JE Pistons NASCAR Canadian Tire Series Chevy Small Block 253732R Pistons, Single - CANADA SBC
JE Pistons NASCAR Canadian Tire Series Chevy Small Block 253732R Pistons, Single - CANADA SBC
A$512.33
Special Order. Contact for ETA.
This item is out of stock in our warehouse and partner distribution centres. In some cases, this may be due to not having live inventory feeds available for all suppliers. Please contact us before ordering if you need to meet a specific deadline.
We accept
Description
JE Pistons NASCAR Canadian Tire Series Chevy small block pistons feature 2618 high-strength aluminum alloy construction with precision CNC-machined ring grooves and are approved by NASCAR for use in competition. These individual pistons include carbon steel wrist pins and double spiro locks.
Part Type
Pistons
Specifications
- Product Attributes - Brand
- JE Pistons
- Product Attributes - Manufacturer's Part Number
- 253732R
- Product Attributes - Part Type
- Pistons
- Product Attributes - Product Line
- JE Pistons NASCAR Canadian Tire Series Chevy Small Block Pistons
- Product Attributes - UPC
- 193564209627
- Product Attributes - Piston Rings Included
- No
- Product Attributes - Bore (in.)
- 4.030 in.
- Product Attributes - Bore (mm)
- 102.362mm
- Product Attributes - Stroke
- 3.480 in.
- Product Attributes - Engine Stroke Type
- Stock
- Product Attributes - Actual Engine Displacement
- 5.8L/355
- Product Attributes - Rod Length
- 5.700 in.
- Product Attributes - Piston Style
- Dish, with two valve reliefs
- Product Attributes - Piston Material
- Forged aluminum
- Product Attributes - Compression Height (in.)
- 1.550 in.
- Product Attributes - Piston Head Volume (cc)
- -11.00cc
- Product Attributes - Wrist Pin Style
- Press-fit or floating
- Product Attributes - Wrist Pin Retainers Included
- Yes
- Product Attributes - Wrist Pin Included
- Yes
- Product Attributes - Pin Diameter (in.)
- 0.927 in.
- Product Attributes - Piston Ring Thickness
- 0.064 in. x 0.064 in. x 0.188 in.
- Product Attributes - File Fit
- No
- Product Attributes - Gapless
- No
- Product Attributes - Top Ring Thickness
- 0.064 in.
- Product Attributes - Second Ring Thickness
- 0.064 in.
- Product Attributes - Oil Ring Thickness
- 0.188 in.
- Product Attributes - Remanufactured
- No
- Product Attributes - Quantity
- Sold individually.
- Product Attributes - Notes
- Designed to fit right exhaust valve orientation.
Reference Information
| Brand Name/s | JE Pistons |
|---|---|
| StreetFX SKU | jep253732R |
| SFX Item ID | 4805654 |
| Supplier Item Code | 4805654 |
| Manufacturer SKU | 253732R |
| Manufacturer UPC | 193564209627 |
