JE Pistons Ultra Series 207481L Pistons, Single - 350SBC ULTRA LT GP

SKU: JEP207481L

Pistons

JE Pistons

JE Pistons Ultra Series 207481L Pistons, Single - 350SBC ULTRA LT GP

SKU: JEP207481L

Pistons

BACKORDER This item will be special ordered in for you. Contact us prior to purchase if you require an ETA.

We accept

Description

JE Ultra Series pistons combine all of the best, most desirable piston features, such as thermal barrier crown coating, lateral gas ports, thick-wall wrist pins, and a revolutionary new forging technology for the ultimate in strength. They are ready for massive power and boost right out of the box.

Features of the JE Ultra Series pistons:

* Grain flow optimized 2618 forging
* Lateral gas ports improve ring seal
* Ceramic crown coating—thermal barrier blocks combustion heat for durability and better exhaust scavenging characteristics
* Perfect Skirt Coating—protects skirts, reduces friction, and eliminates cold-start piston slap and false knock on computer-controlled engines
* Accumulator grooves reduce ring flutter at high rpm
* Double broach pin oiling
* Upgraded 9310 pins and locks—thicker, premium material wrist pins boosts strength
* Carbon steel nitride rings

Part Type

Pistons

Data: v4.2 - Upd: 2026-10-14 11:03:10

Specifications

Product Attributes - Brand: JE Pistons
Product Attributes - Manufacturer's Part Number: 207481L
Product Attributes - Part Type: Pistons
Product Attributes - Product Line: JE Pistons Ultra Series Pistons
Product Attributes - UPC: 193564188007
Product Attributes - Piston Rings Included: No
Product Attributes - Bore (in.): 4.035 in.
Product Attributes - Bore (mm): 102.489mm
Product Attributes - Stroke: 3.500 in.
Product Attributes - Engine Stroke Type: Stock/Stroked
Product Attributes - Actual Engine Displacement: 5.9L/358
Product Attributes - Rod Length: 6.250 in.
Product Attributes - Piston Style: Flat top, with two valve reliefs
Product Attributes - Piston Material: Forged aluminum
Product Attributes - Compression Height (in.): 1.000 in.
Product Attributes - Piston Head Volume (cc): +1.80cc
Product Attributes - Wrist Pin Style: Press-fit or floating
Product Attributes - Wrist Pin Retainers Included: Yes
Product Attributes - Wrist Pin Included: Yes
Product Attributes - Pin Diameter (in.): 0.927 in.
Product Attributes - Piston Ring Thickness: 0.043 in. x 0.043 in. x 3.00mm
Product Attributes - File Fit: No
Product Attributes - Gapless: No
Product Attributes - Top Ring Thickness: 0.043 in.
Product Attributes - Second Ring Thickness: 0.043 in.
Product Attributes - Oil Ring Thickness: 3.0mm
Product Attributes - Remanufactured: No
Product Attributes - Quantity: Sold individually.
Product Attributes - Notes: Designed to fit left exhaust valve orientation. Also fits 488 cubic in. engines with a 3.750 in stroke and 6.125 in. connecting rod, as well as the 409 cubic in. engines with 4.000 in. stroke and 6.000 in. connecting rod.

Reference Information

Brand Name/s	JE Pistons
StreetFX SKU	jep207481L
SFX Item ID	4805143
Supplier Item Code	4805143
Manufacturer SKU	207481L
Manufacturer UPC	193564188007
Alternative References	350SBC

Compatibility

Application Data

Make	CHEVROLET
Beginning Year	1967
Ending Year	2002
Engine Type	V8
Engine Family	Chevy small block Gen I
Engine Size	5.7L/350
Application Notes	Designed to fit left exhaust valve orientation. Also fits 488 cubic in. engines with a 3.750 in stroke and 6.125 in. connecting rod, as well as the 409 cubic in. engines with 4.000 in. stroke and 6.000 in. connecting rod.
