welded for strength, and features chromoly weights and nylon pads to ensure smooth advance as the rpm increases. Corvette models feature a vacuum advance, and are available with or without an adjustable slip collar for engines that have had the deck height modified or use exotic intake manifolds. The distributors also feature a Rynite base. The tach drive assembly has a grease fitting for lubrication, is compact to clear the firewall and linkage, and can be repositioned easily to fit different applications. These distributors require the use of a separate ignition box, such as an MSD 6, 7, 8, or 10 Series ignition.
Part Type
Chevy Corvette Distributor
Specifications
- Product Attributes - Brand
- MSD Ignition
- Product Attributes - Manufacturer's Part Number
- 8572
- Product Attributes - Part Type
- Distributors
- Product Attributes - Product Line
- MSD Pro-Billet Tach Drive Distributors
- Product Attributes - UPC
- 085132085729
- Product Attributes - Distributor Cap Included
- Yes
- Product Attributes - Distributor Cap Style
- Male/HEI
- Product Attributes - Distributor Cap Type
- Small cap
- Product Attributes - Ignition Coil Included
- No
- Product Attributes - Ignition Module Included
- No
- Product Attributes - Computer-Controlled Compatible
- No
- Product Attributes - Trigger Style
- Magnetic
- Product Attributes - Advance Type
- Vacuum and mechanical
- Product Attributes - Ignition Box Required
- Yes
- Product Attributes - Mechanical Tach Drive
- Corvette
- Product Attributes - Slip Collar
- No
- Product Attributes - Distributor Gear Material
- Iron
- Product Attributes - Distributor Gear Rotation
- Standard
- Product Attributes - Distributor Cap Color
- Red
- Product Attributes - Housing Material
- Aluminum
- Product Attributes - Housing Finish
- Natural
- Product Attributes - Marine Use
- No
- Product Attributes - Remanufactured
- No
- Product Attributes - Quantity
- Sold individually.
- Product Attributes - CARB EO Number(s)
- D-40-39
- Product Attributes - Emissions
- California EO Approved
Reference Information
| Brand Name/s | Msd Ignition |
|---|---|
| StreetFX SKU | msd8572 |
| SFX Item ID | 4973567 |
| Supplier Item Code | 4973567 |
| Manufacturer SKU | 8572 |
| Manufacturer UPC | 85132085729 |
