JE Pistons Brodix -12 15 Degree Dome Top 186444L Pistons, Single - 400-12 SBC .150 DOME
JE Pistons Brodix -12 15 Degree Dome Top 186444L Pistons, Single - 400-12 SBC .150 DOME
A$512.33
Special Order. Contact for ETA.
This item is out of stock in our warehouse and partner distribution centres. In some cases, this may be due to not having live inventory feeds available for all suppliers. Please contact us before ordering if you need to meet a specific deadline.
We accept
Description
JE Pistons Brodix -12 15 degree dome top pistons are designed to work with most of the new 15 degree chamber designs. The race-proven hollow dome forging by JE Pistons is the newest design for Sprint Car applications. These pistons have deep valve reliefs to accommodate oversized valves and long-duration, tight lobe separation cams. They accept 1/16, 1/16, 3/16 rings. These pistons utilize hollow dome dedicated left and right hand forgings.
Part Type
Pistons
Specifications
- Product Attributes - Brand
- JE Pistons
- Product Attributes - Manufacturer's Part Number
- 186444L
- Product Attributes - Part Type
- Pistons
- Product Attributes - Product Line
- JE Pistons Brodix -12 15 Degree Dome Top Pistons
- Product Attributes - UPC
- 193564193285
- Product Attributes - Piston Rings Included
- No
- Product Attributes - Bore (in.)
- 4.130 in.
- Product Attributes - Bore (mm)
- 104.902mm
- Product Attributes - Stroke
- 3.800 in.
- Product Attributes - Engine Stroke Type
- Stroked
- Product Attributes - Actual Engine Displacement
- 6.7L/407
- Product Attributes - Rod Length
- 6.000 in.
- Product Attributes - Piston Style
- Dome, with two valve reliefs
- Product Attributes - Piston Material
- Forged aluminum
- Product Attributes - Compression Height (in.)
- 1.100 in.
- Product Attributes - Dome Height (in.)
- 0.150 in.
- Product Attributes - Piston Head Volume (cc)
- +3.00cc
- Product Attributes - Wrist Pin Style
- Press-fit or floating
- Product Attributes - Wrist Pin Retainers Included
- Yes
- Product Attributes - Wrist Pin Included
- Yes
- Product Attributes - Pin Diameter (in.)
- 0.927 in.
- Product Attributes - Piston Ring Thickness
- 0.064 in. x 0.064 in. x 0.218 in.
- Product Attributes - File Fit
- No
- Product Attributes - Gapless
- No
- Product Attributes - Top Ring Thickness
- 0.064 in.
- Product Attributes - Second Ring Thickness
- 0.064 in.
- Product Attributes - Oil Ring Thickness
- 0.218 in.
- Product Attributes - Remanufactured
- No
- Product Attributes - Quantity
- Sold individually.
- Product Attributes - Notes
- Designed to fit left exhaust valve orientation. Oil rail support included. Designed to work with most new 15 degree chamber design cylinder heads.
Reference Information
| Brand Name/s | JE Pistons |
|---|---|
| StreetFX SKU | jep186444L |
| SFX Item ID | 4804510 |
| Supplier Item Code | 4804510 |
| Manufacturer SKU | 186444L |
| Manufacturer UPC | 193564193285 |
