Canton Racing Products

Canton Racing Road Race Series Wet Sump Oil Pans for 1984-1991 CORVETTE - 15-240T Pan, Race, Steel, 6 qt., Rear Sump, Chevy, Small Block, Each

SKU: CTR15-240T

Oil Pans
Canton Racing Road Race Series Wet Sump Oil Pans for 1984-1991 CORVETTE - 15-240T Pan, Race, Steel, 6 qt., Rear Sump, Chevy, Small Block, Each

Canton Racing Products

Canton Racing Road Race Series Wet Sump Oil Pans for 1984-1991 CORVETTE - 15-240T Pan, Race, Steel, 6 qt., Rear Sump, Chevy, Small Block, Each

SKU: CTR15-240T

Oil Pans
A$1,331.67
LAST ONE! Est Ship 4-7 days. LAST ONE! This is the last unit at our distribution centre. Contact us if you need more. The ETA is the approximate time required to prepare your order for dispatch.
View cart 0
We accept
American Express
Mastercard
Visa
PayPal Checkout
Direct Deposit
Afterpay
Apple Pay
Google Pay
Zip Pay

Description

IMPORTANT NOTICE: Designed for 1984-1996 Corvette using 1986 and later blocks with 1-piece rear main seal. Includes a 20mm fitting for a low oil warning sender.System capacity is 7 quarts, which is oil pan capacity plus filter.

No starvation! Canton Racing road race oil pans feature their competition baffling system of trap door baffles and/or slosh baffles. These systems flow oil to the pickup compartment and then keep it from flowing or sloshing away from the pickup during turns, acceleration, and braking. Their wide, low-profile sumps deliver maximum oil capacity and ground clearance. Many pans also include provisions for an optional pan mounted dipstick and a magnetic drain plug. Feed your engine with Canton Racing road race oil pans.

Additional Information

RIGHT HAND SIDE DIPSTICK (PASSENGER SIDE).

Part Type

SBC Vette Road Race Oil Pan - 1pc. Rear Main

Data: v4.2 - Upd: 2026-10-14 09:21:28

Specifications

Product Attributes - Brand
Canton Racing Products
Product Attributes - Manufacturer's Part Number
15-240T
Product Attributes - Part Type
Oil Pans
Product Attributes - Product Line
Canton Racing Road Race Series Wet Sump Oil Pans
Product Attributes - UPC
887753712165
Product Attributes - Sump Style
Wet
Product Attributes - Oil Pan Style
Road Race
Product Attributes - Rear Main Seal Style
1-piece
Product Attributes - Sump Location
Rear
Product Attributes - Dipstick Location
Passenger side
Product Attributes - Oil Pan Capacity
6.00 quarts
Product Attributes - Stroker Clearanced
No
Product Attributes - Maximum Stroke with OE Rod
3.750 in.
Product Attributes - Dipstick Provision
Yes
Product Attributes - Dipstick Included
No
Product Attributes - Oil Pan Depth (in.)
7.000
Product Attributes - Oil Pan Material
Steel
Product Attributes - Oil Pan Color
Silver
Product Attributes - Baffled
Yes
Product Attributes - Kicked Out
Yes
Product Attributes - Kickout Position
Driver and passenger side
Product Attributes - Windage Tray Included
Yes
Product Attributes - Pickup Included
No
Product Attributes - Oil Pump Included
No
Product Attributes - Oil Pump Driveshaft Included
No
Product Attributes - Crank Scraper Included
Yes
Product Attributes - Drain Plug Thread Size
1/2 in.-20
Product Attributes - Gaskets Included
No
Product Attributes - Hardware Included
No
Product Attributes - Quantity
Sold individually.
Product Attributes - Notes
Designed for 1984-1996 Corvette using 1986 and later blocks with 1-piece rear main seal. Includes a 20mm fitting for a low oil warning sender.System capacity is 7 quarts, which is oil pan capacity plus filter.

Reference Information

Brand Name/s Canton Racing Products
StreetFX SKU ctr15-240T
SFX Item ID 5052821
Supplier Item Code 5052821
Manufacturer SKU 15-240T
Manufacturer UPC 887753712165
Alternative References CAN15-240T

Compatibility

Application Data
  • MakeCHEVROLET
    Beginning Year1986
    Ending Year2002
    Engine TypeV8
    Engine Size5.0L/305
    Engine FamilyChevy small block Gen I
    Application NotesDesigned for 1984-1996 Corvette using 1986 and later blocks with 1-piece rear main seal. Includes a 20mm fitting for a low oil warning sender.System capacity is 7 quarts, which is oil pan capacity plus filter.
  • MakeCHEVROLET
    Beginning Year1986
    Ending Year2002
    Engine TypeV8
    Engine Size5.7L/350
    Engine FamilyChevy small block Gen I
    Application NotesDesigned for 1984-1996 Corvette using 1986 and later blocks with 1-piece rear main seal. Includes a 20mm fitting for a low oil warning sender.System capacity is 7 quarts, which is oil pan capacity plus filter.
  • MakeCHEVROLET
    ModelCORVETTE
    Submodel35TH ANNIVERSARY EDITION
    Beginning Year1988
    Ending Year1988
    Engine TypeV8
    Engine Size5.7L/350
    Engine FamilyChevy small block Gen I
    Application NotesMust use 1986-2002 block. Designed for 1984-1996 Corvette using 1986 and later blocks with 1-piece rear main seal. Includes a 20mm fitting for a low oil warning sender.System capacity is 7 quarts, which is oil pan capacity plus filter.
  • MakeCHEVROLET
    ModelCORVETTE
    SubmodelBASE
    Beginning Year1984
    Ending Year1991
    Engine TypeV8
    Engine Size5.7L/350
    Engine FamilyChevy small block Gen I
    Application NotesMust use 1986-2002 block. Designed for 1984-1996 Corvette using 1986 and later blocks with 1-piece rear main seal. Includes a 20mm fitting for a low oil warning sender.System capacity is 7 quarts, which is oil pan capacity plus filter.
  • MakeCHEVROLET
    ModelCORVETTE
    SubmodelINDIANAPOLIS 500 PACE CAR
    Beginning Year1986
    Ending Year1986
    Engine TypeV8
    Engine Size5.7L/350
    Engine FamilyChevy small block Gen I
    Application NotesMust use 1986-2002 block. Designed for 1984-1996 Corvette using 1986 and later blocks with 1-piece rear main seal. Includes a 20mm fitting for a low oil warning sender.System capacity is 7 quarts, which is oil pan capacity plus filter.
  • MakeCHEVROLET
    ModelCORVETTE
    Submodel35TH ANNIVERSARY EDITION
    Beginning Year1988
    Ending Year1988
    Engine TypeV8
    Engine Size5.7L/350
    DrivetrainRWD
    Engine FamilyChevy small block Gen I
    Application NotesStreet/Strip/Road Race Oil Pan; 7 Qt.; 7 in. Deep/W-13.75 in./L-12 in. Sump; Incl. Crank Scraper/Magnetic Drain Plug; Chevy 86 And Newer Small Block w/1 pc. Seal;
    Engine VIN Code8
  • MakeCHEVROLET
    ModelCORVETTE
    SubmodelBASE
    Beginning Year1986
    Ending Year1989
    Engine TypeV8
    Engine Size5.7L/350
    DrivetrainRWD
    Engine FamilyChevy small block Gen I
    Application NotesStreet/Strip/Road Race Oil Pan; 7 Qt.; 7 in. Deep/W-13.75 in./L-12 in. Sump; Incl. Crank Scraper/Magnetic Drain Plug; Chevy 86 And Newer Small Block w/1 pc. Seal;
    Engine VIN Code8
  • MakeCHEVROLET
    ModelCORVETTE
    SubmodelINDIANAPOLIS 500 PACE CAR
    Beginning Year1986
    Ending Year1986
    Engine TypeV8
    Engine Size5.7L/350
    DrivetrainRWD
    Engine FamilyChevy small block Gen I
    Application NotesStreet/Strip/Road Race Oil Pan; 7 Qt.; 7 in. Deep/W-13.75 in./L-12 in. Sump; Incl. Crank Scraper/Magnetic Drain Plug; Chevy 86 And Newer Small Block w/1 pc. Seal;
    Engine VIN Code8
