JE Pistons 360825R Pistons, Single - GM Gen V LT1 .943" Pin

SKU: JEP360825R

Pistons

SKU: JEP360825R

Pistons

BACKORDER This item will be special ordered in for you. Contact us prior to purchase if you require an ETA.

We accept

Description

Pistons, Single - GM Gen V LT1 .943" Pin

Pistons

Data: v4.2 - Upd: 2026-10-14 11:03:11

Product Attributes - Brand: JE Pistons
Product Attributes - Manufacturer's Part Number: 360825R
Product Attributes - Part Type: Pistons
Product Attributes - UPC: 193564200501
Product Attributes - Piston Rings Included: Yes
Product Attributes - Bore (in.): 4.070 in.
Product Attributes - Bore (mm): 103.378mm
Product Attributes - Stroke: 3.622 in.
Product Attributes - Engine Stroke Type: Stock
Product Attributes - Actual Engine Displacement: 6.2L/377
Product Attributes - Rod Length: 6.098 in.
Product Attributes - Piston Style: Dish, with two valve reliefs
Product Attributes - Piston Material: Forged aluminum
Product Attributes - Compression Height (in.): 1.326 in.
Product Attributes - Piston Head Volume (cc): +14.10cc
Product Attributes - Wrist Pin Style: Press-fit or floating
Product Attributes - Wrist Pin Retainers Included: Yes
Product Attributes - Wrist Pin Included: Yes
Product Attributes - Pin Diameter (in.): 0.943 in.
Product Attributes - Piston Ring Thickness: 1.20mm x 1.50mm x 3.00mm
Product Attributes - File Fit: No
Product Attributes - Gapless: No
Product Attributes - Top Ring Thickness: 1.2mm
Product Attributes - Second Ring Thickness: 1.5mm
Product Attributes - Oil Ring Thickness: 3.0mm
Product Attributes - Remanufactured: No
Product Attributes - Quantity: Sold individually.
Product Attributes - Notes: For the right side of the engine. Made from 2618 alloy forged aluminum.
