Description

These unported versions of race-winning Edelbrock Victor Series CNC heads are designed specifically for the professional cylinder head porter and engine builder. Like all other Edelbrock Cylinder heads, Pro-Port cylinder heads are also cast in the USA at the state-of-the-art Edelbrock Foundry with extra-thick walls to allow for custom CNC porting. In most cases, seats and manganese-bronze valve guides are included, but not installed. Please note: These heads can not be used without professional head preparation.

Application Summary

Chevrolet:Big-Block Race

Part Type

Engine Cylinder Head

Data: v4.2 - Upd: 2026-10-14 10:58:34

Features

Extra Thick Walls To Allow For Custom CNC Porting

Specifications

Product Attributes - Brand: Edelbrock
Product Attributes - Manufacturer's Part Number: 614469
Product Attributes - Part Type: Cylinder Heads
Product Attributes - Product Line: Edelbrock Victor DR-23 Degree Pro Port Raw Cylinder Heads
Product Attributes - UPC: 085347997930
Product Attributes - Cylinder Head Style: Bare
Product Attributes - Cylinder Head Material: Cast aluminum
Product Attributes - Intake Valve Diameter (in.): 2.600 in.
Product Attributes - CNC-Machined Combustion Chamber: No
Product Attributes - CNC-Machined Intake Runner: No
Product Attributes - CNC-Machined Exhaust Runner: No
Product Attributes - Intake Port Location: Standard
Product Attributes - Exhaust Port Location: Raised
Product Attributes - Spark Plug Style: Angle
Product Attributes - Intake Valves Included: No
Product Attributes - Exhaust Valves Included: No
Product Attributes - Exhaust Valve Diameter (in.): 1.880 in.
Product Attributes - Valve Springs Included: No
Product Attributes - Damper Spring Included: No
Product Attributes - Retainers Included: No
Product Attributes - Locks Included: No
Product Attributes - Valve Stem Seals Included: No
Product Attributes - Rocker Arm Studs Included: No
Product Attributes - Rocker Arms Included: No
Product Attributes - Rocker Arm Nuts Included: No
Product Attributes - Guideplates Included: No
Product Attributes - Valve Cover Mounting Style: Perimeter bolt
Product Attributes - Accessory Bolt Holes Drilled: No
Product Attributes - Intake Valve Angle: 23
Product Attributes - Valve Guides Included: Yes
Product Attributes - Valve Guide Material: Bronze
Product Attributes - Valve Seats Machined: No
Product Attributes - Valve Seat Machine Style: Un-machined seat
Product Attributes - Valve Seat Material: Copper bronze alloy
Product Attributes - Cylinder Head Color: Natural
Product Attributes - Steam Holes Drilled: No
Product Attributes - Machined for O-Ring: No
Product Attributes - Heat Crossover: No
Product Attributes - Remanufactured: No
Product Attributes - Quantity: Sold individually.
Product Attributes - Notes: Utilizes the EDL-2896 and EDL-2897 intakes, with a rolled deck for a 23 degree valve angle. Includes valve guides, bolt tunes and rocker helicoils not installed. Requires use of EDL-4259 valve covers or custom sheet metal covers.
