JE Pistons 454 BBC .350 DOME Set of 8 Pistons

SKU: JEP170671

Pistons

JE Piston Sets -8 Cyl...

Special Order. Contact for ETA. This item is out of stock in our warehouse and partner distribution centres. In some cases, this may be due to not having live inventory feeds available for all suppliers. Please contact us before ordering if you need to meet a specific deadline.

We accept

Description

JE Auto forged pistons from JE Pistons are the result of over 75 years of industry leading experience extended to our range of premium forged pistons for Chevrolet Big Block 454 Engines. JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons’ performance is proven in victory lane time and time again. Equipped with the following custom level features

Application Summary

Chevrolet Big Block 454

Part Type

Engine Piston Kit

Data: v4.2 - Upd: 2026-10-13 21:38:40

Features

Accumulator Groove: A specialty groove between the top and second ring provides added volume for blow-by gases. This helps reduce pressure between the rings, improving top ring seal and minimizing ring flutter at high cylinder pressures.
Designed specifically for Chevrolet Big Block 454 Engines. To provide optimized performance durability
Double Pin Oilers: Deliver twice the amount of oil to the wrist pin as compared to the standard single pin oiler.
Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
Includes high-quality wrist pins, and locks
Made 100% in the USA
Pin Fit: The pin bore is precision honed to attain an exact pin clearance. Clearances typically range from .0003 to .0010 between the wrist pin and pin bore.
Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
Smooth Crown Finish: Deburs all areas around the valve pocket and dome area, to reduces stress risers and prevent hot spots.
Vertical Gas Ports: Machined gas ports channel combustion pressure behind the top ring for improved cylinder sealing and reduced blow-by under high load. Common in drag racing applications where maximum ring seal is critical.

Specifications

Product Attributes - Brand: JE Pistons
Product Attributes - Manufacturer's Part Number: 170671
Product Attributes - Part Type: Pistons
Product Attributes - Product Line: JE Pistons Big Duke/Big Chief/Big Victor GP 18 Degree Pistons
Product Attributes - UPC: 00193564217653
Product Attributes - Piston Rings Included: No
Product Attributes - Bore (in.): 4.530 in.
Product Attributes - Bore (mm): 115.062mm
Product Attributes - Stroke: 4.250 in.
Product Attributes - Rod Length: 6.385 in.
Product Attributes - Piston Style: Dome, with two valve reliefs
Product Attributes - Piston Material: Forged aluminum
Product Attributes - Compression Height (in.): 1.270 in.
Product Attributes - Piston Head Volume (cc): -13.00cc
Product Attributes - Wrist Pin Style: Press-fit or floating
Product Attributes - Wrist Pin Retainers Included: No
Product Attributes - Wrist Pin Included: Yes
Product Attributes - Pin Diameter (in.): 0.990 in.
Product Attributes - Piston Ring Thickness: 0.043 in. x 1/16 in. x 3/16 in.
Product Attributes - File Fit: No
Product Attributes - Gapless: No
Product Attributes - Remanufactured: No
Product Attributes - Quantity: Sold individually.
Product Attributes - Notes: Oil rail support included.
