Moroso GM BBC Stroker Straight Box Sump Oil Pan

SKU: MOR20025

Oil Pans

MOR Oil Pans...

Moroso GM BBC Stroker Straight Box Sump Oil Pan
Moroso

Moroso

Moroso GM BBC Stroker Straight Box Sump Oil Pan

SKU: MOR20025

Oil Pans

MOR Oil Pans...

A$1,120.19
IN STOCK! Est Ship 4-7 days. This item is IN STOCK at one of our warehouses or distribution centres, the ETA is the approximate time required to prepare your order for dispatch.
View cart 0
We accept
American Express
Mastercard
Visa
PayPal Checkout
Direct Deposit
Afterpay
Apple Pay
Google Pay
Zip Pay

Description

Moroso straight box sump oil pans clear 4.75 in. stroke with most steel rods, 4.5 in. stroke with most aluminum rods. The core-based pans use the stock bolt pattern—and feature dual trap doors, rear anti-climb baffle, and removable anti-slosh baffle for improved oil control. The replacement units are constructed of steel with a clear zinc finish for protection. They're designed for use with 168 and 153-tooth flywheel combinations.

Product Overview

Moroso GM BBC Stroker Straight Box Sump Oil Pan

Product Details

Description:Moroso GM BBC Stroker Straight Box Sump Oil Pan
Part Number:mor20025

Part Type

BBC 11qt Wet Sump Oil Pan Straight Box Sump

Data: v4.2 - Upd: 2026-10-13 17:53:10

Specifications

Product Attributes - Brand
Moroso
Product Attributes - Manufacturer's Part Number
20025
Product Attributes - Part Type
Oil Pans
Product Attributes - Product Line
Moroso Straight Box Sump Oil Pans
Product Attributes - UPC
084663200250
Product Attributes - Sump Style
Wet
Product Attributes - Oil Pan Style
Street/Strip
Product Attributes - Rear Main Seal Style
2-piece
Product Attributes - Sump Location
Rear
Product Attributes - Dipstick Location
Passenger side
Product Attributes - Oil Pan Capacity
11.00 quarts
Product Attributes - Stroker Clearanced
Yes
Product Attributes - Maximum Stroke with OE Rod
4.750 in.
Product Attributes - Dipstick Provision
Yes
Product Attributes - Dipstick Included
No
Product Attributes - Oil Pan Depth (in.)
8.000
Product Attributes - Oil Pan Material
Steel
Product Attributes - Oil Pan Color
Black
Product Attributes - Baffled
Yes
Product Attributes - Kicked Out
No
Product Attributes - Windage Tray Included
No
Product Attributes - Pickup Included
No
Product Attributes - Oil Pump Included
No
Product Attributes - Oil Pump Driveshaft Included
No
Product Attributes - Crank Scraper Included
No
Product Attributes - Gaskets Included
No
Product Attributes - Hardware Included
No
Product Attributes - Quantity
Sold individually.
Product Attributes - Notes
Can be used in Drag race, Mud Truck, and Marine applications. Check clearance for your application.

Reference Information

Brand Name/s Moroso
StreetFX SKU mor20025
SFX Item ID 4105883
Supplier Item Code 4105883
Manufacturer SKU 20025
Manufacturer UPC 84663200250

Compatibility

Application Data
  • MakeCHEVROLET
    Beginning Year1965
    Ending Year1970
    Engine TypeV8
    Engine Size6.5L/396
    Engine FamilyChevy big block Mark IV
    Application NotesCan be used in Drag race, Mud Truck, and Marine applications. Check clearance for your application.
  • MakeCHEVROLET
    Beginning Year1967
    Ending Year1969
    Engine TypeV8
    Engine Size7.0L/427
    Engine FamilyChevy big block Mark IV
    Application NotesCan be used in Drag race, Mud Truck, and Marine applications. Check clearance for your application.
  • MakeCHEVROLET
    Beginning Year1970
    Ending Year1972
    Engine TypeV8
    Engine Size6.6L/402
    Engine FamilyChevy big block Mark IV
    Application NotesCan be used in Drag race, Mud Truck, and Marine applications. Check clearance for your application.
  • MakeCHEVROLET
    Beginning Year1970
    Ending Year1990
    Engine TypeV8
    Engine Size7.4L/454
    Engine FamilyChevy big block Mark IV
    Application NotesCan be used in Drag race, Mud Truck, and Marine applications. Check clearance for your application.
