JE Pistons Ultra Series 360830L Pistons, Single - Ford Modular Coyote -

SKU: JEP360830L

Pistons

JE Pistons

JE Pistons Ultra Series 360830L Pistons, Single - Ford Modular Coyote -

SKU: JEP360830L

Pistons

BACKORDER This item will be special ordered in for you. Contact us prior to purchase if you require an ETA.

We accept

Description

JE Ultra Series pistons combine all of the best, most desirable piston features, such as thermal barrier crown coating, lateral gas ports, thick-wall wrist pins, and a revolutionary new forging technology for the ultimate in strength. They are ready for massive power and boost right out of the box.

Features of the JE Ultra Series pistons:

* Grain flow optimized 2618 forging
* Lateral gas ports improve ring seal
* Ceramic crown coating—thermal barrier blocks combustion heat for durability and better exhaust scavenging characteristics
* Perfect Skirt Coating—protects skirts, reduces friction, and eliminates cold-start piston slap and false knock on computer-controlled engines
* Accumulator grooves reduce ring flutter at high rpm
* Double broach pin oiling
* Upgraded 9310 pins and locks—thicker, premium material wrist pins boosts strength
* Carbon steel nitride rings

Part Type

Pistons

Data: v4.2 - Upd: 2026-10-14 11:03:11

Specifications

Product Attributes - Brand: JE Pistons
Product Attributes - Manufacturer's Part Number: 360830L
Product Attributes - Part Type: Pistons
Product Attributes - Product Line: JE Pistons Ultra Series Pistons
Product Attributes - UPC: 193564198952
Product Attributes - Piston Rings Included: No
Product Attributes - Bore (in.): 3.630 in.
Product Attributes - Bore (mm): 92.200mm
Product Attributes - Stroke: 3.650 in.
Product Attributes - Engine Stroke Type: Stock
Product Attributes - Rod Length: 5.933 in.
Product Attributes - Piston Style: Dome, with four valve reliefs
Product Attributes - Piston Material: Forged aluminum
Product Attributes - Compression Height (in.): 1.174 in.
Product Attributes - Piston Head Volume (cc): -2.50cc
Product Attributes - Wrist Pin Style: Floating
Product Attributes - Wrist Pin Retainers Included: Yes
Product Attributes - Wrist Pin Included: Yes
Product Attributes - Pin Diameter (in.): 0.866 in.
Product Attributes - Piston Ring Thickness: 1.00mm x 1.20mm x 2.80mm
Product Attributes - File Fit: Yes
Product Attributes - Gapless: No
Product Attributes - Top Ring Thickness: 1.0mm
Product Attributes - Top Ring Material: Carbon steel
Product Attributes - Second Ring Thickness: 1.2mm
Product Attributes - Second Ring Material: Ductile iron
Product Attributes - Oil Ring Thickness: 2.8mm
Product Attributes - Oil Ring Material: Carbon steel
Product Attributes - Oil Ring Facing Material: Nitride
Product Attributes - Oil Ring Tension: Standard
Product Attributes - Remanufactured: No
Product Attributes - Quantity: Sold individually.
Product Attributes - Notes: JEP-JG1008-3632 is the recommended piston ring set.
