Edelbrock Carburetor AVS2 Series 4-Barrel 650 CFM Off-Road Electric Choke Satin Finish (Non-EGR)
Edelbrock Carburetor AVS2 Series 4-Barrel 650 CFM Off-Road Electric Choke Satin Finish (Non-EGR)
A$1,203.28
IN STOCK! Est Ship 4-7 days.
This item is IN STOCK at one of our warehouses or distribution centres, the ETA is the approximate time required to prepare your order for dispatch.
We accept
Description
Edelbrock's AVS2 Off-Road Carburetor #1916 with Electric Choke is a special 650 CFM version of the proven #1906 street carb with Annular Flow Booster technology for near-EFI-like drivability that you can feel as soon as you step on the gas. Like AVS2 street carbs, the AVS2 Off-Road features an annular ring with eight evenly spaced orifices that replaces the standard single brass tube (down-leg) fuel feed. The AVS2 Off-Road booster ring distributes fuel into the airflow stream with an even spray that eliminates flat spots and greatly improves throttle response in the low-to mid-RPM range without sacrificing top-end power. For superior fuel control over rough terrain, the AVS2 Off-Road features a new spring-loaded needle and seat along with a spring-loaded anti-syphon ball in the accelerator pump circuit to prevent fuel drip common with standard carbs in off-road situations.The AVS2 Off-Road is unaffected by engine backfires since there are no power valves to blow out. For fast and simple part-throttle tuning, metering rods and springs can be changed in seconds without carburetor removal or fuel draining. AVS2 Off-Road carbs have the unique ability to hold a tune when compared to other carburetors. Your tuning and adjustments stay unchanged, so performance remains consistent. Updated primary and secondary booster clusters in the AVS2 Off-Road offer the most accurate and up-to-date calibration available for today's fuels and octane levels. Additionally, the unique Qwik-Tune Secondary Air Valve allows for limitless calibration of the secondary circuit. Adjustments can be with simple hand tools in seconds to suit your application.AVS2 Off-Road Carburetors feature a two-piece design for easy tuning that allows you to make float level adjustments or replace internal components without draining the carburetor or removing it from the engine. The AVS2 Off-Road 650 CFM is available with a manual (#1915) or electric (#1916) choke and are manufactured by Edelbrock in the USA
Product Overview
Edelbrock's AVS2 Off-Road Carburetor #1916 with Electric Choke is a special 650 CFM version of the proven #1906 street carb with Annular Flow Booster technology for near-EFI-like drivability that you can feel as soon as you step on the gas. Like AVS2 street carbs, the AVS2 Off-Road features an annular ring with eight evenly spaced orifices that replaces the standard single brass tube (down-leg) fuel feed. The AVS2 Off-Road booster ring distributes fuel into the airflow stream with an even spray that eliminates flat spots and greatly improves throttle response in the low-to mid-RPM range without sacrificing top-end power. For superior fuel control over rough terrain, the AVS2 Off-Road features a new spring-loaded needle and seat along with a spring-loaded anti-syphon ball in the accelerator pump circuit to prevent fuel drip common with standard carbs in off-road situations. The AVS2 Off-Road is unaffected by engine backfires since there are no power valves to blow out. For fast and simple part-throttle tuning, metering rods and springs can be changed in seconds without carburetor removal or fuel draining. AVS2 Off-Road carbs have the unique ability to hold a tune when compared to other carburetors. Your tuning and adjustments stay unchanged, so performance remains consistent. Updated primary and secondary booster clusters in the AVS2 Off-Road offer the most accurate and up-to-date calibration available for today's fuels and octane levels. Additionally, the unique Qwik-Tune Secondary Air Valve allows for limitless calibration of the secondary circuit. Adjustments can be with simple hand tools in seconds to suit your application. AVS2 Off-Road Carburetors feature a two-piece design for easy tuning that allows you to make float level adjustments or replace internal components without draining the carburetor or removing it from the engine. The AVS2 Off-Road 650 CFM is available with a manual (#1915) or electric (#1916) choke and are manufactured by Edelbrock in the USA
Features and Benefits
- AVS2 Series Carburetor
- Annular Flow Booster technology
- Spring-loaded needle and seat for rough terrain
- Spring-loaded anti-syphon ball eliminates drip
- No power valves to blow out
- Available with manual or electric choke
Product Details
| Barrel Quantity: | 4 Barrel |
|---|---|
| Barrel: | Four |
| Body Height: | 3.25 |
| Booster Type: | annular |
| Bore Diameter: | Primary Bore 1.44; Secondary Bore 1.75 |
| CFM: | 650 |
| Choke Type: | Electric |
| Choke: | Electric |
| Condition: | New |
| Description: | AVS2 Series Carburetor |
| EGR Port: | No |
| Emission: | OEM |
| Finish: | Satin |
| Flange Shape: | Square |
| Flange: | Square Bore |
| Gasket Or Seal Included: | Yes |
| Main Venturi Diameter: | 1.19 |
| Material: | Aluminum |
| Maximum Flow Rating: | 650 |
| Metering Rod Size: | .073 x .042 |
| Part Number: | ede1916 |
| Primary Jet Diameter: | 0.104 |
| Primary Power Valve: | N/A |
| RGL: | WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Secondary Jet Diameter: | 0.098 |
| Series: | AVS2 |
| Spring Force: | 5" Hg (Orange) |
| Throttle Bore: | 1.750 in. |
| Type: | OEM |
| Usage: | OEM |
| WARNING CA Proposition 65 Message: | WARNING: This product can expose you to Zinc; which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information; visit www.P65warnings.ca.gov. |
| WARNING CA Proposition 65: | Yes |
Part Type
Carburetor
Features
- Annular Flow Booster technology
- Available with manual or electric choke
- No power valves to blow out
- Spring-loaded anti-syphon ball eliminates drip
- Spring-loaded needle and seat for rough terrain
Specifications
- Product Attributes - Brand
- Edelbrock
- Product Attributes - Manufacturer's Part Number
- 1916
- Product Attributes - Part Type
- Carburetors
- Product Attributes - Product Line
- Edelbrock AVS2 Series Carburetors
- Product Attributes - UPC
- 085347019168
- Product Attributes - CFM
- 650
- Product Attributes - Fuel Category
- Gasoline
- Product Attributes - Remanufactured
- No
- Product Attributes - Number of Barrels
- 4
- Product Attributes - Carburetor Flange
- Square bore
- Product Attributes - Choke
- Electric
- Product Attributes - Secondary Type
- Mechanical
- Product Attributes - Fuel Inlet
- Dual
- Product Attributes - Primary Jet Size
- 104
- Product Attributes - Secondary Jet Size
- 98
- Product Attributes - Carburetor Color
- Satin
- Product Attributes - Ford Kickdown
- No
- Product Attributes - Booster Type
- Annular
- Product Attributes - Throttle Linkage Type
- Universal
- Product Attributes - Carburetor Height (in.)
- 3.250 in.
- Product Attributes - Quantity
- Sold individually.
- Product Attributes - Notes
- Metering rod size is .073 x .042. Orange step-up springs are installed.
- Product Attributes - Special Attention
- Features an spring loaded needle and seat for rough terrain.
Reference Information
| Brand Name/s | Edelbrock |
|---|---|
| StreetFX SKU | ede1916 |
| SFX Item ID | 4237611 |
| Supplier Item Code | 4237611 |
| Manufacturer SKU | 1916 |
| Manufacturer UPC | 85347019168 |
| Alternative References | avs2, EDB1916, EDL-1916, 4-Barrel |
