COMP Cams Race Sportsman 1.332in OD Conical Spring - 1.9in Installed Height - 1 Spring
COMP Cams Race Sportsman 1.332in OD Conical Spring - 1.9in Installed Height - 1 Spring
A$75.64
Available from MFR.
This item is available from the manufacturer's distribution centre. The dispatch timeframe shown is an estimate based on historical order processing and release times for this part. This item is not held in our own warehouse, and actual dispatch timing may vary depending on manufacturer workload and logistics at the time of ordering.
We accept
Description
Valve springs are one of the most critical and overlooked components in your engine. They must be matched to your cam in order for the engine to reach its full potential. It does absolutely no good to install a cam that will perform up to 8,000 rpm if you do not have the correct springs. Use the only valve springs that will give the recommended spring pressure with the valve both on the seat and at maximum lift. COMP Cams valve springs are offered in single and dual styles to meet your cam requirements.
Product Overview
Conical Valve Springs from COMP Cams have a unique cone shape. They were specifically designed for Small Block Chevrolets with up to .500†lift but require no machining to the spring pockets. Extensive quality assurance testing ensures your new Conical Valve Springs are free of any microscopic surface defects for optimum strength and durability. These Conical Valve Springs work with Titanium (part #730) and Steel Retainers (part #740, 743).
Product Details
| Amazon ASIN: | B00N6LQRUM |
|---|---|
| C.A.R.B. E.O. Number: | N/A |
| C.A.R.B. Exempt for California Certified Vehicles Manufactured Before 1965?: | Yes, but must meet tailpipe emission standards for year of vehicle. |
| C.A.R.B. Exempt for Federally Certified Vehicles Manufactured Before 1967?: | Yes, but must meet tailpipe emission standards for year of vehicle. |
| C.A.R.B. Exempt for Foreign Vehicles Manufactured Before 1967?: | Yes, but must meet tailpipe emission standards for year of vehicle. |
| C.A.R.B. Exempt for On-Road Vehicles?: | Yes |
| C.A.R.B. Exempt for Racing and Off-Road Only Vehicles?: | Yes, but must be a race/competition only vehicle. |
| C.A.R.B. Exemption Reason: | No impact on pollution output of vehicle. |
| California Proposition 65: | WARNING: Cancer and Reproductive Harm P65Warnings.ca.gov |
| Camshaft Type: | N/A |
| Coil Bind Height: | 1.175 |
| Compatible .570" Guide Diameter Spring Seat: | 4677-1 |
| Compatible Retainer: | 788-1 |
| Compatible Shims: | 4754 |
| Damper: | No |
| Description: | Race Sportsman 1.332" OD Conical Spring; 1.900" Installed Height; 1 Spring |
| Inside Diameter: | N/A |
| Installed Height (in.): | N/A |
| Installed Pressure (lbs.): | N/A |
| Number of Springs: | 1 |
| Open Height (in.): | N/A |
| Open Pressure (lbs.): | N/A |
| Outer Bottom Spring Inside Diameter: | 0.932 |
| Outer Bottom Spring Outside Diameter: | 1.332 |
| Outer Top Spring Inside Diameter: | 0.66 |
| Outer Top Spring Outside Diameter: | 1.06 |
| Part Number: | cca7230-1 |
| Position: | N/A |
| Seat Height: | 1.9 |
| Seat Pressure: | 145 |
| Spring Rate (lbs./in.): | 520 |
| Spring Rate: | 519 |
| Spring Type: | Single |
| Title: | Race Sportsman 1.332" OD Conical Spring; 1.900" Installed Height; 1 Spring |
| Valve Spring Series: | Race Sportsman |
Part Type
Engine Valve Spring
Specifications
- Product Attributes - Brand
- COMP Cams
- Product Attributes - Manufacturer's Part Number
- 7230-1
- Product Attributes - Part Type
- Valve Springs
- Product Attributes - Product Line
- COMP Cams Valve Springs
- Product Attributes - UPC
- 036584283171
- Product Attributes - Valve Spring Style
- Conical
- Product Attributes - Number of Springs Per Valve
- Single
- Product Attributes - Maximum Valve Lift (in.)
- 0.665 in.
- Product Attributes - Retainers Included
- No
- Product Attributes - Outside Diameter of Outer Spring (in.)
- 1.332 in.
- Product Attributes - Coil Bind Height (in.)
- 1.185 in.
- Product Attributes - Damper Spring Included
- No
- Product Attributes - Spring Rate (lbs./in.)
- 520 lbs./in.
- Product Attributes - Inside Diameter of Outer Spring (in.)
- 0.932 in.
- Product Attributes - Locks Included
- No
- Product Attributes - Valve Stem Seals Included
- No
- Product Attributes - Valve Springs Coated
- No
- Product Attributes - Remanufactured
- No
- Product Attributes - Quantity
- Sold individually.
- Product Attributes - Notes
- O.D. at top of spring is 1.060 in. and I.D. at top is 0.660 in.
Reference Information
| Brand Name/s | Comp Cams |
|---|---|
| StreetFX SKU | cca7230-1 |
| SFX Item ID | 4118131 |
| Supplier Item Code | 4118131 |
| Manufacturer SKU | 7230-1 |
| Manufacturer UPC | 36584283171 |
| Alternative References | 1.332in, 1.9in |
