Home / Shop / Holley Retrofit Engine Oil Pans for GM LS Engines 302-1 Pan, Swap, Aluminum, Natural, 4.250 in. Stroke, 5.5 Quarts, Chevy, 4.8, 5.3, 6.0L, Each

Holley Retrofit Engine Oil Pans for GM LS Engines 302-1 Pan, Swap, Aluminum, Natural, 4.250 in. Stroke, 5.5 Quarts, Chevy, 4.8, 5.3, 6.0L, Each

SKU: HLY302-1

Oil Pans

Holley

Holley Retrofit Engine Oil Pans for GM LS Engines 302-1 Pan, Swap, Aluminum, Natural, 4.250 in. Stroke, 5.5 Quarts, Chevy, 4.8, 5.3, 6.0L, Each

SKU: HLY302-1

Oil Pans

IN STOCK! Est Ship 4-7 days. This item is IN STOCK at one of our warehouses or distribution centres, the ETA is the approximate time required to prepare your order for dispatch.

We accept

Description

Holley retrofit engine oil pans for GM LS engines are designed to install an LS engine in a variety of GM muscle car and truck chassis. They provide OEM fitment, OEM oil filter mounting, OEM oil cooler port provision, OEM engine NVH suppression, OEM flange gasket and sealing, proper structural rigidity, and OEM bellhousing attachments. The oil pans are manufactured from traditional high-quality cast aluminum and include a sump baffle, oil pump pickup tube, sump plug, oil filter stud, and oil passage cover.

Part Type

GM Retro Fit Oil Pan - LS Engines

Data: v4.2 - Upd: 2026-10-14 03:44:37

Specifications

Product Attributes - Brand: Holley
Product Attributes - Manufacturer's Part Number: 302-1
Product Attributes - Part Type: Oil Pans
Product Attributes - Product Line: Holley Retrofit Engine Oil Pans for GM LS Engines
Product Attributes - UPC: 090127669648
Product Attributes - Sump Style: Wet
Product Attributes - Oil Pan Style: Street/Strip
Product Attributes - Sump Location: Rear
Product Attributes - Oil Pan Capacity: 5.50 quarts
Product Attributes - Stroker Clearanced: Yes
Product Attributes - Maximum Stroke with OE Rod: 4.250 in.
Product Attributes - Dipstick Provision: No
Product Attributes - Dipstick Included: No
Product Attributes - Oil Pan Depth (in.): 5.890
Product Attributes - Oil Pan Material: Aluminum
Product Attributes - Oil Pan Color: Natural
Product Attributes - Baffled: Yes
Product Attributes - Kicked Out: No
Product Attributes - Windage Tray Included: No
Product Attributes - Pickup Included: Yes
Product Attributes - Oil Pump Included: No
Product Attributes - Oil Pump Driveshaft Included: No
Product Attributes - Crank Scraper Included: No
Product Attributes - Gaskets Included: No
Product Attributes - Hardware Included: No
Product Attributes - Quantity: Sold individually.
Product Attributes - Notes: Engine will take a total of 6 quarts of oil including the stock filter. Engine location may need to be adjusted (up/down or fore/aft) for proper clearance.

Reference Information

Brand Name/s	Holley
StreetFX SKU	hly302-1
SFX Item ID	4783358
Supplier Item Code	4783358
Manufacturer SKU	302-1
Manufacturer UPC	90127669648
Alternative References	HOL302-1, 6.0L

Compatibility

Application Data

Make PONTIAC
Model GTO
Beginning Year 1967
Ending Year 1986
Engine Type V8
Engine Size 4.8L/294
Drivetrain RWD
Engine Family Chevy small block Gen III/IV (LS-based engines)
Make PONTIAC
Model GTO
Beginning Year 1967
Ending Year 1986
Engine Type V8
Engine Size 5.3L/325
Drivetrain RWD
Engine Family Chevy small block Gen III/IV (LS-based engines)
Make PONTIAC
Model GTO
Beginning Year 1967
Ending Year 1986
Engine Type V8
Engine Size 5.7L/350
Drivetrain RWD
Engine Family Chevy small block Gen III/IV (LS-based engines)
Make PONTIAC
Model GTO
Beginning Year 1967
Ending Year 1986
Engine Type V8
Engine Size 6.0L/364
Drivetrain RWD
Engine Family Chevy small block Gen III/IV (LS-based engines)
Make PONTIAC
Model GTO
Beginning Year 1967
Ending Year 1986
Engine Type V8
Engine Size 6.2L/376
Drivetrain RWD
Engine Family Chevy small block Gen III/IV (LS-based engines)
Make PONTIAC
Model LEMANS
Beginning Year 1963
Ending Year 1981
Engine Type V8
Engine Size 4.8L/294
Drivetrain RWD
Engine Family Chevy small block Gen III/IV (LS-based engines)
Make PONTIAC
Model LEMANS
Beginning Year 1963
Ending Year 1981
Engine Type V8
Engine Size 5.3L/325
Drivetrain RWD
Engine Family Chevy small block Gen III/IV (LS-based engines)
Make PONTIAC
Model LEMANS
Beginning Year 1963
Ending Year 1981
Engine Type V8
Engine Size 5.7L/350
Drivetrain RWD
Engine Family Chevy small block Gen III/IV (LS-based engines)
Make PONTIAC
Model LEMANS
Beginning Year 1963
Ending Year 1981
Engine Type V8
Engine Size 6.0L/364
Drivetrain RWD
Engine Family Chevy small block Gen III/IV (LS-based engines)
Make PONTIAC
Model LEMANS
Beginning Year 1963
Ending Year 1981
Engine Type V8
Engine Size 6.2L/376
Drivetrain RWD
Engine Family Chevy small block Gen III/IV (LS-based engines)
Make PONTIAC
Model PHOENIX
Beginning Year 1977
Ending Year 1979
Engine Type V8
Engine Size 4.8L/294
Drivetrain RWD
Engine Family Chevy small block Gen III/IV (LS-based engines)
Make PONTIAC
Model PHOENIX
Beginning Year 1977
Ending Year 1979
Engine Type V8
Engine Size 5.3L/325
Drivetrain RWD
Engine Family Chevy small block Gen III/IV (LS-based engines)
Make PONTIAC
Model PHOENIX
Beginning Year 1977
Ending Year 1979
Engine Type V8
Engine Size 5.7L/350
Drivetrain RWD
Engine Family Chevy small block Gen III/IV (LS-based engines)
Make PONTIAC
Model PHOENIX
Beginning Year 1977
Ending Year 1979
Engine Type V8
Engine Size 6.0L/364
Drivetrain RWD
Engine Family Chevy small block Gen III/IV (LS-based engines)
Make PONTIAC
Model PHOENIX
Beginning Year 1977
Ending Year 1979
Engine Type V8
Engine Size 6.2L/376
Drivetrain RWD
Engine Family Chevy small block Gen III/IV (LS-based engines)
Make PONTIAC
Model TEMPEST
Beginning Year 1961
Ending Year 1970
Engine Type V8
Engine Size 4.8L/294
Drivetrain RWD
Engine Family Chevy small block Gen III/IV (LS-based engines)
Make PONTIAC
Model TEMPEST
Beginning Year 1961
Ending Year 1970
Engine Type V8
Engine Size 5.3L/325
Drivetrain RWD
Engine Family Chevy small block Gen III/IV (LS-based engines)
Make PONTIAC
Model TEMPEST
Beginning Year 1961
Ending Year 1970
Engine Type V8
Engine Size 5.7L/350
Drivetrain RWD
Engine Family Chevy small block Gen III/IV (LS-based engines)
Make PONTIAC
Model TEMPEST
Beginning Year 1961
Ending Year 1970
Engine Type V8
Engine Size 6.0L/364
Drivetrain RWD
Engine Family Chevy small block Gen III/IV (LS-based engines)
Make PONTIAC
Model TEMPEST
Beginning Year 1961
Ending Year 1970
Engine Type V8
Engine Size 6.2L/376
Drivetrain RWD
Engine Family Chevy small block Gen III/IV (LS-based engines)
Make PONTIAC
Model VENTURA
Beginning Year 1971
Ending Year 1977
Engine Type V8
Engine Size 4.8L/294
Drivetrain RWD
Engine Family Chevy small block Gen III/IV (LS-based engines)
Make PONTIAC
Model VENTURA
Beginning Year 1971
Ending Year 1977
Engine Type V8
Engine Size 5.3L/325
Drivetrain RWD
Engine Family Chevy small block Gen III/IV (LS-based engines)
Make PONTIAC
Model VENTURA
Beginning Year 1971
Ending Year 1977
Engine Type V8
Engine Size 5.7L/350
Drivetrain RWD
Engine Family Chevy small block Gen III/IV (LS-based engines)
Make PONTIAC
Model VENTURA
Beginning Year 1971
Ending Year 1977
Engine Type V8
Engine Size 6.0L/364
Drivetrain RWD
Engine Family Chevy small block Gen III/IV (LS-based engines)
Make PONTIAC
Model VENTURA
Beginning Year 1971
Ending Year 1977
Engine Type V8
Engine Size 6.2L/376
Drivetrain RWD
Engine Family Chevy small block Gen III/IV (LS-based engines)
