BMR 78-87 G-Body Non-Adj. Upper A-Arms (Polyurethane) - Black Hammertone
BMR 78-87 G-Body Non-Adj. Upper A-Arms (Polyurethane) - Black Hammertone
A$852.33
Available from MFR.
This item is available from the manufacturer's distribution centre. The dispatch timeframe shown is an estimate based on historical order processing and release times for this part. This item is not held in our own warehouse, and actual dispatch timing may vary depending on manufacturer workload and logistics at the time of ordering.
We accept
Description
This means you get a great blend of performance and comfort. Designed for street performance, drag race, handling, and pro-touring applications, BMR upper A-arms are engineered to provide 2 additional degrees of positive caster for increased high-speed stability. These A-arms give you improved geometry and increased lateral grip during cornering situations. The upper arms also have revised cross shaft geometry, requiring less shim stack to achieve negative camber on lowered cars, or race and pro touring vehicles with aggressive alignments.BMR's suspension AA012 Non-Adjustable Upper A-arms are available in black hammertone and red powdercoat for long-lasting good looks. Installation time is 3-4 hours. Proudly made in the U.S.A.Control arm hardware kit RH007 (Includes upper and lower control arm hardware - Highly Recommended) also available.
Product Overview
A-arms are one of the most important, yet overlooked suspension components. They are the direct link between the front wheels and the chassis. Any deflection causes a change in alignment, which results in poor performance and driving feel. Fabricated from heavy-duty 1.25-inch, 0.095-inch wall DOM tubing with laser-cut, CNC-formed steel plate for extra strength, deflection is eliminated with A-arms from BMR Suspension. BMRs AA012 Upper A-arms are equipped with CNC machined, nickel-plated, dual-offset cross-shafts with heavy-duty stainless bushing retainers. They come pre-assembled with new polyurethane bump stops. New upper ball joints are included as well. Greasable, 95-durometer bushings add a solid, more responsive feel over the stock rubber bushings. BMRs bushings are internally fluted, which allows grease to evenly coat the inner sleeve. These flutes also direct grease to the outer edge of the bushing, keeping the thrust surface lubricated. This efficient lubrication ensures quiet, reliable operation over the life of the bushings.
Product Details
| Adjustable: | No |
|---|---|
| Ball Joint Included: | Yes |
| Bushing Material: | Polyurethane |
| Bushings Included: | Yes |
| Control Arm Finish: | Black Hammertone Powdercoated |
| Control Arm Material: | Steel |
| Control Arm Style: | Tubular |
| Description: | BMR 78-87 G-Body Non-Adj. Upper A-Arms (Polyurethane) - Black Hammertone |
| Hardware Included: | No |
| Part Number: | bmrAA012H |
| Quantity: | Sold as a pair |
Part Type
Suspension Control Arm
Specifications
- Product Attributes - UPC
- 887753320902
- Product Attributes - Brand
- BMR Suspension
- Product Attributes - Notes
- Provides an additional 2 degrees of caster.
- Product Attributes - Quantity
- Sold as a pair.
- Product Attributes - Part Type
- Control Arms
- Product Attributes - Adjustable
- No
- Product Attributes - Product Line
- BMR Suspension A-Arms
- Product Attributes - Bushing Material
- Polyurethane
- Product Attributes - Bushings Included
- Yes
- Product Attributes - Control Arm Color
- Black
- Product Attributes - Control Arm Style
- Tubular
- Product Attributes - Hardware Included
- No
- Product Attributes - Cross Pin Material
- Billet steel
- Product Attributes - Ball Joint Included
- Yes
- Product Attributes - Control Arm Material
- Steel
- Product Attributes - Manufacturer's Part Number
- AA012H
Reference Information
| Brand Name/s | Bmr Suspension |
|---|---|
| StreetFX SKU | bmrAA012H |
| SFX Item ID | 4008175 |
| Supplier Item Code | 4008175 |
| Manufacturer SKU | AA012H |
| Manufacturer UPC | 887753320902 |
