ICON 2014+ Ram 2500 Air Ride Rear 2.5 Series Shocks VS PB - Pair
ICON 2014+ Ram 2500 Air Ride Rear 2.5 Series Shocks VS PB - Pair
A$2,551.54
Last Available from MFR.
LAST ONE AVAILABLE from the manufacturer's distribution centre. Once sold, this item may not be immediately available again. The dispatch timeframe shown is an estimate based on historical orders for this part and is dependent on the manufacturer releasing the final available unit.
We accept
Description
ICON Vehicle Specific (V.S.) 2.5 Aluminum Series shocks are designed and built to give your vehicle outstanding performance off-road and a smooth ride on the street. These shocks are configured specifically for each application in both length and damping tune. Like all ICON shock absorbers, V.S. 2.5 Aluminum Series shocks are 100% rebuildable and 100% revalveable. For piggyback and specific remote reservoir applications, ICON’s unique use of a 6061 billet aluminum manifold a few inches below the top cap of the shock creates an internal “Bump Zone” that when used creates an additional 20% of damping force. This additional force helps prevent harsh bottom outs and controls the suspension when compressing at high velocity. If you are looking for a more user defined tune, consider looking into the Compression Damping Control Valve (CDCV) shocks.
Product Overview
ICON Vehicle Specific (V.S.) 2.5 Aluminum Series shocks are designed and built to give your vehicle outstanding performance off-road and a smooth ride on the street. These shocks are configured specifically for each application in both length and damping tune. Like all ICON shock absorbers, V.S. 2.5 Aluminum Series shocks are 100% rebuildable and 100% revalveable. For piggyback and specific remote reservoir applications, ICON’s unique use of a 6061 billet aluminum manifold a few inches below the top cap of the shock creates an internal “Bump Zone” that when used creates an additional 20% of damping force. This additional force helps prevent harsh bottom outs and controls the suspension when compressing at high velocity. If you are looking for a more user defined tune, consider looking into the Compression Damping Control Valve (CDCV) shocks.
Features and Benefits
- All ICON 2.5 Series Piggyback and Remote Reservoir shocks can be upgraded to ICON’s Compression Damping Control Valve (CDCV)
- ICON’s internal “Bump Zone” increases damping by 20% to provide more control as the shock approaches full compression
- One-piece impact extruded aluminum cylinders offer excellent corrosion resistance and consistent finish
- 100% Rebuildable
- 100% Revalveable
- Remote reservoir design improves heat dissipation to reduce shock fade during prolonged use
- Premium grade 5WT shock oil for consistent suspension damping along a wide temperature range
- Nitrogen charged monotube design with piggyback reservoir
- One piece digressive piston design with vehicle specific valving for unsurpassed performance and ride quality on and off-road
- 7/8” diameter induction hardened, chrome plated shock shaft
- Polyurethane bushings and forged steel mounting stems for OE factory type fitment
- PTFE lined spherical bearings and application specific mounting hardware
- 6061 aircraft grade aluminum CNC machined components
Product Details
| 71060: | Piggyback Reservoir |
|---|---|
| AAP_UDA_12: | EA |
| AAP_UDA_22: | 1 |
| AAP_UDA_4: | 55 |
| Adjustable: | NO |
| Boot Included: | NO |
| Bore Diameter: | 2.25 |
| California Prop 65 Warning: | Yes |
| California Proposition 65: | WARNING: This product contains chemicals known to the State of California to cause cancer, and birth defects or other reproductive harm. |
| Cylinder Material: | Aluminum |
| Description: | 14-UP RAM 2500 AIR RIDE REAR 2.5 VS PB PAIR |
| External Reservoir: | Piggyback Reservoir |
| Gas Charged: | Yes |
| Lower Mount Type: | EYELET |
| Mounting Hardware Included: | Yes |
| Part Number: | ico217708P |
| Service Parts: | 191016 - 7.5" FINNED RESI UPGRADE KIT |
| Shock Absorber Body End Measuring Point: | CENTER OF EYELET |
| Shock Absorber Rod End Measuring Point: | Shoulder of Stem |
| Title: | 14-UP RAM 2500 AIR RIDE REAR 2.5 VS PB PAIR |
| Tube Outside Diameter: | 2.5 |
| Upper Mount Type: | Stem |
Kit Options
This item is available as a full kit.
Select a kit option in the following table if you are looking for this item in a bundle form with all associated components.
Kit option/s:
| Thumb | SKU | Kit Title |
|---|---|---|
 |
icoK212512A | ICON 2014+ Ram 2500 4WD 2.5in Stage 2 Suspension System (Air Ride) (1x ico217802P, 1x ico217708P, 1x ico214200) |
 |
icoK212542A | ICON 14+ Ram 2500 4WD 2.5in Stage 2 Suspension System(Air Ride) (1x ico217802P, 1x ico217708P, 1x ico214200) |
 |
icoK212543A | ICON 14+ Ram 2500 4WD 2.5in Stage 3 Suspension System (1x ico217802P, 1x ico217708P, 1x ico214200, 1x ico214214) |
Part Type
Suspension Shock Absorber Set
Features
- 100% Rebuildable
- 100% Revalveable
- 6061 aircraft grade aluminum CNC machined components
- 7/8” diameter induction hardened, chrome plated shock shaft
- All ICON 2.5 Series Piggyback and Remote Reservoir shocks can be upgraded to ICON’s Compression Damping Control Valve (CDCV)
- ICON’s internal “Bump Zone” increases damping by 20% to provide more control as the shock approaches full compression
- Nitrogen charged monotube design with piggyback reservoir
- One piece digressive piston design with vehicle specific valving for unsurpassed performance and ride quality on and off-road
- One-piece impact extruded aluminum cylinders offer excellent corrosion resistance and consistent finish
- Polyurethane bushings and forged steel mounting stems for OE factory type fitment
- Premium grade 5WT shock oil for consistent suspension damping along a wide temperature range
- PTFE lined spherical bearings and application specific mounting hardware
- Remote reservoir design improves heat dissipation to reduce shock fade during prolonged use
Specifications
- Product Attributes - Brand
- ICON Vehicle Dynamics
- Product Attributes - Manufacturer's Part Number
- 217708P
- Product Attributes - Part Type
- Shocks and Struts
- Product Attributes - UPC
- 00840103401027
Reference Information
| Brand Name/s | Icon |
|---|---|
| StreetFX SKU | ico217708P |
| SFX Item ID | 4140921 |
| Supplier Item Code | 4140921 |
| Manufacturer SKU | 217708P |
| Manufacturer UPC | 840103401027 |
| Alternative References | IVD217708P |
