On sale
Hella Horn Disc 24V 400Hz Htone (B36)
Hella Horn Disc 24V 400Hz Htone (B36)
A$79.52
Special Order. Contact for ETA.
This item is out of stock in our warehouse and partner distribution centres. In some cases, this may be due to not having live inventory feeds available for all suppliers. Please contact us before ordering if you need to meet a specific deadline.
We accept
Description
The HELLA B36 Series Disc Horn is engineered for durability and performance, providing a reliable safety feature for any vehicle. These disc horns are galvanized to resist corrosion and built to last, with a sound frequency of 335 Hz (Low-Tone), or 400 Hz (High-Tone), ensuring precise and robust auditory signals in all driving conditions. The sleek, compact design allows for versatile installation options, making it an excellent choice for drivers who need a powerful horn without compromising space. Whether navigating busy city streets or rural roads, the HELLA B36 Series enhances your vehicle's audible presence, ensuring you are heard when it matters most. These horns guarantee your highest safety and the attention needed in critical situations. HELLA horns guarantee the best functionality, optimum fit, and long-lasting customer satisfaction.
Product Overview
The HELLA B36 Series Disc Horn is engineered for durability and performance, providing a reliable safety feature for any vehicle. These disc horns are galvanized to resist corrosion and built to last, with a sound frequency of 335 Hz (Low-Tone), or 400 Hz (High-Tone), ensuring precise and robust auditory signals in all driving conditions. The sleek, compact design allows for versatile installation options, making it an excellent choice for drivers who need a powerful horn without compromising space. Whether navigating busy city streets or rural roads, the HELLA B36 Series enhances your vehicle's audible presence, ensuring you are heard when it matters most. These horns guarantee your highest safety and the attention needed in critical situations. HELLA horns guarantee the best functionality, optimum fit, and long-lasting customer satisfaction.
Features and Benefits
- With moisture protection
- Delivers maximum awareness with a volume output ranging from 108 dB(A) to 118 dB(A), ensuring audibility.
- Facilitates fast identification and installation with concise short codes, streamlining maintenance and replacement.
- Enhances road safety by emitting a 335 Hz tone, providing clear and audible alerts in all conditions.
- Ensures long-term reliability with robust construction engineered to withstand vibration and harsh conditions.
- Designed for universal compatibility, this part fits most modern vehicles, simplifying the installation process.
Product Details
| Assy./disassy. by qualified personnel required!: | . |
|---|---|
| Assy/Disassy by Qualified Personnel Required!: | . |
| Bracket: | M10 mounting screw |
| California Proposition 65 Required: | No |
| Depth (in): | 2.09 |
| Depth (mm): | 53 |
| Depth [mm]: | 53 |
| Description: | HORN 24V 400HZ B36 3BA |
| Diameter (cm): | 11.2 |
| Diameter (in): | 4.40 |
| Diameter (mm): | 112 |
| Diameter [cm]: | 11.2 |
| Diameter [in]: | 4.40 |
| Diameter [mm]: | 112 |
| Frequency Range (Hz): | 400 |
| Frequency Range [Hz]: | 400 |
| Frequency range to (Hz): | 400 |
| Frequency range to [Hz]: | 400 |
| Fulfils ECE norm: | R28 |
| Homologation: | ECE-R28 |
| Housing Color: | grey/black |
| Housing Colour: | Grey |
| IP Rating: | IP5K9K |
| Inspection Tag: | E1 20024 |
| Measurements (cm): | 5.3 x 12.9 |
| Measurements [cm]: | 5.3 x 12.9 |
| Mounting Type: | With 6.3 mm Blade Terminal Contacts, Open |
| Operating Mode: | Electric |
| Overall Height (in): | 5.08 |
| Overall Height (mm): | 129 |
| Overall Height [mm]: | 129 |
| Part Number: | hella002768431 |
| Power Consumption [W]: | 72 |
| Power consumption (A): | 3 |
| Protection Type (IP Code): | X4K |
| Protection: | IP54 |
| Quantity: | 1 |
| Rated Voltage [V]: | 24 |
| Registration Type: | ECE approved |
| Signal: | High Tone |
| Single Includes: | (1) High-Tone Disc Horn, Mounting Brackets, Step-by-Step Mounting Instructions |
| Sound Level (dB(A)): | 116 |
| Sound Level [dB(A)]: | 116 |
| Supplementary Article/Info 2: | with E quality seal |
| Temperature range from (C): | -40 |
| Temperature range from (F): | -40.00 |
| Temperature range from [°C]: | -40 |
| Temperature range to (C): | 90 |
| Temperature range to (F): | 140.00 |
| Temperature range to [°C]: | 60 |
| Test Mark: | ECE |
| Voltage (V): | 24 |
| Voltage [V]: | 24 |
| Voltage: | 24.00 |
| Wattage (W): | 72 |
Part Type
Operator controlled auditory alerting device
Features
- Delivers maximum awareness with a volume output ranging from 108 dB(A) to 118 dB(A), ensuring audibility.
- Designed for universal compatibility, this part fits most modern vehicles, simplifying the installation process.
- Enhances road safety by emitting a 335 Hz tone, providing clear and audible alerts in all conditions.
- Ensures long-term reliability with robust construction engineered to withstand vibration and harsh conditions.
- Facilitates fast identification and installation with concise short codes, streamlining maintenance and replacement.
- With moisture protection
Specifications
- Product Attributes - Brand
- Hella
- Product Attributes - Manufacturer's Part Number
- 002768431
- Product Attributes - Part Type
- Horns
- Product Attributes - UPC
- 04082300052640
Reference Information
| Brand Name/s | Hella |
|---|---|
| StreetFX SKU | hella002768431 |
| SFX Item ID | 4521122 |
| Supplier Item Code | 4521122 |
| Manufacturer SKU | 002768431 |
| Manufacturer UPC | N/A |
| Alternative References | HLA-002768431, 24V, 400Hz, (B36) |
