JE Pistons 131636L Pistons, Single - 4.030 SBC 8.5-INVDM

SKU: JEP131636L

Pistons

JE Pistons

JE Pistons 131636L Pistons, Single - 4.030 SBC 8.5-INVDM

SKU: JEP131636L

Pistons

LAST ONE! Est Ship 4-7 days. LAST ONE! This is the last unit at our distribution centre. Contact us if you need more. The ETA is the approximate time required to prepare your order for dispatch.

We accept

Description

Pistons, Single - 4.030 SBC 8.5-INVDM

Part Type

Pistons

Data: v4.2 - Upd: 2026-10-14 10:58:56

Specifications

Product Attributes - Brand: JE Pistons
Product Attributes - Manufacturer's Part Number: 131636L
Product Attributes - Part Type: Pistons
Product Attributes - UPC: 193564188656
Product Attributes - Piston Rings Included: No
Product Attributes - Bore (in.): 4.030 in.
Product Attributes - Bore (mm): 102.362mm
Product Attributes - Stroke: 3.480 in.
Product Attributes - Engine Stroke Type: Stock
Product Attributes - Actual Engine Displacement: 5.8L/355
Product Attributes - Rod Length: 5.700 in.
Product Attributes - Piston Style: Dish, with two valve reliefs
Product Attributes - Piston Material: Forged aluminum
Product Attributes - Compression Height (in.): 1.560 in.
Product Attributes - Piston Head Volume (cc): +21.40cc
Product Attributes - Wrist Pin Style: Press-fit or floating
Product Attributes - Wrist Pin Retainers Included: Yes
Product Attributes - Wrist Pin Included: Yes
Product Attributes - Pin Diameter (in.): 0.927 in.
Product Attributes - Piston Ring Thickness: 0.064 in. x 0.064 in. x 0.188 in.
Product Attributes - File Fit: No
Product Attributes - Gapless: No
Product Attributes - Top Ring Thickness: 0.064 in.
Product Attributes - Second Ring Thickness: 0.064 in.
Product Attributes - Oil Ring Thickness: 0.188 in.
Product Attributes - Remanufactured: No
Product Attributes - Quantity: Sold individually.
Product Attributes - Notes: For the left side of the engine. Made from 2618 alloy forged aluminum.
Product Attributes - Special Attention: Designed to work with Chevy 23 degree cylinder heads with 20/30 valve spacing..

Reference Information

Brand Name/s	JE Pistons
StreetFX SKU	jep131636L
SFX Item ID	4809503
Supplier Item Code	4809503
Manufacturer SKU	131636L
Manufacturer UPC	193564188656
Alternative References	8.5-INVDM
