Weld S71 20x11 / 5x4.5 BP / 8in BS Black Wheel (Low Pad) - Non-Beadlock
Weld S71 20x11 / 5x4.5 BP / 8in BS Black Wheel (Low Pad) - Non-Beadlock
A$3,009.74
Special Order. Contact for ETA.
This item is out of stock in our warehouse and partner distribution centres. In some cases, this may be due to not having live inventory feeds available for all suppliers. Please contact us before ordering if you need to meet a specific deadline.
We accept
Description
IMPORTANT NOTICE: Note in regards to wheels and tyres.Unless otherwise stated, wheels and tyres are supplied individually. They are not typically listed as a full set since most vehicles run different widths and offsets front to rear. Please carefully check your PCD, width and offset (ET) when choosing wheels or wheel and tyre packages. If you need more information or clarification, contact StreetFX customer support prior to ordering.(keyword: wheel)Images are supplied by the manufacturer and may be generic. While all efforts are made to provide accurate pictures, there may be differences in the actual product, such as colour, quantity, version, or included components. Please carefully review the description and specifications for details on inclusions or any variations. Some items may be sold individually or in sets, and images may occasionally depict additional products or quantities not included in your purchase. For assistance or clarification, please contact customer support.Reference Information Reference Data (Provide these details to our support team) Brand Name/s Weld, Weld Performance, Weld Racing StreetFX SKU wel71LB0110A80A SFX Item ID 4184919 Accounting SKU wel-71LB0110A80A Manufacturer SKU 71LB0110A80A Manufacturer UPC N/A Alternative References WLD-71LB0110A80A
Weld S71 20x11 / 5x4.5 BP / 8in BS Black Wheel (Low Pad) - Non-Beadlock
WELD Racing brings its application flexible racing technology to the street with a budget friendly 3-piece modular wheel using a unique welded assembly process. These wheels offer the classic WELD Racing look and continue the WELD tradition utilizing a forged billet center and cold forged rims. These unique wheels offers 3 mounting pad heights to clear just about any brake package making them the perfect choice for street, drag, road course or auto cross.
Additional Information
20X11'' Black S71 Low Pad 5X4.5'' Bolt Pattern 8'' Backspace; Valve Stem and Center Cap Included; Made in Kansas City, MO USA
Part Type
Wheel
Product Details
| Description: | Weld S71 20x11 / 5x4.5 BP / 8in BS Black Wheel (Low Pad) - Non-Beadlock |
| Part Number: | wel71LB0110A80A |
| Title: | WELD Street and Strip 20X11'' Black S71 Low Pad 5X4.5'' Bolt Pattern 8'' Backspace |
| Wheel Bolt Pattern Size: | 4.5 |
Product Overview
| Additional Application Notes | |
|---|---|
| • Position: Rear; 20" conical lugs required | |
These additional application notes are supplied by the manufacturer and collated from multiple year ranges. Not all of these notes may apply to every year or every variant. Please contact a StreetFX agent for clarification if required.
Data: v2 - Desc: v4.2 - Upd: 2026-10-13 17:40:48
Product Overview
WELD Racing brings its application flexible racing technology to the street with a budget friendly 3-piece modular wheel using a unique welded assembly process. These wheels offer the classic WELD Racing look and continue the WELD tradition utilizing a forged billet center and cold forged rims. These unique wheels offers 3 mounting pad heights to clear just about any brake package making them the perfect choice for street, drag, road course or auto cross.
Product Details
| Description: | Weld S71 20x11 / 5x4.5 BP / 8in BS Black Wheel (Low Pad) - Non-Beadlock |
|---|---|
| Part Number: | wel71LB0110A80A |
| Title: | WELD Street and Strip 20X11'' Black S71 Low Pad 5X4.5'' Bolt Pattern 8'' Backspace |
| Wheel Bolt Pattern Size: | 4.5 |
Part Type
Wheel
Specifications
Wheel, RT-S S71, Aluminum, Black, 20 in. x 11 in., 5 x 4.50 in. Bolt Circle, 8.000 in. Backspace, Each
Weld Racing RT-S S71 forged aluminum black anodized wheels feature 3-piece forgings that are assembled by welding, for application flexibility. They are manufactured using primary forging-grade aluminum alloys to create maximum strength and durability. Weld Racing RT-S forged wheels are available in 15 in. to 18 in. diameters and are tested with F.E.A. and in-house destructive testing to ensure safety.
| Product Attributes | |
|---|---|
| Brand | Weld Racing |
| Manufacturer's Part Number | 71LB0110A80A |
| Part Type | Wheels |
| Product Line | Weld Racing RT-S S71 Forged Aluminum Black Anodized Wheels |
| UPC | 190300232758 |
| Wheel Diameter | 20 in. |
| Wheel Width (in.) | 11.00 |
| Wheel Size | 20x11 |
| Wheel Bolt Pattern (application) | 5 x 114.3mm 5 x 4 1/2 in. |
| Wheel Material | Forged aluminum |
| Designed for Dually Truck | No |
| Manufacturers Wheel Series | Weld Racing RT-S S71 Series |
| Backspacing (in.) | 8.00 |
| Offset | +51.00mm |
| Wheel Construction | 3-piece |
| TPMS Sensor Compatible | Yes |
| Beadlock Type | None |
| Lug Nut/Bolt Seat Style | Conical seat - 60 degree |
| Hub Centric Ring Compatible | No |
| Center Bore Diameter (in.) | 3.18 |
| Center Bore Diameter (mm) | 80.77 |
| Center Cap Included | Yes |
| Load Rating (lbs.) | 1,580 lbs. |
| Lug Nuts Included | No |
| Small Diameter Lug Nuts Required | No |
| Valve Stems Included | Yes |
| Valve Stem Material | Rubber |
| Valve Stem Finish | Chrome sleeve |
| Quantity | Sold individually. |
| Notes | Low brake clearance design. .89 in. from the peak of the spoke curvature for brake clearance. Will not accept 5/8 in. drive studs. |
Product Details
| Description: | Weld S71 20x11 / 5x4.5 BP / 8in BS Black Wheel (Low Pad) - Non-Beadlock |
|---|---|
| Part Number: | wel71LB0110A80A |
| Title: | WELD Street and Strip 20X11'' Black S71 Low Pad 5X4.5'' Bolt Pattern 8'' Backspace |
| Wheel Bolt Pattern Size: | 4.5 |
Reference Information
| Brand Name/s | Weld |
|---|---|
| StreetFX SKU | wel71LB0110A80A |
| SFX Item ID | 4184919 |
| Supplier Item Code | 4184919 |
| Manufacturer SKU | 71LB0110A80A |
| Manufacturer UPC | N/A |
| Alternative References | s71, WLD-71LB0110A80A, 20x11, 5x4.5, 8in |
Compatibility
| Weld S71 20x11 / 5x4.5 BP / 8in BS Black Wheel (Low Pad) - Non-Beadlock | ||||
|---|---|---|---|---|
| Year Range | Make | Model | Submodels | Region |
| 2015-2017 | Ford | Mustang | GT, V6, EcoBoost, GT Premium, GT 50 Years Limited Edition, EcoBoost Premium, Shelby GT350, Shelby GT350R | US |
Please note that this information serves as a fitment guide only. For specific fitment questions or clarifications, please contact us, as manufacturers may introduce variations and modifications during model year or regional revisions. While we strive to provide accurate data, fitment details may vary by region; therefore, compatibility outside the listed region and submodel variant cannot be guaranteed.
Detailed Compatibility
| Application Data | |
|---|---|
| Wheel Bolt Pattern (application) | 5 x 114.3mm |
| Wheel Bolt Pattern (application) | 5 x 4 1/2 in. |
| Make | ASTON MARTIN |
| Model | DB9 |
| Submodel | BASE |
| Beginning Year | 2013 |
| Ending Year | 2016 |
| Position | R |
This may not be an exhaustive list of compatible vehicles. Please reach out to one of our representatives if you are unsure or do not see your vehicle here.
