MagnaFlow Sys CB 02-04 VW Golf R32
MagnaFlow Sys CB 02-04 VW Golf R32
A$2,677.31
Last Available from MFR.
LAST ONE AVAILABLE from the manufacturer's distribution centre. Once sold, this item may not be immediately available again. The dispatch timeframe shown is an estimate based on historical orders for this part and is dependent on the manufacturer releasing the final available unit.
We accept
Description
The MagnaFlow Volkswagen R32 Touring Series Cat-Back Performance Exhaust System is the perfect partner for your 3.2L Volkswagen R32 to take on a grand tour or a weekend cruise thanks to the powerful, resonant exhaust note and dyno-proven performance it brings to the table. This durable, corrosion resistant stainless steel exhaust kit is engineered to conquer the miles with ease while enhancing your driving experience with Moderate exterior and Mild interior sound levels generated through its fast-flowing, mandrel bent 2.5in. main piping and 2 Straight-Through muffler that terminate in a Dual Split Rear exit with 4in. Polished Welded-On Double Wall Angle Cut Folded Edge tips. 16650 features a cat-back layout design to replace your import's stock exhaust components from the catalytic converter on back. The use of extensive 3D scans made during the development process has resulted in an easy-to-install, direct-fit design that fits your Volkswagen R32 like a glove. 16650 is produced using CNC precision robotic manufacturing techniques and is backed by MagnaFlow's limited lifetime construction warranty.
Product Overview
The MagnaFlow 2004 Volkswagen R32 Touring Series Cat-Back Performance Exhaust System 16650 is the perfect partner for your 3.2L 2004-2004 Volkswagen R32 to take on a grand tour or a weekend cruise thanks to the powerful, resonant exhaust note and dyno-proven performance it brings to the table. This durable, corrosion resistant stainless steel exhaust kit is engineered to conquer the miles with ease while enhancing your driving experience with Moderate exterior and Mild interior sound levels generated through its fast-flowing, mandrel bent 2.5in. main piping and 2 Straight-Through muffler that terminate in a Dual Split Rear exit with 4in. Polished Welded-On Double Wall Angle Cut Folded Edge tips. 16650 features a cat-back layout design to replace your import's stock exhaust components from the catalytic converter on back. This Volkswagen R32 exhaust system is compatible with 2004-2004 engines. The use of extensive 3D scans made during the development process has resulted in an easy-to-install, direct-fit design that fits your Volkswagen R32 like a glove. 16650 is produced using CNC precision robotic manufacturing techniques and is backed by MagnaFlow's limited lifetime construction warranty.
Features and Benefits
- 409 Stainless Steel Construction
- Increased Horsepower And Torque
- Mandrel Bent Tubing
Product Details
| 11010: | 18 |
|---|---|
| Anticipated Ship Out Time: | Approximately 1-2 Days |
| Attachment Style: | Clamp-On |
| Attachment Type: | Clamp-On |
| Catalytic Converter Quantity: | 0 |
| Clamp Type: | Band Clamp |
| Clamping Type: | Band Clamp |
| Clamps Included: | Yes |
| Color/Finish: | Stainless |
| Components: | Band Clamp=3 |
| Description: | Touring Series Stainless Cat-Back System |
| Exhaust Inlet Connection Type: | Clamp-On |
| Exhaust Pipe Material: | Stainless |
| Exhaust Tip Connection: | Welded-On |
| Exhaust Tip Cut: | Angle Cut |
| Exhaust Tip Diameter: | 4 |
| Exhaust Tip Edge: | Folded Edge |
| Exhaust Tip Finish: | Polished |
| Exhaust Tip Intercooled: | No |
| Exhaust Tip Length: | 4.5 |
| Exhaust Tip Material: | Stainless Steel |
| Exhaust Tip Quantity: | 2 |
| Exhaust Tip Resonated: | No |
| Exhaust Tip Shape: | Round |
| Exhaust Tip Wall: | Double Wall |
| Exhaust Type: | Dual |
| Exit Location: | Dual Split Rear |
| Exit Position: | Dual Split Rear |
| Exit Quantity: | Dual |
| Exit Style: | Dual Split Rear |
| Finish: | Stainless |
| Gasket Included: | No |
| Gasket Or Seal Included: | No |
| Hangers Included: | Yes |
| Inlet Connection Type: | Clamp-On |
| Inlet Inside Diameter: | 2.500 in. |
| Inlet Type: | Clamp-On |
| Main Piping Diameter: | 2.500 in. |
| Material: | Stainless |
| Mounting Bracket Included: | No |
| Muffler (Front) Body Height: | 4 |
| Muffler (Front) Body Width: | 4 |
| Muffler (Rear) Body Height: | 5 |
| Muffler (Rear) Body Length: | 18 |
| Muffler (Rear) Body Width: | 8 |
| Muffler Body Diameter: | 4.000 in. x 4.000 in. |
| Muffler Body Finish: | Polished |
| Muffler Body Height Position Front: | 4 |
| Muffler Body Height Position Rear: | 5 |
| Muffler Body Height: | 4.000 in. |
| Muffler Body Length Position Front: | 18 |
| Muffler Body Length Position Rear: | 18 |
| Muffler Body Length: | 18.000 in. |
| Muffler Body Material: | Stainless Steel |
| Muffler Body Shape: | Round |
| Muffler Body Width Position Front: | 4 |
| Muffler Body Width Position Rear: | 8 |
| Muffler Body Width: | 4.000 in. |
| Muffler Count: | 2 |
| Muffler Finish: | Brushed |
| Muffler Material: | Stainless Steel |
| Muffler Quantity: | 2 |
| Muffler Type: | Straight-Through |
| Outlet Outside Diameter: | 4.000 in. |
| Part Number: | mag16650 |
| Pipe Material: | Stainless Steel |
| Prop 65 Y/N: | No |
| Recommended Use: | Performance |
| Series: | Touring |
| Sound Level: | Moderate |
| Subtitle: | Cat-Back Performance Exhaust System |
| Subtitles: | Cat-Back |
| System Type: | Cat Back |
| Tail Pipe Diameter: | 2.500 in. |
| Tip Diameter: | 4.000 in. |
| Tip Finish: | Polished |
| Tip Length: | 4.500 in. |
| Tip Material: | Stainless Steel |
| Tip Quantity: | 2 |
| Tip Shape: | Round |
| Tip Type: | Double Wall |
| Title: | MagnaFlow 2004 Volkswagen R32 Touring Series Cat-Back Performance Exhaust System |
| Tubing Diameter: | 2.500 in. |
| Type: | Cat-Back |
| Valve Included: | No |
| Valve Type: | None |
| WARNING CA Proposition 65: | No |
| Warranty: | Lifetime |
Part Type
Exhaust System Kit
Features
- 409 Stainless Steel Construction
- Increased Horsepower And Torque
- Mandrel bent tubing
Specifications
- Product Attributes - Brand
- MagnaFlow
- Product Attributes - Manufacturer's Part Number
- 16650
- Product Attributes - Part Type
- Exhaust Systems
- Product Attributes - Product Line
- MagnaFlow Touring Series Performance Exhaust Systems
- Product Attributes - UPC
- 841380019929
- Product Attributes - System Material
- 409 stainless steel
- Product Attributes - System Style
- Cat-back
- Product Attributes - Exhaust Type
- Single in/Dual out
- Product Attributes - Exit Location
- Split rear
- Product Attributes - System Finish
- Natural
- Product Attributes - Catalytic Converter(s) Included
- No
- Product Attributes - Intermediate Pipe Diameter (in.)
- 2.50 in.
- Product Attributes - Muffler Included
- Yes
- Product Attributes - Muffler Quantity
- Two
- Product Attributes - Muffler Configuration
- Dual inlet/Dual outlet
- Product Attributes - Muffler Style
- Perforated tube with packing
- Product Attributes - Muffler Material
- 409 stainless steel
- Product Attributes - Muffler Finish
- Polished
- Product Attributes - Hardware Included
- Yes
- Product Attributes - Tailpipe Diameter (in.)
- 2.50 in.
- Product Attributes - Tip Included
- Yes
- Product Attributes - Tip Outlet Size (in.)
- 4.00
- Product Attributes - Tip Quantity
- 2
- Product Attributes - Tip Shape
- Round
- Product Attributes - Tip Cut
- Slant
- Product Attributes - Tip Edge Style
- Rolled edge
- Product Attributes - Tip Material
- 304 stainless steel
- Product Attributes - Tip Color
- Polished
- Product Attributes - Remanufactured
- No
- Product Attributes - Quantity
- Sold as a kit.
- Product Attributes - Notes
- Depending on vehicle configuration, some modifications may be required. See installation instructions for details, if applicable. Kit includes polished muffler and resonator.
- Product Attributes - Special Attention
- It is illegal to install parts or components that bypass, defeat, or render inoperative the manufacturers’ technology and design necessary to reduce vehicle emissions to meet state and federal Clean Air Act standards.
Reference Information
| Brand Name/s | Magnaflow |
|---|---|
| StreetFX SKU | mag16650 |
| SFX Item ID | 4284563 |
| Supplier Item Code | 4284563 |
| Manufacturer SKU | 16650 |
| Manufacturer UPC | 841380019929 |
| Alternative References | mpe-16650, MFL16650, R32 |
