COMP Cams Pushrods CS 8.000 5/16 W/.210
COMP Cams Pushrods CS 8.000 5/16 W/.210
A$499.93
Limited Availability from MFR
Limited stock available from the manufacturer's distribution centre. The dispatch timeframe shown is an estimate based on historical orders of this part. This item is not held in our own warehouse, and availability and release timing may vary depending on manufacturer stock movements and processing at the time of ordering.
We accept
Description
radiusCustom lengths available by special order
Product Overview
*Hi-Tech 210° Radius Pushrods*
* Designed for high-lift applications where pushrod and seat interference are problems at maximum lift
* Work well with rocker arms that feature cup type adjusters and applications that require more load bearing surface from the pushrod
* Same features as other Hi-Tech Pushrods with addition of 210° radius rather than 180° radius
* Custom lengths available by special order
Product Details
| Amazon ASIN: | B00062YF76 |
|---|---|
| Ball Radius: | 210 |
| C.A.R.B. E.O. Number: | N/A |
| C.A.R.B. Exempt for California Certified Vehicles Manufactured Before 1965?: | Yes, but must meet tailpipe emission standards for year of vehicle. |
| C.A.R.B. Exempt for Federally Certified Vehicles Manufactured Before 1967?: | Yes, but must meet tailpipe emission standards for year of vehicle. |
| C.A.R.B. Exempt for Foreign Vehicles Manufactured Before 1967?: | Yes, but must meet tailpipe emission standards for year of vehicle. |
| C.A.R.B. Exempt for On-Road Vehicles?: | Yes |
| C.A.R.B. Exempt for Racing and Off-Road Only Vehicles?: | Yes, but must be a race/competition only vehicle. |
| C.A.R.B. Exemption Reason: | No impact on pollution output of vehicle. |
| California Proposition 65: | WARNING: Cancer and Reproductive Harm P65Warnings.ca.gov |
| Description: | Hi-Tech 210 Radius 8.000" Long, .080" Wall, 5/16" Diameter Pushrod Set |
| Diameter (in.): | 0.3125 |
| Diameter: | 5/16 |
| Guide Plate Compatible: | Yes |
| Length: | 8 |
| Lifter End Style: | 5/16 Oil Through One-Piece Construction Ball |
| Overall Length (in.): | 8 |
| Part Number: | cca7761-16 |
| Pushrod Series: | Hi-Tech 210 Degree Radius |
| Rocker End Style: | 5/16 Oil Through One-Piece Construction Ball |
| Title: | Hi-Tech 210 Radius 8.000" Long, .080" Wall, 5/16" Diameter Pushrod Set |
| Wall Thickness: | 0.08 |
Part Type
Engine Push Rod Set
Specifications
- Product Attributes - Brand
- COMP Cams
- Product Attributes - Manufacturer's Part Number
- 7761-16
- Product Attributes - Part Type
- Pushrods, Valvetrain
- Product Attributes - Product Line
- COMP Cams Hi-Tech 210 Degree Pushrods
- Product Attributes - UPC
- 036584423058
- Product Attributes - Assembled
- Yes
- Product Attributes - Compatible with Guideplates
- Yes
- Product Attributes - Pushrod Tube Diameter
- 5/16 in.
- Product Attributes - Pushrod Material
- Chromoly
- Product Attributes - Top Tip Style
- Ball
- Product Attributes - Bottom Tip Style
- Ball
- Product Attributes - Intake Overall Length (in.)
- 8.000 in.
- Product Attributes - Exhaust Overall Length (in.)
- 8.000 in.
- Product Attributes - One-Piece Pushrod
- Yes
- Product Attributes - Oiling
- Yes
- Product Attributes - Tapered
- No
- Product Attributes - Tip Attachment
- Formed
- Product Attributes - Top Tip Diameter
- 5/16 in.
- Product Attributes - Bottom Tip Diameter
- 5/16 in.
- Product Attributes - Wall Thickness (in.)
- 0.080 in.
- Product Attributes - Heat-Treated
- Yes
- Product Attributes - Quantity
- Sold as a set of 16.
Reference Information
| Brand Name/s | Comp Cams |
|---|---|
| StreetFX SKU | cca7761-16 |
| SFX Item ID | 4121502 |
| Supplier Item Code | 4121502 |
| Manufacturer SKU | 7761-16 |
| Manufacturer UPC | 36584423058 |
| Alternative References | W/.210 |
