JE Pistons Ford Modular 314693R Pistons, Single - 5.4L 4V MODULAR 9.5

SKU: JEP314693R

Pistons

JE Pistons

JE Pistons Ford Modular 314693R Pistons, Single - 5.4L 4V MODULAR 9.5

SKU: JEP314693R

Pistons

BACKORDER This item will be special ordered in for you. Contact us prior to purchase if you require an ETA.

We accept

Description

JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import, and sport compact applications, and they have been performance-proven in victory lane time and time again.

JE Pistons Ford Modular pistons are single replacements forged from 2618 aluminum and utilize a dedicated Forged Side Relief (FSR) forging specifically designed for high-horsepower Modular engine. Lightweight and extremely durable, each piston features high-quality offset wrist pins, locks, and accumulator grooves that help reduce pressure from combustion gases, reducing ring flutter and improving ring seal. Equip your engine with the best in forged pistons—JE Pistons.

Part Type

Pistons

Data: v4.2 - Upd: 2026-10-14 11:01:27

Specifications

Product Attributes - Brand: JE Pistons
Product Attributes - Manufacturer's Part Number: 314693R
Product Attributes - Part Type: Pistons
Product Attributes - Product Line: JE Pistons Ford Modular Pistons
Product Attributes - UPC: 193564195395
Product Attributes - Piston Rings Included: No
Product Attributes - Bore (in.): 3.562 in.
Product Attributes - Bore (mm): 90.475mm
Product Attributes - Stroke: 4.165 in.
Product Attributes - Engine Stroke Type: Stock
Product Attributes - Actual Engine Displacement: 5.4L/332
Product Attributes - Rod Length: 6.657 in.
Product Attributes - Piston Style: Dish, with four valve reliefs
Product Attributes - Piston Material: Forged aluminum
Product Attributes - Compression Height (in.): 1.320 in.
Product Attributes - Piston Head Volume (cc): +17.50cc
Product Attributes - Wrist Pin Style: Press-fit or floating
Product Attributes - Wrist Pin Retainers Included: Yes
Product Attributes - Wrist Pin Included: Yes
Product Attributes - Pin Diameter (in.): 0.866 in.
Product Attributes - Piston Ring Thickness: 0.039 in. x 0.047 in. x 0.110 in.
Product Attributes - File Fit: No
Product Attributes - Gapless: No
Product Attributes - Remanufactured: No
Product Attributes - Quantity: Sold individually.
Product Attributes - Notes: Fits right side exhaust valve orientation, works with turbocharger and nitrous.

Reference Information

Brand Name/s	JE Pistons
StreetFX SKU	jep314693R
SFX Item ID	4807113
Supplier Item Code	4807113
Manufacturer SKU	314693R
Manufacturer UPC	193564195395
Alternative References	5.4L

Compatibility

Application Data

Make	FORD
Beginning Year	2000
Ending Year	2000
Engine Type	V8
Engine Family	Ford modular V8
Engine Size	5.4L/330
Application Notes	This is a right side piston, that can be used on turbos, and with nitrous. Designed for 4 valve models.

Make	FORD
Beginning Year	2005
Ending Year	2012
Engine Type	V8
Engine Family	Ford modular V8
Engine Size	5.4L/330
Application Notes	This is a right side piston, that can be used on turbos, and with nitrous. Designed for 4 valve models.
