Home / Shop / Canton Racing Street/Strip Wet Sump Oil Pans 15-660 Pan, Street/Strip, Steel, 6 qt., Front Sump, Ford, Small Block, 351, Each

Canton Racing Street/Strip Wet Sump Oil Pans 15-660 Pan, Street/Strip, Steel, 6 qt., Front Sump, Ford, Small Block, 351, Each

SKU: CTR15-660

Oil Pans

Canton Racing Products

Canton Racing Street/Strip Wet Sump Oil Pans 15-660 Pan, Street/Strip, Steel, 6 qt., Front Sump, Ford, Small Block, 351, Each

SKU: CTR15-660

Oil Pans

LAST ONE! Est Ship 4-7 days. LAST ONE! This is the last unit at our distribution centre. Contact us if you need more. The ETA is the approximate time required to prepare your order for dispatch.

We accept

Description

Canton Racing street/strip wet sump oil pans come in configurations ranging from production replacement pans to increased-capacity deep and shallow pans with race-proven oil control systems. In addition, Canton Racing street/strip oil pans include magnetic drain plugs and, in most pan applications, an oil temperature fitting.

Part Type

Ford 351W Front Sump Oil Pan

Data: v4.2 - Upd: 2026-10-14 09:22:15

Specifications

Product Attributes - Brand: Canton Racing Products
Product Attributes - Manufacturer's Part Number: 15-660
Product Attributes - Part Type: Oil Pans
Product Attributes - Product Line: Canton Racing Street/Strip Wet Sump Oil Pans
Product Attributes - UPC: 887753713063
Product Attributes - Sump Style: Wet
Product Attributes - Oil Pan Style: Stock
Product Attributes - Sump Location: Front
Product Attributes - Dipstick Location: Passenger side
Product Attributes - Oil Pan Capacity: 6.00 quarts
Product Attributes - Stroker Clearanced: Yes
Product Attributes - Maximum Stroke with OE Rod: 4.000 in.
Product Attributes - Dipstick Provision: Yes
Product Attributes - Dipstick Included: No
Product Attributes - Oil Pan Depth (in.): 8.000
Product Attributes - Oil Pan Material: Steel
Product Attributes - Oil Pan Color: Silver
Product Attributes - Baffled: Yes
Product Attributes - Kicked Out: Yes
Product Attributes - Kickout Position: Driver and passenger side
Product Attributes - Windage Tray Included: No
Product Attributes - Pickup Included: No
Product Attributes - Oil Pump Included: No
Product Attributes - Oil Pump Driveshaft Included: No
Product Attributes - Crank Scraper Included: Yes
Product Attributes - Drain Plug Thread Size: 1/2 in.-20
Product Attributes - Gaskets Included: No
Product Attributes - Hardware Included: No
Product Attributes - Quantity: Sold individually.
Product Attributes - Notes: System capacity is 7 quarts, which is oil pan capacity plus filter. Pan mounted dipstick. Designed to fit most front sump production chassis except Mustang IIs, Mavericks, and Comets, which may fit with modification. May not fit 4WD models due to the oil pan kickout. Slosh baffle is welded to inside of pan and is not removable.

Reference Information

Brand Name/s	Canton Racing Products
StreetFX SKU	ctr15-660
SFX Item ID	5052055
Supplier Item Code	5052055
Manufacturer SKU	15-660
Manufacturer UPC	887753713063
Alternative References	CAN15-660

Compatibility

Application Data

Make	FORD
Model	COUNTRY SEDAN
Submodel	BASE
Beginning Year	1969
Ending Year	1974
Engine Type	V8
Engine Size	5.8L/351
Engine Family	Ford small block Windsor
Application Notes	System capacity is 7 quarts, which is oil pan capacity plus filter. Pan mounted dipstick. Designed to fit most front sump production chassis except Mustang IIs, Mavericks, and Comets, which may fit with modification. May not fit 4WD models due to the oil pan kickout. Slosh baffle is welded to inside of pan and is not removable.

Make	FORD
Model	COUNTRY SQUIRE
Submodel	BASE
Beginning Year	1969
Ending Year	1974
Engine Type	V8
Engine Size	5.8L/351
Engine Family	Ford small block Windsor
Application Notes	System capacity is 7 quarts, which is oil pan capacity plus filter. Pan mounted dipstick. Designed to fit most front sump production chassis except Mustang IIs, Mavericks, and Comets, which may fit with modification. May not fit 4WD models due to the oil pan kickout. Slosh baffle is welded to inside of pan and is not removable.

Make	FORD
Model	CUSTOM 500
Submodel	BASE
Beginning Year	1969
Ending Year	1977
Engine Type	V8
Engine Size	5.8L/351
Engine Family	Ford small block Windsor
Application Notes	System capacity is 7 quarts, which is oil pan capacity plus filter. Pan mounted dipstick. Designed to fit most front sump production chassis except Mustang IIs, Mavericks, and Comets, which may fit with modification. May not fit 4WD models due to the oil pan kickout. Slosh baffle is welded to inside of pan and is not removable.

Make	FORD
Model	CUSTOM
Submodel	BASE
Beginning Year	1969
Ending Year	1972
Engine Type	V8
Engine Size	5.8L/351
Engine Family	Ford small block Windsor
Application Notes	System capacity is 7 quarts, which is oil pan capacity plus filter. Pan mounted dipstick. Designed to fit most front sump production chassis except Mustang IIs, Mavericks, and Comets, which may fit with modification. May not fit 4WD models due to the oil pan kickout. Slosh baffle is welded to inside of pan and is not removable.

Make	FORD
Model	ELITE
Submodel	BASE
Beginning Year	1975
Ending Year	1976
Engine Type	V8
Engine Size	5.8L/351
Engine Family	Ford small block Windsor
Application Notes	System capacity is 7 quarts, which is oil pan capacity plus filter. Pan mounted dipstick. Designed to fit most front sump production chassis except Mustang IIs, Mavericks, and Comets, which may fit with modification. May not fit 4WD models due to the oil pan kickout. Slosh baffle is welded to inside of pan and is not removable.

Make	FORD
Model	FAIRLANE
Submodel	500
Beginning Year	1969
Ending Year	1970
Engine Type	V8
Engine Size	5.8L/351
Engine Family	Ford small block Windsor
Application Notes	System capacity is 7 quarts, which is oil pan capacity plus filter. Pan mounted dipstick. Designed to fit most front sump production chassis except Mustang IIs, Mavericks, and Comets, which may fit with modification. May not fit 4WD models due to the oil pan kickout. Slosh baffle is welded to inside of pan and is not removable.

Make	FORD
Model	FAIRLANE
Submodel	BASE
Beginning Year	1969
Ending Year	1969
Engine Type	V8
Engine Size	5.8L/351
Engine Family	Ford small block Windsor
Application Notes	System capacity is 7 quarts, which is oil pan capacity plus filter. Pan mounted dipstick. Designed to fit most front sump production chassis except Mustang IIs, Mavericks, and Comets, which may fit with modification. May not fit 4WD models due to the oil pan kickout. Slosh baffle is welded to inside of pan and is not removable.

Make	FORD
Model	FALCON
Submodel	BASE
Beginning Year	1970
Ending Year	1970
Engine Type	V8
Engine Size	5.8L/351
Engine Family	Ford small block Windsor
Application Notes	System capacity is 7 quarts, which is oil pan capacity plus filter. Pan mounted dipstick. Designed to fit most front sump production chassis except Mustang IIs, Mavericks, and Comets, which may fit with modification. May not fit 4WD models due to the oil pan kickout. Slosh baffle is welded to inside of pan and is not removable.

Make	FORD
Model	FALCON
Submodel	FUTURA
Beginning Year	1970
Ending Year	1970
Engine Type	V8
Engine Size	5.8L/351
Engine Family	Ford small block Windsor
Application Notes	System capacity is 7 quarts, which is oil pan capacity plus filter. Pan mounted dipstick. Designed to fit most front sump production chassis except Mustang IIs, Mavericks, and Comets, which may fit with modification. May not fit 4WD models due to the oil pan kickout. Slosh baffle is welded to inside of pan and is not removable.

Make	FORD
Model	GALAXIE 500
Submodel	BASE
Beginning Year	1969
Ending Year	1974
Engine Type	V8
Engine Size	5.8L/351
Engine Family	Ford small block Windsor
Application Notes	System capacity is 7 quarts, which is oil pan capacity plus filter. Pan mounted dipstick. Designed to fit most front sump production chassis except Mustang IIs, Mavericks, and Comets, which may fit with modification. May not fit 4WD models due to the oil pan kickout. Slosh baffle is welded to inside of pan and is not removable.

Make	FORD
Model	GALAXIE 500
Submodel	XL
Beginning Year	1969
Ending Year	1970
Engine Type	V8
Engine Size	5.8L/351
Engine Family	Ford small block Windsor
Application Notes	System capacity is 7 quarts, which is oil pan capacity plus filter. Pan mounted dipstick. Designed to fit most front sump production chassis except Mustang IIs, Mavericks, and Comets, which may fit with modification. May not fit 4WD models due to the oil pan kickout. Slosh baffle is welded to inside of pan and is not removable.

Make	FORD
Model	GRANADA
Submodel	BASE
Beginning Year	1975
Ending Year	1977
Engine Type	V8
Engine Size	5.8L/351
Engine Family	Ford small block Windsor
Application Notes	System capacity is 7 quarts, which is oil pan capacity plus filter. Pan mounted dipstick. Designed to fit most front sump production chassis except Mustang IIs, Mavericks, and Comets, which may fit with modification. May not fit 4WD models due to the oil pan kickout. Slosh baffle is welded to inside of pan and is not removable.

Make	FORD
Model	GRANADA
Submodel	GHIA
Beginning Year	1975
Ending Year	1977
Engine Type	V8
Engine Size	5.8L/351
Engine Family	Ford small block Windsor
Application Notes	System capacity is 7 quarts, which is oil pan capacity plus filter. Pan mounted dipstick. Designed to fit most front sump production chassis except Mustang IIs, Mavericks, and Comets, which may fit with modification. May not fit 4WD models due to the oil pan kickout. Slosh baffle is welded to inside of pan and is not removable.

Make	FORD
Model	GRAN TORINO
Submodel	BASE
Beginning Year	1972
Ending Year	1976
Engine Type	V8
Engine Size	5.8L/351
Engine Family	Ford small block Windsor
Application Notes	System capacity is 7 quarts, which is oil pan capacity plus filter. Pan mounted dipstick. Designed to fit most front sump production chassis except Mustang IIs, Mavericks, and Comets, which may fit with modification. May not fit 4WD models due to the oil pan kickout. Slosh baffle is welded to inside of pan and is not removable.

Make	FORD
Model	GRAN TORINO
Submodel	BROUGHAM
Beginning Year	1973
Ending Year	1976
Engine Type	V8
Engine Size	5.8L/351
Engine Family	Ford small block Windsor
Application Notes	System capacity is 7 quarts, which is oil pan capacity plus filter. Pan mounted dipstick. Designed to fit most front sump production chassis except Mustang IIs, Mavericks, and Comets, which may fit with modification. May not fit 4WD models due to the oil pan kickout. Slosh baffle is welded to inside of pan and is not removable.

Make	FORD
Model	GRAN TORINO
Submodel	ELITE
Beginning Year	1974
Ending Year	1975
Engine Type	V8
Engine Size	5.8L/351
Engine Family	Ford small block Windsor
Application Notes	System capacity is 7 quarts, which is oil pan capacity plus filter. Pan mounted dipstick. Designed to fit most front sump production chassis except Mustang IIs, Mavericks, and Comets, which may fit with modification. May not fit 4WD models due to the oil pan kickout. Slosh baffle is welded to inside of pan and is not removable.

Make	FORD
Model	GRAN TORINO
Submodel	SPORT
Beginning Year	1972
Ending Year	1975
Engine Type	V8
Engine Size	5.8L/351
Engine Family	Ford small block Windsor
Application Notes	System capacity is 7 quarts, which is oil pan capacity plus filter. Pan mounted dipstick. Designed to fit most front sump production chassis except Mustang IIs, Mavericks, and Comets, which may fit with modification. May not fit 4WD models due to the oil pan kickout. Slosh baffle is welded to inside of pan and is not removable.

Make	FORD
Model	GRAN TORINO
Submodel	SQUIRE
Beginning Year	1972
Ending Year	1976
Engine Type	V8
Engine Size	5.8L/351
Engine Family	Ford small block Windsor
Application Notes	System capacity is 7 quarts, which is oil pan capacity plus filter. Pan mounted dipstick. Designed to fit most front sump production chassis except Mustang IIs, Mavericks, and Comets, which may fit with modification. May not fit 4WD models due to the oil pan kickout. Slosh baffle is welded to inside of pan and is not removable.

Make	FORD
Model	LTD
Submodel	BASE
Beginning Year	1969
Ending Year	1982
Engine Type	V8
Engine Size	5.8L/351
Engine Family	Ford small block Windsor
Application Notes	System capacity is 7 quarts, which is oil pan capacity plus filter. Pan mounted dipstick. Designed to fit most front sump production chassis except Mustang IIs, Mavericks, and Comets, which may fit with modification. May not fit 4WD models due to the oil pan kickout. Slosh baffle is welded to inside of pan and is not removable.

Make	FORD
Model	LTD
Submodel	BROUGHAM
Beginning Year	1970
Ending Year	1976
Engine Type	V8
Engine Size	5.8L/351
Engine Family	Ford small block Windsor
Application Notes	System capacity is 7 quarts, which is oil pan capacity plus filter. Pan mounted dipstick. Designed to fit most front sump production chassis except Mustang IIs, Mavericks, and Comets, which may fit with modification. May not fit 4WD models due to the oil pan kickout. Slosh baffle is welded to inside of pan and is not removable.

Make	FORD
Model	LTD
Submodel	COUNTRY SQUIRE
Beginning Year	1979
Ending Year	1981
Engine Type	V8
Engine Size	5.8L/351
Engine Family	Ford small block Windsor
Application Notes	System capacity is 7 quarts, which is oil pan capacity plus filter. Pan mounted dipstick. Designed to fit most front sump production chassis except Mustang IIs, Mavericks, and Comets, which may fit with modification. May not fit 4WD models due to the oil pan kickout. Slosh baffle is welded to inside of pan and is not removable.

Make	FORD
Model	LTD
Submodel	CROWN VICTORIA
Beginning Year	1980
Ending Year	1982
Engine Type	V8
Engine Size	5.8L/351
Engine Family	Ford small block Windsor
Application Notes	System capacity is 7 quarts, which is oil pan capacity plus filter. Pan mounted dipstick. Designed to fit most front sump production chassis except Mustang IIs, Mavericks, and Comets, which may fit with modification. May not fit 4WD models due to the oil pan kickout. Slosh baffle is welded to inside of pan and is not removable.

Make	FORD
Model	LTD II
Submodel	BASE
Beginning Year	1977
Ending Year	1979
Engine Type	V8
Engine Size	5.8L/351
Engine Family	Ford small block Windsor
Application Notes	System capacity is 7 quarts, which is oil pan capacity plus filter. Pan mounted dipstick. Designed to fit most front sump production chassis except Mustang IIs, Mavericks, and Comets, which may fit with modification. May not fit 4WD models due to the oil pan kickout. Slosh baffle is welded to inside of pan and is not removable.

Make	FORD
Model	LTD II
Submodel	BROUGHAM
Beginning Year	1977
Ending Year	1978
Engine Type	V8
Engine Size	5.8L/351
Engine Family	Ford small block Windsor
Application Notes	System capacity is 7 quarts, which is oil pan capacity plus filter. Pan mounted dipstick. Designed to fit most front sump production chassis except Mustang IIs, Mavericks, and Comets, which may fit with modification. May not fit 4WD models due to the oil pan kickout. Slosh baffle is welded to inside of pan and is not removable.

Make	FORD
Model	LTD II
Submodel	LANDAU
Beginning Year	1979
Ending Year	1979
Engine Type	V8
Engine Size	5.8L/351
Engine Family	Ford small block Windsor
Application Notes	System capacity is 7 quarts, which is oil pan capacity plus filter. Pan mounted dipstick. Designed to fit most front sump production chassis except Mustang IIs, Mavericks, and Comets, which may fit with modification. May not fit 4WD models due to the oil pan kickout. Slosh baffle is welded to inside of pan and is not removable.

Loading compatibility information...
