Edelbrock Polished B/B Chev Rect Port RPM Air-Gap Manifold
Edelbrock Polished B/B Chev Rect Port RPM Air-Gap Manifold
Sale ends in Calculating...
A$1,891.54 A$2,053.61
Special Order. Contact for ETA.
This item is out of stock in our warehouse and partner distribution centres. In some cases, this may be due to not having live inventory feeds available for all suppliers. Please contact us before ordering if you need to meet a specific deadline.
We accept
Description
IMPORTANT NOTICE: Requires a gasket with a 2.54 in. x 1.75 in. port size or runner will not seal due to extra bolt locations. Do not use large port gaskets. Will not fit under the stock hood of a Corvette, 1965-67 Chevelle or 1967-81 Camaro.
Edelbrock part #75621 RPM Air-Gap 2-R intake manifold is designed for street 396-502 c.i.d. Chevrolet V8's with high-performance rectangular-port heads. The open air space separates the runners from the hot engine oil, and as a result, the air/fuel mixture stays cooler for a denser charge and more power. This intake manifold is a dual-plane, high-rise design with a 180 degree firing order to produce incredible top-end horsepower while retaining good throttle response. The larger plenum and runners match the free-flowing exhaust, high-lift cams and other modifications of a high output engine. They are intended for high-performance's street or competition engines that run up to 6500 rpm. Includes rear water outlets, two distributor clamp locations and nitrous bosses. Accepts all late model alternator and A/C brackets for the street. For square-bore carbs only. No provision for exhaust heated chokes and no exhaust crossover. This manifold offers a polished finish for a brilliant shine and classic look.
Product Overview
Edelbrock part #75621 RPM Air-Gap 2-R intake manifold is designed for street 396-502 c.i.d. Chevrolet V8's with high-performance rectangular-port heads. The open air space separates the runners from the hot engine oil, and as a result, the air/fuel mixture stays cooler for a denser charge and more power. This intake manifold is a dual-plane, high-rise design with a 180 degree firing order to produce incredible top-end horsepower while retaining good throttle response. The larger plenum and runners match the free-flowing exhaust, high-lift cams and other modifications of a high output engine. They are intended for high-performance's street or competition engines that run up to 6500 rpm. Includes rear water outlets, two distributor clamp locations and nitrous bosses. Accepts all late model alternator and A/C brackets for the street. For square-bore carbs only. No provision for exhaust heated chokes and no exhaust crossover. This manifold offers a polished finish for a brilliant shine and classic look.
Features and Benefits
- Larger Plenum and Runners Maximizes Other Upgrades
Product Details
| Basic Operating RPM Range: | 1500-6500 |
|---|---|
| CNC Ported: | No |
| Center Maximum Height: | 5.220 |
| Cylinder Head Type: | Rectangular Port |
| Description: | RPM Air-Gap 2-R Intake Manifold |
| EGR Port: | No |
| Emission: | Without EGR |
| Engine Make/Size: | Chevy Big Block (396-502) |
| Finish: | Polished |
| Flange Type: | 4150 |
| Front Maximum Height: | 4.450 |
| Gasket Or Seal Included: | No |
| Grade Type: | Performance |
| Material: | Aluminum |
| Number of Carbs: | One |
| Part Number: | ede75621 |
| Position: | N/A |
| RGL: | WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| RPM Range: | 1500-6500 |
| Rear Maximum Height: | 6.000 |
| Series: | RPM Air-Gap |
| Single Or Dual Plane Type: | Dual |
| Usage: | Street/Hi-Performance |
| Vehicle Model: | Chevrolet |
| WARNING CA Proposition 65 Message: | WARNING: This product can expose you to Lead; which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information; visit www.P65warnings.ca.gov. |
| WARNING CA Proposition 65: | Yes |
Application Summary
Chevrolet:Big-Block Mark IV:396 (6.5L)-502 (8.2L)
Part Type
Engine Intake Manifold
Features
- Larger Plenum and Runners Maximizes Other Upgrades
Specifications
- Product Attributes - Brand
- Edelbrock
- Product Attributes - Manufacturer's Part Number
- 75621
- Product Attributes - Part Type
- Intake Manifolds, Carbureted
- Product Attributes - Product Line
- Edelbrock Performer RPM Air-Gap Intake Manifolds
- Product Attributes - UPC
- 085347756216
- Product Attributes - Intake Section Included
- Complete
- Product Attributes - Engine Block Deck Height
- Standard deck
- Product Attributes - Carburetor Quantity
- One
- Product Attributes - Intake Style
- Dual plane
- Product Attributes - Basic Operating RPM Range
- 1,500-6,500
- Product Attributes - Intake Manifold Height
- 5.220 in.
- Product Attributes - Intake Color
- Polished
- Product Attributes - Intake Material
- Aluminum
- Product Attributes - EGR
- No
- Product Attributes - Quantity
- Sold individually.
- Product Attributes - Notes
- Requires a gasket with a 2.54 in. x 1.75 in. port size or runner will not seal due to extra bolt locations. Do not use large port gaskets. Will not fit under the stock hood of a Corvette, 1965-67 Chevelle or 1967-81 Camaro.
Reference Information
| Brand Name/s | Edelbrock |
|---|---|
| StreetFX SKU | ede75621 |
| SFX Item ID | 4236932 |
| Supplier Item Code | 4236932 |
| Manufacturer SKU | 75621 |
| Manufacturer UPC | 85347756216 |
| Alternative References | EDB75621, EDL-75621 |
Brochures
Compatibility
Chevrolet:Big-Block Mark IV:396 (6.5L)-502 (8.2L)
