JE Pistons 13 Degree All Pro/13.5 GB2000 Dome Top 281799R Pistons, Single - 400SBC ALLPRO/GB2000
JE Pistons 13 Degree All Pro/13.5 GB2000 Dome Top 281799R Pistons, Single - 400SBC ALLPRO/GB2000
A$505.15
Special Order. Contact for ETA.
This item is out of stock in our warehouse and partner distribution centres. In some cases, this may be due to not having live inventory feeds available for all suppliers. Please contact us before ordering if you need to meet a specific deadline.
We accept
Description
JE Pistons 13 degree All Pro/13.5 degree GB2000 Dome Top series pistons are excellent for Sprint Car and drag race use. Valve reliefs will accommodate oversized valves and long-duration, tight lobe separation cams. Precision CNC-machined ring grooves are designed for 1/16, 1/16, and 3/16 rings. These pistons utilize dedicated left and right hand forgings.
Part Type
Pistons
Specifications
- Product Attributes - Brand
- JE Pistons
- Product Attributes - Manufacturer's Part Number
- 281799R
- Product Attributes - Part Type
- Pistons
- Product Attributes - Product Line
- JE Pistons 13 Degree All Pro/13.5 Degree GB2000 Dome Top Pistons
- Product Attributes - UPC
- 193564193810
- Product Attributes - Piston Rings Included
- No
- Product Attributes - Bore (in.)
- 4.135 in.
- Product Attributes - Bore (mm)
- 105.029mm
- Product Attributes - Stroke
- 3.800 in.
- Product Attributes - Engine Stroke Type
- Stroked
- Product Attributes - Actual Engine Displacement
- 6.7L/408
- Product Attributes - Rod Length
- 5.850 in.
- Product Attributes - Piston Style
- Dome, with two valve reliefs
- Product Attributes - Piston Material
- Forged aluminum
- Product Attributes - Compression Height (in.)
- 1.250 in.
- Product Attributes - Piston Head Volume (cc)
- -4.70cc
- Product Attributes - Wrist Pin Style
- Press-fit or floating
- Product Attributes - Wrist Pin Retainers Included
- Yes
- Product Attributes - Wrist Pin Included
- Yes
- Product Attributes - Pin Diameter (in.)
- 0.927 in.
- Product Attributes - Piston Ring Thickness
- 1.20mm x 1.50mm x 3.00mm
- Product Attributes - File Fit
- No
- Product Attributes - Gapless
- No
- Product Attributes - Top Ring Thickness
- 1.2mm
- Product Attributes - Second Ring Thickness
- 1.5mm
- Product Attributes - Oil Ring Thickness
- 3.0mm
- Product Attributes - Remanufactured
- No
- Product Attributes - Quantity
- Sold individually.
- Product Attributes - Notes
- Designed to fit right exhaust valve orientation.
Reference Information
| Brand Name/s | JE Pistons |
|---|---|
| StreetFX SKU | jep281799R |
| SFX Item ID | 4801922 |
| Supplier Item Code | 4801922 |
| Manufacturer SKU | 281799R |
| Manufacturer UPC | 193564193810 |
| Alternative References | Pro/13.5, GB2000, 400SBC, ALLPRO/GB2000 |
