Canton Racing Products

Canton Racing Road Race Series Wet Sump Oil Pans for 1982-1992 CAMARO, FIREBIRD - 15-244T Pan, Race, Steel, 5 qt., Rear Sump, Chevy, Small Block,1986 and Later, Each

SKU: CTR15-244T

Oil Pans
Canton Racing Road Race Series Wet Sump Oil Pans for 1982-1992 CAMARO, FIREBIRD - 15-244T Pan, Race, Steel, 5 qt., Rear Sump, Chevy, Small Block,1986 and Later, Each

Canton Racing Products

Canton Racing Road Race Series Wet Sump Oil Pans for 1982-1992 CAMARO, FIREBIRD - 15-244T Pan, Race, Steel, 5 qt., Rear Sump, Chevy, Small Block,1986 and Later, Each

SKU: CTR15-244T

Oil Pans
A$1,328.16
LAST ONE! Est Ship 4-7 days. LAST ONE! This is the last unit at our distribution centre. Contact us if you need more. The ETA is the approximate time required to prepare your order for dispatch.
View cart 0
We accept
American Express
Mastercard
Visa
PayPal Checkout
Direct Deposit
Afterpay
Apple Pay
Google Pay
Zip Pay

Description

IMPORTANT NOTICE: System capacity is 6 quarts, which is oil pan capacity plus filter. Includes a 20mm fitting for a low oil warning sender.

No starvation! Canton Racing road race oil pans feature their competition baffling system of trap door baffles and/or slosh baffles. These systems flow oil to the pickup compartment and then keep it from flowing or sloshing away from the pickup during turns, acceleration, and braking. Their wide, low-profile sumps deliver maximum oil capacity and ground clearance. Many pans also include provisions for an optional pan mounted dipstick and a magnetic drain plug. Feed your engine with Canton Racing road race oil pans.

Part Type

SBC R/R Oil Pan - 7qt. W/1pc. Rear Main

Data: v4.2 - Upd: 2026-10-14 09:21:50

Specifications

Product Attributes - Brand
Canton Racing Products
Product Attributes - Manufacturer's Part Number
15-244T
Product Attributes - Part Type
Oil Pans
Product Attributes - Product Line
Canton Racing Road Race Series Wet Sump Oil Pans
Product Attributes - UPC
887753712240
Product Attributes - Sump Style
Wet
Product Attributes - Oil Pan Style
Road Race
Product Attributes - Rear Main Seal Style
1-piece
Product Attributes - Sump Location
Rear
Product Attributes - Dipstick Location
Passenger side
Product Attributes - Oil Pan Capacity
5.00 quarts
Product Attributes - Stroker Clearanced
Yes
Product Attributes - Maximum Stroke with OE Rod
3.875 in.
Product Attributes - Dipstick Provision
Yes
Product Attributes - Dipstick Included
No
Product Attributes - Oil Pan Depth (in.)
7.500
Product Attributes - Oil Pan Material
Steel
Product Attributes - Oil Pan Color
Silver
Product Attributes - Baffled
Yes
Product Attributes - Kicked Out
Yes
Product Attributes - Kickout Position
Driver and passenger side
Product Attributes - Windage Tray Included
Yes
Product Attributes - Pickup Included
No
Product Attributes - Oil Pump Included
No
Product Attributes - Oil Pump Driveshaft Included
No
Product Attributes - Crank Scraper Included
Yes
Product Attributes - Drain Plug Thread Size
1/2 in.-20
Product Attributes - Gaskets Included
No
Product Attributes - Hardware Included
No
Product Attributes - Quantity
Sold individually.
Product Attributes - Notes
System capacity is 6 quarts, which is oil pan capacity plus filter. Includes a 20mm fitting for a low oil warning sender.
Product Attributes - Special Attention
Designed for 1986 and later blocks with 1-piece rear main seal.

Reference Information

Brand Name/s Canton Racing Products
StreetFX SKU ctr15-244T
SFX Item ID 5052418
Supplier Item Code 5052418
Manufacturer SKU 15-244T
Manufacturer UPC 887753712240
Alternative References CAN15-244T

Compatibility

Application Data
  • MakeCHEVROLET
    ModelCAMARO
    SubmodelBASE
    Beginning Year1988
    Ending Year1988
    Engine TypeV8
    Engine Size5.0L/305
    Engine FamilyChevy small block Gen I
    Application NotesDesigned for 1986 and later blocks with 1-piece rear main seal. System capacity is 6 quarts, which is oil pan capacity plus filter. Includes a 20mm fitting for a low oil warning sender.
  • MakeCHEVROLET
    ModelCAMARO
    SubmodelBERLINETTA
    Beginning Year1982
    Ending Year1986
    Engine TypeV8
    Engine Size5.0L/305
    Engine FamilyChevy small block Gen I
    Application NotesDesigned for 1986 and later blocks with 1-piece rear main seal. System capacity is 6 quarts, which is oil pan capacity plus filter. Includes a 20mm fitting for a low oil warning sender.
  • MakeCHEVROLET
    ModelCAMARO
    SubmodelIROC-Z
    Beginning Year1985
    Ending Year1990
    Engine TypeV8
    Engine Size5.0L/305
    Engine FamilyChevy small block Gen I
    Application NotesDesigned for 1986 and later blocks with 1-piece rear main seal. System capacity is 6 quarts, which is oil pan capacity plus filter. Includes a 20mm fitting for a low oil warning sender.
  • MakeCHEVROLET
    ModelCAMARO
    SubmodelIROC-Z
    Beginning Year1987
    Ending Year1990
    Engine TypeV8
    Engine Size5.7L/350
    Engine FamilyChevy small block Gen I
    Application NotesDesigned for 1986 and later blocks with 1-piece rear main seal. System capacity is 6 quarts, which is oil pan capacity plus filter. Includes a 20mm fitting for a low oil warning sender.
  • MakeCHEVROLET
    ModelCAMARO
    SubmodelLT
    Beginning Year1987
    Ending Year1987
    Engine TypeV8
    Engine Size5.0L/305
    Engine FamilyChevy small block Gen I
    Application NotesDesigned for 1986 and later blocks with 1-piece rear main seal. System capacity is 6 quarts, which is oil pan capacity plus filter. Includes a 20mm fitting for a low oil warning sender.
  • MakeCHEVROLET
    ModelCAMARO
    SubmodelRS
    Beginning Year1989
    Ending Year1992
    Engine TypeV8
    Engine Size5.0L/305
    Engine FamilyChevy small block Gen I
    Application NotesDesigned for 1986 and later blocks with 1-piece rear main seal. System capacity is 6 quarts, which is oil pan capacity plus filter. Includes a 20mm fitting for a low oil warning sender.
  • MakeCHEVROLET
    ModelCAMARO
    SubmodelRS HERITAGE EDITION
    Beginning Year1992
    Ending Year1992
    Engine TypeV8
    Engine Size5.0L/305
    Engine FamilyChevy small block Gen I
    Application NotesDesigned for 1986 and later blocks with 1-piece rear main seal. System capacity is 6 quarts, which is oil pan capacity plus filter. Includes a 20mm fitting for a low oil warning sender.
  • MakeCHEVROLET
    ModelCAMARO
    SubmodelSPORT
    Beginning Year1982
    Ending Year1987
    Engine TypeV8
    Engine Size5.0L/305
    Engine FamilyChevy small block Gen I
    Application NotesDesigned for 1986 and later blocks with 1-piece rear main seal. System capacity is 6 quarts, which is oil pan capacity plus filter. Includes a 20mm fitting for a low oil warning sender.
  • MakeCHEVROLET
    ModelCAMARO
    SubmodelZ28
    Beginning Year1982
    Ending Year1987
    Engine TypeV8
    Engine Size5.0L/305
    Engine FamilyChevy small block Gen I
    Application NotesDesigned for 1986 and later blocks with 1-piece rear main seal. System capacity is 6 quarts, which is oil pan capacity plus filter. Includes a 20mm fitting for a low oil warning sender.
  • MakeCHEVROLET
    ModelCAMARO
    SubmodelZ28
    Beginning Year1991
    Ending Year1992
    Engine TypeV8
    Engine Size5.0L/305
    Engine FamilyChevy small block Gen I
    Application NotesDesigned for 1986 and later blocks with 1-piece rear main seal. System capacity is 6 quarts, which is oil pan capacity plus filter. Includes a 20mm fitting for a low oil warning sender.
  • MakeCHEVROLET
    ModelCAMARO
    SubmodelZ28
    Beginning Year1991
    Ending Year1992
    Engine TypeV8
    Engine Size5.7L/350
    Engine FamilyChevy small block Gen I
    Application NotesDesigned for 1986 and later blocks with 1-piece rear main seal. System capacity is 6 quarts, which is oil pan capacity plus filter. Includes a 20mm fitting for a low oil warning sender.
  • MakeCHEVROLET
    ModelCAMARO
    SubmodelZ28 HERITAGE EDITION
    Beginning Year1992
    Ending Year1992
    Engine TypeV8
    Engine Size5.0L/305
    Engine FamilyChevy small block Gen I
    Application NotesDesigned for 1986 and later blocks with 1-piece rear main seal. System capacity is 6 quarts, which is oil pan capacity plus filter. Includes a 20mm fitting for a low oil warning sender.
  • MakeCHEVROLET
    ModelCAMARO
    SubmodelZ28 HERITAGE EDITION
    Beginning Year1992
    Ending Year1992
    Engine TypeV8
    Engine Size5.7L/350
    Engine FamilyChevy small block Gen I
    Application NotesDesigned for 1986 and later blocks with 1-piece rear main seal. System capacity is 6 quarts, which is oil pan capacity plus filter. Includes a 20mm fitting for a low oil warning sender.
  • MakeCHEVROLET
    ModelCAMARO
    SubmodelZ28 INDIANAPOLIS 500 PACE CAR
    Beginning Year1982
    Ending Year1982
    Engine TypeV8
    Engine Size5.0L/305
    Engine FamilyChevy small block Gen I
    Application NotesDesigned for 1986 and later blocks with 1-piece rear main seal. System capacity is 6 quarts, which is oil pan capacity plus filter. Includes a 20mm fitting for a low oil warning sender.
  • MakePONTIAC
    ModelFIREBIRD
    SubmodelBASE
    Beginning Year1982
    Ending Year1992
    Engine TypeV8
    Engine Size5.0L/305
    Engine FamilyChevy small block Gen I
    Application NotesDesigned for 1986 and later blocks with 1-piece rear main seal. System capacity is 6 quarts, which is oil pan capacity plus filter. Includes a 20mm fitting for a low oil warning sender.
  • MakePONTIAC
    ModelFIREBIRD
    SubmodelBASE
    Beginning Year1987
    Ending Year1988
    Engine TypeV8
    Engine Size5.7L/350
    Engine FamilyChevy small block Gen I
    Application NotesDesigned for 1986 and later blocks with 1-piece rear main seal. System capacity is 6 quarts, which is oil pan capacity plus filter. Includes a 20mm fitting for a low oil warning sender.
  • MakePONTIAC
    ModelFIREBIRD
    SubmodelFORMULA
    Beginning Year1989
    Ending Year1992
    Engine TypeV8
    Engine Size5.0L/305
    Engine FamilyChevy small block Gen I
    Application NotesDesigned for 1986 and later blocks with 1-piece rear main seal. System capacity is 6 quarts, which is oil pan capacity plus filter. Includes a 20mm fitting for a low oil warning sender.
  • MakePONTIAC
    ModelFIREBIRD
    SubmodelFORMULA
    Beginning Year1989
    Ending Year1992
    Engine TypeV8
    Engine Size5.7L/350
    Engine FamilyChevy small block Gen I
    Application NotesDesigned for 1986 and later blocks with 1-piece rear main seal. System capacity is 6 quarts, which is oil pan capacity plus filter. Includes a 20mm fitting for a low oil warning sender.
  • MakePONTIAC
    ModelFIREBIRD
    SubmodelS/E
    Beginning Year1982
    Ending Year1986
    Engine TypeV8
    Engine Size5.0L/305
    Engine FamilyChevy small block Gen I
    Application NotesDesigned for 1986 and later blocks with 1-piece rear main seal. System capacity is 6 quarts, which is oil pan capacity plus filter. Includes a 20mm fitting for a low oil warning sender.
  • MakePONTIAC
    ModelFIREBIRD
    SubmodelTRANS AM
    Beginning Year1982
    Ending Year1992
    Engine TypeV8
    Engine Size5.0L/305
    Engine FamilyChevy small block Gen I
    Application NotesDesigned for 1986 and later blocks with 1-piece rear main seal. System capacity is 6 quarts, which is oil pan capacity plus filter. Includes a 20mm fitting for a low oil warning sender.
  • MakePONTIAC
    ModelFIREBIRD
    SubmodelTRANS AM
    Beginning Year1987
    Ending Year1992
    Engine TypeV8
    Engine Size5.7L/350
    Engine FamilyChevy small block Gen I
    Application NotesDesigned for 1986 and later blocks with 1-piece rear main seal. System capacity is 6 quarts, which is oil pan capacity plus filter. Includes a 20mm fitting for a low oil warning sender.
  • MakePONTIAC
    ModelFIREBIRD
    SubmodelTRANS AM GTA
    Beginning Year1989
    Ending Year1992
    Engine TypeV8
    Engine Size5.0L/305
    Engine FamilyChevy small block Gen I
    Application NotesDesigned for 1986 and later blocks with 1-piece rear main seal. System capacity is 6 quarts, which is oil pan capacity plus filter. Includes a 20mm fitting for a low oil warning sender.
  • MakePONTIAC
    ModelFIREBIRD
    SubmodelTRANS AM GTA
    Beginning Year1989
    Ending Year1992
    Engine TypeV8
    Engine Size5.7L/350
    Engine FamilyChevy small block Gen I
    Application NotesDesigned for 1986 and later blocks with 1-piece rear main seal. System capacity is 6 quarts, which is oil pan capacity plus filter. Includes a 20mm fitting for a low oil warning sender.

Loading compatibility information...
