Moroso Chevrolet Big Block Mark IV (w/Four Pick Ups) Drag Race Dry Sump 7.5in Aluminum Oil Pan
Moroso Chevrolet Big Block Mark IV (w/Four Pick Ups) Drag Race Dry Sump 7.5in Aluminum Oil Pan
A$3,304.56
IN STOCK! Est Ship 4-7 days.
This item is IN STOCK at one of our warehouses or distribution centres, the ETA is the approximate time required to prepare your order for dispatch.
We accept
Description
Moroso Ultra-Pro aluminum Pro Modified oil pans have all of the features and designs that you need for your high-horsepower engine. They have a removable bottom section that provides quick, between-rounds access to inspect main bearings and replace pistons without removing the entire oil pan. The removable section uses a machined channel, which accommodates a reusable square O-ring rubber gasket to provide leak-free sealing. The Moroso Ultra-Pro aluminum Pro Modified oil pans are box-style, all-aluminum pans featuring a maximum-size power kickout, a unidirectional windage tray screen, a block-high crankshaft scraper, and internal baffling. Designed for 2-piece rear main seal Donovan-style big block Chevrolet engines, Moroso Ultra-Pro aluminum Pro Modified oil pans give you the strength, reliability, and access that you need for your engine.
Product Overview
Moroso Chevrolet Big Block Mark IV (w/Four Pick Ups) Drag Race Dry Sump 7.5in Aluminum Oil Pan
Product Details
| Description: | Moroso Chevrolet Big Block Mark IV (w/Four Pick Ups) Drag Race Dry Sump 7.5in Aluminum Oil Pan |
|---|---|
| Part Number: | mor21581 |
Part Type
BBC Ultra-Pro Alum. Dry Sump Oil Pan
Specifications
- Product Attributes - Brand
- Moroso
- Product Attributes - Manufacturer's Part Number
- 21581
- Product Attributes - Part Type
- Oil Pans
- Product Attributes - Product Line
- Moroso Ultra-Pro Aluminum Pro Modified Oil Pans
- Product Attributes - UPC
- 084663215810
- Product Attributes - Sump Style
- Dry
- Product Attributes - Oil Pan Style
- Drag Race
- Product Attributes - Rear Main Seal Style
- 2-piece
- Product Attributes - Sump Location
- Full
- Product Attributes - Stroker Clearanced
- Yes
- Product Attributes - Maximum Stroke with OE Rod
- 4.500 in.
- Product Attributes - Dipstick Provision
- No
- Product Attributes - Dipstick Included
- No
- Product Attributes - Oil Pan Depth (in.)
- 7.500
- Product Attributes - Oil Pan Material
- Aluminum
- Product Attributes - Oil Pan Color
- Natural
- Product Attributes - Baffled
- No
- Product Attributes - Kicked Out
- Yes
- Product Attributes - Windage Tray Included
- Yes
- Product Attributes - Pickup Included
- No
- Product Attributes - Oil Pump Included
- No
- Product Attributes - Oil Pump Driveshaft Included
- No
- Product Attributes - Crank Scraper Included
- Yes
- Product Attributes - Drain Plug Thread Size
- 1/2 in.-20
- Product Attributes - Gaskets Included
- No
- Product Attributes - Hardware Included
- No
- Product Attributes - Quantity
- Sold individually.
- Product Attributes - Notes
- Accepts 5 in. stroke with aluminum rods.
Reference Information
| Brand Name/s | Moroso |
|---|---|
| StreetFX SKU | mor21581 |
| SFX Item ID | 4103510 |
| Supplier Item Code | 4103510 |
| Manufacturer SKU | 21581 |
| Manufacturer UPC | 84663215810 |
| Alternative References | 7.5in |
