Edelbrock Manifold EFI Pro-Flo XT LS3 Series Black Finish
Edelbrock Manifold EFI Pro-Flo XT LS3 Series Black Finish
A$1,925.23
Available from MFR.
This item is available from the manufacturer's distribution centre. The dispatch timeframe shown is an estimate based on historical order processing and release times for this part. This item is not held in our own warehouse, and actual dispatch timing may vary depending on manufacturer workload and logistics at the time of ordering.
We accept
Description
Edelbrock part #7142 Pro Flo XT LS3 intake manifold is designed for use on GM LS3 engines. This manifold will accept late model LS Drive-By-Wire throttle bodies or Edelbrock 90mm mechanical throttle body and is offered in a black powder coat finish. This manifold is not intended to be a direct replacement for late model vehicle applications due to hood/cowl clearance and emissions incompatibility.
Product Overview
Edelbrock part #7142 Pro Flo XT LS3 intake manifold is designed for use on GM LS3 engines. This manifold will accept late model LS Drive-By-Wire throttle bodies or Edelbrock 90mm mechanical throttle body and is offered in a black powder coat finish. This manifold is not intended to be a direct replacement for late model vehicle applications due to hood/cowl clearance and emissions incompatibility.
Features and Benefits
- 90mm Throttle Bore Opening
Product Details
| Basic Operating RPM Range: | 1500-7000 |
|---|---|
| CNC Ported: | No |
| Center Maximum Height: | 9.680 |
| Cylinder Head Type: | Standard |
| Description: | Pro-Flo XT EFI Intake Manifold |
| EGR Port: | No |
| Emission: | Without EGR |
| Engine Make/Size: | Chevy LS3 |
| Finish: | Black Powder Coated |
| Flange Type: | Throttle Body XT |
| Front Maximum Height: | 9.280 |
| Gasket Or Seal Included: | No |
| Grade Type: | Performance |
| Material: | Aluminum |
| Number of Carbs: | One |
| Part Number: | ede7142 |
| Position: | N/A |
| RGL: | WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| RPM Range: | 1500-7000 |
| Rear Maximum Height: | 9.680 |
| Series: | Pro-Flo XT |
| Single Or Dual Plane Type: | Single |
| Usage: | Racing |
| Vehicle Model: | Chevrolet |
| WARNING CA Proposition 65 Message: | WARNING: This product can expose you to Lead; which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information; visit www.P65warnings.ca.gov. |
| WARNING CA Proposition 65: | Yes |
Application Summary
Chevrolet:Small-Block Gen IV L76:364 (6.0L);Chevrolet:Small-Block Gen IV L77:364 (6.0L);Chevrolet:Small-Block Gen IV L92:376 (6.2L);Chevrolet:Small-Block Gen IV L94:376 (6.2L);Chevrolet:Small-Block Gen IV L99:376 (6.2L);Chevrolet:Small-Block Gen IV L9H:37
Part Type
Engine Intake Manifold
Features
- 90mm Throttle Bore Opening
Specifications
- Product Attributes - Brand
- Edelbrock
- Product Attributes - Manufacturer's Part Number
- 7142
- Product Attributes - Part Type
- Intake Manifolds, Fuel Injected
- Product Attributes - Product Line
- Edelbrock Pro-Flo XT EFI Intake Manifolds
- Product Attributes - UPC
- 085347071425
- Product Attributes - Cylinder Head Configuration
- Rectangular Port LS3/L76/L92/L99
- Product Attributes - Fuel Injection Style
- Multi-port
- Product Attributes - Basic Operating RPM Range
- 1,500-7,000
- Product Attributes - Intake Section Included
- Complete
- Product Attributes - Throttle Body Bore Size
- 90mm
- Product Attributes - Engine Block Deck Height
- Standard deck
- Product Attributes - Injectors Included
- No
- Product Attributes - Multi-Port Fuel Rails Included
- No
- Product Attributes - EGR
- No
- Product Attributes - Aftermarket Fuel Rail Required
- Yes
- Product Attributes - Throttle Body Included
- No
- Product Attributes - Supplemental Bosses Cast-In
- Yes
- Product Attributes - Supplemental Bosses Machined
- Yes
- Product Attributes - Supplemental Boss Quantity
- Eight
- Product Attributes - Runners Included
- Yes
- Product Attributes - Runners Removable
- No
- Product Attributes - Plenum Material
- Aluminum
- Product Attributes - Plenum Finish
- Black powdercoated
- Product Attributes - Base Material
- Aluminum
- Product Attributes - Base Color
- Black powdercoated
- Product Attributes - Remanufactured
- No
- Product Attributes - Quantity
- Sold individually.
- Product Attributes - Notes
- Designed for LS3 with OE or equivalent throttle body. Not intended as direct replacement for late-model vehicles due to hood and cowl clearance.
Reference Information
| Brand Name/s | Edelbrock |
|---|---|
| StreetFX SKU | ede7142 |
| SFX Item ID | 4237508 |
| Supplier Item Code | 4237508 |
| Manufacturer SKU | 7142 |
| Manufacturer UPC | 85347071425 |
| Alternative References | edl-7142, EDB7142, LS3 |
Brochures
Compatibility
Chevrolet:Small-Block Gen IV L76:364 (6.0L);Chevrolet:Small-Block Gen IV L77:364 (6.0L);Chevrolet:Small-Block Gen IV L92:376 (6.2L);Chevrolet:Small-Block Gen IV L94:376 (6.2L);Chevrolet:Small-Block Gen IV L99:376 (6.2L);Chevrolet:Small-Block Gen IV L9H:37
