Moroso

Moroso

Moroso Dart/Rocket Small Block (w/-16An External Pick Up) Wet Sump 8qt 8.5in Alum Oil Pan

SKU: MOR21248

Oil Pans

MOR Oil Pans...

Moroso Dart/Rocket Small Block (w/-16An External Pick Up) Wet Sump 8qt 8.5in Alum Oil Pan
Moroso

Moroso

Moroso Dart/Rocket Small Block (w/-16An External Pick Up) Wet Sump 8qt 8.5in Alum Oil Pan

SKU: MOR21248

Oil Pans

MOR Oil Pans...

A$2,307.72
Limited Availability from MFR Limited stock available from the manufacturer's distribution centre. The dispatch timeframe shown is an estimate based on historical orders of this part. This item is not held in our own warehouse, and availability and release timing may vary depending on manufacturer stock movements and processing at the time of ordering.
View cart 0
We accept
American Express
Mastercard
Visa
PayPal Checkout
Direct Deposit
Afterpay
Apple Pay
Google Pay
Zip Pay

Description

Moroso drag race oil pans are available for hundreds of vehicle-specific applications. The sizes and configurations are built for easy installation and optimum performance. Our selection includes a variety of styles, materials, and fluid capacities for drag racing, street and strip, and road race usage. Order the replacement model designed for your ride.

Product Overview

Moroso Dart/Rocket Small Block (w/-16An External Pick Up) Wet Sump 8qt 8.5in Alum Oil Pan

Product Details

Description:Moroso Dart/Rocket Small Block (w/-16An External Pick Up) Wet Sump 8qt 8.5in Alum Oil Pan
Part Number:mor21248

Part Type

Oil Pans

Data: v4.2 - Upd: 2026-10-13 17:56:56

Specifications

Product Attributes - Brand
Moroso
Product Attributes - Manufacturer's Part Number
21248
Product Attributes - Part Type
Oil Pans
Product Attributes - Product Line
Moroso Drag Race Pans
Product Attributes - UPC
084663212482
Product Attributes - Sump Style
Wet
Product Attributes - Oil Pan Style
Drag Race
Product Attributes - Rear Main Seal Style
2-piece
Product Attributes - Sump Location
Rear
Product Attributes - Dipstick Location
Driver side
Product Attributes - Oil Pan Capacity
8.00 quarts
Product Attributes - Stroker Clearanced
No
Product Attributes - Maximum Stroke with OE Rod
4.250 in.
Product Attributes - Dipstick Provision
Yes
Product Attributes - Dipstick Included
No
Product Attributes - Oil Pan Depth (in.)
8.500
Product Attributes - Oil Pan Material
Aluminum
Product Attributes - Oil Pan Color
Natural
Product Attributes - Baffled
Yes
Product Attributes - Kicked Out
Yes
Product Attributes - Kickout Position
Driver and passenger side
Product Attributes - Windage Tray Included
Yes
Product Attributes - Pickup Included
No
Product Attributes - Oil Pump Included
No
Product Attributes - Oil Pump Driveshaft Included
No
Product Attributes - Crank Scraper Included
No
Product Attributes - Gaskets Included
No
Product Attributes - Hardware Included
No
Product Attributes - Quantity
Sold individually.
Product Attributes - Notes
For use with Dart/Rocket block with 168-tooth flywheel or flexplate. Features O-ring magnetic drain plug, -8AN drain plug, -8AN dipstick bung, and -16AN external pick-up.

Reference Information

Brand Name/s Moroso
StreetFX SKU mor21248
SFX Item ID 4103486
Supplier Item Code 4103486
Manufacturer SKU 21248
Manufacturer UPC 84663212482
Alternative References (w/-16An, 8qt, 8.5in

Compatibility

Application Data
  • MakeCHEVROLET
    Beginning Year1955
    Ending Year1957
    Engine TypeV8
    Engine Size4.3L/265
    DrivetrainRWD
    Engine FamilyChevy small block Gen I
    Application NotesFor use with Dart/Rocket block with 168-tooth flywheel or flexplate. Features O-ring magnetic drain plug, -8AN drain plug, -8AN dipstick bung, and -16AN external pick-up.
  • MakeCHEVROLET
    Beginning Year1957
    Ending Year1967
    Engine TypeV8
    Engine Size4.6L/283
    DrivetrainRWD
    Engine FamilyChevy small block Gen I
    Application NotesFor use with Dart/Rocket block with 168-tooth flywheel or flexplate. Features O-ring magnetic drain plug, -8AN drain plug, -8AN dipstick bung, and -16AN external pick-up.
  • MakeCHEVROLET
    Beginning Year1962
    Ending Year1969
    Engine TypeV8
    Engine Size5.3L/327
    DrivetrainRWD
    Engine FamilyChevy small block Gen I
    Application NotesFor use with Dart/Rocket block with 168-tooth flywheel or flexplate. Features O-ring magnetic drain plug, -8AN drain plug, -8AN dipstick bung, and -16AN external pick-up.
  • MakeCHEVROLET
    Beginning Year1964
    Ending Year1967
    Engine TypeV8
    Engine Size5.4L/327
    DrivetrainRWD
    Engine FamilyChevy small block Gen I
    Application NotesFor use with Dart/Rocket block with 168-tooth flywheel or flexplate. Features O-ring magnetic drain plug, -8AN drain plug, -8AN dipstick bung, and -16AN external pick-up.
  • MakeCHEVROLET
    Beginning Year1967
    Ending Year1969
    Engine TypeV8
    Engine Size4.9L/302
    DrivetrainRWD
    Engine FamilyChevy small block Gen I
    Application NotesFor use with Dart/Rocket block with 168-tooth flywheel or flexplate. Features O-ring magnetic drain plug, -8AN drain plug, -8AN dipstick bung, and -16AN external pick-up.
  • MakeCHEVROLET
    Beginning Year1967
    Ending Year1985
    Engine TypeV8
    Engine Size5.7L/350
    DrivetrainRWD
    Engine FamilyChevy small block Gen I
    Application NotesFor use with Dart/Rocket block with 168-tooth flywheel or flexplate. Features O-ring magnetic drain plug, -8AN drain plug, -8AN dipstick bung, and -16AN external pick-up.
  • MakeCHEVROLET
    Beginning Year1968
    Ending Year1973
    Engine TypeV8
    Engine Size5.0L/307
    DrivetrainRWD
    Engine FamilyChevy small block Gen I
    Application NotesFor use with Dart/Rocket block with 168-tooth flywheel or flexplate. Features O-ring magnetic drain plug, -8AN drain plug, -8AN dipstick bung, and -16AN external pick-up.
  • MakeCHEVROLET
    Beginning Year1970
    Ending Year1980
    Engine TypeV8
    Engine Size6.6L/400
    DrivetrainRWD
    Engine FamilyChevy small block Gen I
    Application NotesFor use with Dart/Rocket block with 168-tooth flywheel or flexplate. Features O-ring magnetic drain plug, -8AN drain plug, -8AN dipstick bung, and -16AN external pick-up.
  • MakeCHEVROLET
    Beginning Year1975
    Ending Year1976
    Engine TypeV8
    Engine Size4.3L/262
    DrivetrainRWD
    Engine FamilyChevy small block Gen I
    Application NotesFor use with Dart/Rocket block with 168-tooth flywheel or flexplate. Features O-ring magnetic drain plug, -8AN drain plug, -8AN dipstick bung, and -16AN external pick-up.
  • MakeCHEVROLET
    Beginning Year1976
    Ending Year1985
    Engine TypeV8
    Engine Size5.0L/305
    DrivetrainRWD
    Engine FamilyChevy small block Gen I
    Application NotesFor use with Dart/Rocket block with 168-tooth flywheel or flexplate. Features O-ring magnetic drain plug, -8AN drain plug, -8AN dipstick bung, and -16AN external pick-up.
  • MakeCHEVROLET
    Beginning Year1979
    Ending Year1982
    Engine TypeV8
    Engine Size4.4L/267
    DrivetrainRWD
    Engine FamilyChevy small block Gen I
    Application NotesFor use with Dart/Rocket block with 168-tooth flywheel or flexplate. Features O-ring magnetic drain plug, -8AN drain plug, -8AN dipstick bung, and -16AN external pick-up.
