Description

Bilstein SMX Series shock absorbers are specifically designed for motorsports applications that mandate the use of stock mount (OE) suspension components. Designed using 46mm monotube technology, the shocks are available in a variety of damping options including dry kit designed specifically to provide the best options for a variety of race track types and conditions. Built in the USA with precision components and top quality controls, the SMX Series shocks deliver Bilstein’s famous fade-free performance and consistency in a factory-mount package that championship winning racers demand.

Application Summary

No Applications

Part Type

Suspension Shock Absorber

Data: v4.2 - Upd: 2026-10-14 10:57:38

Features

46mm piston design for maximum damping control
A wide range of valving choices available for endless tuning combinations
Precision Components And Top Quality Controls
Stock mount design for GM metric chassis applications

Specifications

Product Attributes - Brand: Bilstein
Product Attributes - Manufacturer's Part Number: 24-296793
Product Attributes - Part Type: Shocks and Struts
Product Attributes - Product Line: Bilstein SMX Series Shocks
Product Attributes - UPC: 651860847566
Product Attributes - Ride Height: Custom
Product Attributes - Ride Height Note: Additional ride height information may be available for your vehicle, please refer to the app tab.
Product Attributes - Extended Length (in.): 12.01
Product Attributes - Collapsed Length (in.): 8.27
Product Attributes - Internal Design: Monotube
Product Attributes - Adjustable Valving: No
Product Attributes - Gas Charged: Yes
Product Attributes - Upper Mount: Stud
Product Attributes - Lower Mount: Bar pin
Product Attributes - Bushing Material: Rubber
Product Attributes - Bushing Color: Black
Product Attributes - Boot Included: No
Product Attributes - Body Diameter (in.): 1.811
Product Attributes - Remanufactured: No
Product Attributes - Quantity: Sold individually.
Product Attributes - Notes: 83 compression and 286 rebound at 5 in. per second.

Reference Information

Brand Name/s	Bilstein
StreetFX SKU	bil24-296793
SFX Item ID	4811723
Supplier Item Code	4811723
Manufacturer SKU	24-296793
Manufacturer UPC	651860847566
Alternative References	BSN-24-296793
