Moroso Ford 5.0L/5.2L Coyote Cobra Replica Road Race Baffled Rear T-Sump Steel Black Pc Oil Pan
Moroso Ford 5.0L/5.2L Coyote Cobra Replica Road Race Baffled Rear T-Sump Steel Black Pc Oil Pan
A$1,432.83
LAST ONE! Est Ship 4-7 days.
LAST ONE! This is the last unit at our distribution centre. Contact us if you need more. The ETA is the approximate time required to prepare your order for dispatch.
We accept
Description
IMPORTANT NOTICE: Designed for Cobra replicas that require a shallow rear sump pan. Uses factory windage tray and dipstick. Pan has two 1/2 in NPT fittings for temperature sensor and supercharger oil drainback and one 20mm fitting for low oil warning sensor.
Moroso offers a variety of wet sump baffled oil pans for road racing, drag racing, street and strip, and Circle Track applications. They're available for a variety of year/make and engine applications. Control your vital lubricant in extreme driving situations with a replacement or upgrade Moroso wet sump baffled oil pan.
Product Overview
Moroso Ford 5.0L/5.2L Coyote Cobra Replica Road Race Baffled Rear T-Sump Steel Black Pc Oil Pan
Product Details
| Description: | Moroso Ford 5.0L/5.2L Coyote Cobra Replica Road Race Baffled Rear T-Sump Steel Black Pc Oil Pan |
|---|---|
| Part Number: | mor20568 |
Part Type
Oil Pan Ford 5.0/5.2 Cobra Road-Race Steel
Specifications
- Product Attributes - Brand
- Moroso
- Product Attributes - Manufacturer's Part Number
- 20568
- Product Attributes - Part Type
- Oil Pans
- Product Attributes - Product Line
- Moroso Wet Sump Road Race Baffled Oil Pans
- Product Attributes - UPC
- 084663205682
- Product Attributes - Sump Style
- Wet
- Product Attributes - Oil Pan Style
- Road Race
- Product Attributes - Sump Location
- Rear
- Product Attributes - Dipstick Location
- Driver side
- Product Attributes - Oil Pan Capacity
- 9.50 quarts
- Product Attributes - Stroker Clearanced
- No
- Product Attributes - Dipstick Provision
- Yes
- Product Attributes - Dipstick Included
- No
- Product Attributes - Oil Pan Depth (in.)
- 4.375
- Product Attributes - Oil Pan Material
- Steel
- Product Attributes - Oil Pan Color
- Black
- Product Attributes - Baffled
- Yes
- Product Attributes - Kicked Out
- Yes
- Product Attributes - Kickout Position
- Driver and passenger side
- Product Attributes - Windage Tray Included
- No
- Product Attributes - Pickup Included
- No
- Product Attributes - Oil Pump Included
- No
- Product Attributes - Oil Pump Driveshaft Included
- No
- Product Attributes - Crank Scraper Included
- No
- Product Attributes - Drain Plug Thread Size
- 1/2 in. NPT
- Product Attributes - Gaskets Included
- No
- Product Attributes - Hardware Included
- No
- Product Attributes - Quantity
- Sold individually.
- Product Attributes - Notes
- Designed for Cobra replicas that require a shallow rear sump pan. Uses factory windage tray and dipstick. Pan has two 1/2 in NPT fittings for temperature sensor and supercharger oil drainback and one 20mm fitting for low oil warning sensor.
Reference Information
| Brand Name/s | Moroso |
|---|---|
| StreetFX SKU | mor20568 |
| SFX Item ID | 4105710 |
| Supplier Item Code | 4105710 |
| Manufacturer SKU | 20568 |
| Manufacturer UPC | 84663205682 |
| Alternative References | 5.0L/5.2L |
Compatibility
| Application Data |
|
|---|
Loading compatibility information...
