JE Pistons 302/351W Flat Top 188703R Pistons, Single - 302 SBF FLAT TOP
JE Pistons 302/351W Flat Top 188703R Pistons, Single - 302 SBF FLAT TOP
A$512.33
Special Order. Contact for ETA.
This item is out of stock in our warehouse and partner distribution centres. In some cases, this may be due to not having live inventory feeds available for all suppliers. Please contact us before ordering if you need to meet a specific deadline.
We accept
Description
JE Pistons 302/351W flat top pistons are designed to be compatible with nitrous applications. They will accommodate larger valves and long-duration, tight lobe separation cams. Their precision CNC-machined ring grooves accept 1/16, 1/16, 3/16 rings.
Part Type
Pistons
Specifications
- Product Attributes - Brand
- JE Pistons
- Product Attributes - Manufacturer's Part Number
- 188703R
- Product Attributes - Part Type
- Pistons
- Product Attributes - Product Line
- JE Pistons 302/351W Flat Top Pistons
- Product Attributes - UPC
- 193564186058
- Product Attributes - Piston Rings Included
- No
- Product Attributes - Bore (in.)
- 4.030 in.
- Product Attributes - Bore (mm)
- 102.362mm
- Product Attributes - Stroke
- 3.400 in.
- Product Attributes - Engine Stroke Type
- Stroked
- Product Attributes - Actual Engine Displacement
- 5.7L/347
- Product Attributes - Rod Length
- 5.400 in.
- Product Attributes - Piston Style
- Flat top, with two valve reliefs
- Product Attributes - Piston Material
- Forged aluminum
- Product Attributes - Compression Height (in.)
- 1.100 in.
- Product Attributes - Piston Head Volume (cc)
- +5.00cc
- Product Attributes - Wrist Pin Style
- Press-fit or floating
- Product Attributes - Wrist Pin Retainers Included
- Yes
- Product Attributes - Wrist Pin Included
- Yes
- Product Attributes - Pin Diameter (in.)
- 0.927 in.
- Product Attributes - Piston Ring Thickness
- 0.064 in. x 0.064 in. x 0.218 in.
- Product Attributes - File Fit
- No
- Product Attributes - Gapless
- No
- Product Attributes - Top Ring Thickness
- 0.064 in.
- Product Attributes - Second Ring Thickness
- 0.064 in.
- Product Attributes - Oil Ring Thickness
- 0.218 in.
- Product Attributes - Remanufactured
- No
- Product Attributes - Quantity
- Sold individually.
- Product Attributes - Notes
- Designed to fit right exhaust valve orientation. Oil rail support included.
Reference Information
| Brand Name/s | JE Pistons |
|---|---|
| StreetFX SKU | jep188703R |
| SFX Item ID | 4802016 |
| Supplier Item Code | 4802016 |
| Manufacturer SKU | 188703R |
| Manufacturer UPC | 193564186058 |
| Alternative References | 302/351W |
