JE Pistons 367118 Pistons, SRP PRO 2618 SMALL BLOCK FLAT TOP

SKU: JEP367118

Pistons

JE Pistons

JE Pistons 367118 Pistons, SRP PRO 2618 SMALL BLOCK FLAT TOP

SKU: JEP367118

Pistons

BACKORDER This item will be special ordered in for you. Contact us prior to purchase if you require an ETA.

We accept

Description

Pistons, SRP PRO 2618 SMALL BLOCK FLAT TOP

Part Type

Pistons

Data: v4.2 - Upd: 2026-10-14 11:07:03

Specifications

Product Attributes - Brand: JE Pistons
Product Attributes - Manufacturer's Part Number: 367118
Product Attributes - Part Type: Pistons
Product Attributes - UPC: 193564265401
Product Attributes - Piston Rings Included: Yes
Product Attributes - Bore (in.): 4.130 in.
Product Attributes - Bore (mm): 104.902mm
Product Attributes - Stroke: 3.750 in.
Product Attributes - Engine Stroke Type: Stock
Product Attributes - Actual Engine Displacement: 6.6L/402
Product Attributes - Rod Length: 6.000 in.
Product Attributes - Piston Style: Flat top, with two valve reliefs
Product Attributes - Piston Material: Forged aluminum
Product Attributes - Compression Height (in.): 1.125 in.
Product Attributes - Piston Head Volume (cc): +5.00cc
Product Attributes - Wrist Pin Style: Press-fit or floating
Product Attributes - Wrist Pin Retainers Included: Yes
Product Attributes - Wrist Pin Included: Yes
Product Attributes - Pin Diameter (in.): 0.927 in.
Product Attributes - Piston Ring Thickness: 0.048 in. x 0.060 in. x 0.149 in.
Product Attributes - File Fit: No
Product Attributes - Gapless: No
Product Attributes - Top Ring Thickness: 0.048 in.
Product Attributes - Second Ring Thickness: 0.060 in.
Product Attributes - Oil Ring Thickness: 0.149 in.
Product Attributes - Remanufactured: No
Product Attributes - Quantity: Sold as a set of 8.
Product Attributes - Notes: Made from 2618 alloy forged aluminum.
Product Attributes - Special Attention: Designed to work with Chevy 23 degree cylinder heads with 20/30 valve spacing..
