Description

Data: v4.2 - Upd: 2026-10-14 11:04:39

Specifications

Product Attributes - Brand

JE Pistons

Product Attributes - Manufacturer's Part Number

326375L

Product Attributes - Part Type

Pistons

Product Attributes - UPC

193564200891

Product Attributes - Piston Rings Included

No

Product Attributes - Bore (in.)

3.905 in.

Product Attributes - Bore (mm)

99.187mm

Product Attributes - Stroke

4.000 in.

Product Attributes - Engine Stroke Type

Stroked

Product Attributes - Actual Engine Displacement

6.3L/383

Product Attributes - Rod Length

6.125 in.

Product Attributes - Piston Style

Dish, with two valve reliefs

Product Attributes - Piston Material

Forged aluminum

Product Attributes - Compression Height (in.)

1.115 in.

Product Attributes - Piston Head Volume (cc)

+30.20cc

Product Attributes - Wrist Pin Style

Press-fit or floating

Product Attributes - Wrist Pin Retainers Included

Yes

Product Attributes - Wrist Pin Included

Yes

Product Attributes - Pin Diameter (in.)

0.927 in.

Product Attributes - Piston Ring Thickness

1.50mm x 1.50mm x 3.00mm

Product Attributes - File Fit

No

Product Attributes - Gapless

No

Product Attributes - Top Ring Thickness

1.5mm

Product Attributes - Second Ring Thickness

1.5mm

Product Attributes - Oil Ring Thickness

3.0mm

Product Attributes - Remanufactured

No

Product Attributes - Quantity

Sold individually.

Product Attributes - Notes

For the left side of the engine. Made from 2618 alloy forged aluminum.

Product Attributes - Special Attention

Designed to work with LSX/L92 12-degree cylinder heads.
