Weld Draglite 15x4 / 5x4.5 & 5x4.75 BP / 2.5in. BS Polished Wheel - Non-Beadlock

SKU: WEL90-54344

Wheels

WEL Draglite Wheels...

Weld

Weld Draglite 15x4 / 5x4.5 & 5x4.75 BP / 2.5in. BS Polished Wheel - Non-Beadlock

SKU: WEL90-54344

Wheels

WEL Draglite Wheels...

LAST ONE! Est Ship 3-5 days. LAST ONE! This is the last unit at our distribution centre. Contact us if you need more. The ETA is the approximate time required to prepare your order for dispatch.

We accept

Description

IMPORTANT NOTICE: Note in regards to wheels and tyres.Unless otherwise stated, wheels and tyres are supplied individually. They are not typically listed as a full set since most vehicles run different widths and offsets front to rear. Please carefully check your PCD, width and offset (ET) when choosing wheels or wheel and tyre packages. If you need more information or clarification, contact StreetFX customer support prior to ordering.(keyword: wheel)Images are supplied by the manufacturer and may be generic. While all efforts are made to provide accurate pictures, there may be differences in the actual product, such as colour, quantity, version, or included components. Please carefully review the description and specifications for details on inclusions or any variations. Some items may be sold individually or in sets, and images may occasionally depict additional products or quantities not included in your purchase. For assistance or clarification, please contact customer support.Reference Information Reference Data (Provide these details to our support team) Brand Name/s Weld, Weld Performance, Weld Racing StreetFX SKU wel90-54344 SFX Item ID 4181181 Accounting SKU wel-90-54344 Manufacturer SKU 90-54344 Manufacturer UPC 190300472567 Alternative References WLD-90-54344

Weld Draglite 15x4 / 5x4.5 & 5x4.75 BP / 2.5in. BS Polished Wheel - Non-Beadlock

If there is a classic design for street and strip cars, it would be the WELD Sport Forged wheels. These designs are perhaps the most well known and established in the WELD family. They have a timeless look that has no shortage of style. 2-pc wheel design uses a revolutionary cold forged and welded construction for a lighter and stronger wheel. The best strength to weight ratio and lowest rotational moment of inertia of all mid-priced wheels.

Additional Information

15X4'' Polished Draglite 5X4.5/4.75'' Bolt Pattern 2.5'' Backspace; Valve Stem and Center Cap Included; Made in Kansas City, MO USA

Part Type

Wheel

Product Details

Backspacing:	2.5
Center Cap Included:	Yes
Color:	Polished
Description:	Weld Draglite 15x4 / 5x4.5 & 5x4.75 BP / 2.5in. BS Polished Wheel - Non-Beadlock
Diameter:	15
Finish:	Polished
Inside Diameter:	3.18
Lug Hole Quantity:	5
Material:	Forged Aluminum
Part Number:	wel90-54344
TPMS Compatible:	Yes
Title:	WELD Street and Strip 15X4'' Polished Draglite 5X4.5/4.75'' Bolt Pattern 2.5'' Backspace
Wheel Bolt Pattern Size:	4.5/4.75
Width:	4

Product Overview

Additional Application Notes
• Position: Front; 15" - 1/2" -RH20 Studs
• Position: Front; 15" - 1/2" RH20 Studs
• Position: Front; 15" = 7/16" - RH20 studs
• Position: Front; 15" - 7/16" - RH20 studs
• Position: Front; 15" - 1/16" - RH20 studs
• Position: Front; 15" - 12 MM x 1.5 studs
• Position: Front; 15" 7/16" - RH20 studs
• Position: Front; 12 MM x 1.5 studs
• Position: Front; 15" - 7/16" -RH20 studs
• Position: Front; 15" - 12MM x 1.5 studs
• Position: Front; 15" - 1/2" - RH20 and 1/2" LH20 studs
• Position: Front; 15" - 1/2" RH20 studs
• Position: Front; 15" - 1/2" - RH20 and 1/2" - LH20 studs
• Position: Front; 15" - 1/2" - RH20 studs
• Position: Front; 15" - RWD - 12MM x 1.5 studs
• Position: Front; 15" - 12 MM x 1.5studs
• Position: Front; 15" - 7/16" - RH 20 studs

These additional application notes are supplied by the manufacturer and collated from multiple year ranges. Not all of these notes may apply to every year or every variant. Please contact a StreetFX agent for clarification if required.

Data: v2 - Desc: v4.2 - Upd: 2026-10-13 17:37:15

Product Overview

Product Details

Backspacing:	2.5
Center Cap Included:	Yes
Color:	Polished
Description:	Weld Draglite 15x4 / 5x4.5 & 5x4.75 BP / 2.5in. BS Polished Wheel - Non-Beadlock
Diameter:	15
Finish:	Polished
Inside Diameter:	3.18
Lug Hole Quantity:	5
Material:	Forged Aluminum
Part Number:	wel90-54344
TPMS Compatible:	Yes
Title:	WELD Street and Strip 15X4'' Polished Draglite 5X4.5/4.75'' Bolt Pattern 2.5'' Backspace
Wheel Bolt Pattern Size:	4.5/4.75
Width:	4

Part Type

Wheel

Data: v4.2 - Upd: 2026-10-10 18:33:01

Specifications

Wheel, Draglite, Aluminum, Polished, 15 in. x 4 in., 5 x 4.50/4.75 in. Bolt Circle, 2.50 in. Backspace, Each

Weld Racing's Draglite polished wheels are made from cold-forged aluminum, so you know that they're strong and lightweight--up to 40 percent lighter than other comparable race wheels. They can take the abuse of street driving, while reducing your car's unsprung weight, helping to lower ETs and improve your car's handling. The Draglite wheels include a center cap.

Product Attributes
Brand	Weld Racing
Manufacturer's Part Number	90-54344
Part Type	Wheels
Product Line	Weld Racing Draglite Polished Wheels
UPC	190300472567
Wheel Diameter	15 in.
Wheel Width (in.)	4.00
Wheel Size	15x4
Wheel Bolt Pattern (application)	5 x 114.3mm 5 x 120.65mm 5 x 4 1/2 in. 5 x 4 3/4 in.
Wheel Material	Forged aluminum
Wheel Face Color	Polished
Wheel Face Finish	Polished
Wheel Barrel/Lip Color	Polished
Wheel Barrel/Lip Finish	Polished
Manufacturers Wheel Series	Weld Racing Draglite Series
Backspacing (in.)	2.50
Offset	0.00mm
Wheel Construction	2-piece
TPMS Sensor Compatible	Yes
Beadlock Type	None
Lug Nut/Bolt Seat Style	Shank
Lug Nut Shank Length (in.)	1.38
Lug Nut Shank Diameter (in.)	0.69
Washer Outside Diameter (in.)	1.25 in.
Hub Centric Ring Compatible	No
Center Bore Diameter (in.)	3.18
Center Bore Diameter (mm)	80.77
Center Cap Included	Yes
Load Rating (lbs.)	1,200 lbs.
Lug Nuts Included	No
Small Diameter Lug Nuts Required	No
Valve Stems Included	Yes
Valve Stem Material	Rubber
Valve Stem Finish	Chrome sleeve
Quantity	Sold individually.
Special Attention	Due to the construction of the inner wheel barrel, some aftermarket brake kits may require modification for fitment and clearance.
Designed for Dually Truck	No

Product Details

Backspacing:	2.5
Center Cap Included:	Yes
Color:	Polished
Description:	Weld Draglite 15x4 / 5x4.5 & 5x4.75 BP / 2.5in. BS Polished Wheel - Non-Beadlock
Diameter:	15
Finish:	Polished
Inside Diameter:	3.18
Lug Hole Quantity:	5
Material:	Forged Aluminum
Part Number:	wel90-54344
TPMS Compatible:	Yes
Title:	WELD Street and Strip 15X4'' Polished Draglite 5X4.5/4.75'' Bolt Pattern 2.5'' Backspace
Wheel Bolt Pattern Size:	4.5/4.75
Width:	4

Reference Information

Brand Name/s	Weld
StreetFX SKU	wel90-54344
SFX Item ID	4181181
Supplier Item Code	4181181
Manufacturer SKU	90-54344
Manufacturer UPC	190300472567
Alternative References	wld-90-54344, 15x4, 5x4.5, 5x4.75, 2.5in.

Compatibility

Weld Draglite 15x4 / 5x4.5 & 5x4.75 BP / 2.5in. BS Polished Wheel - Non-Beadlock
Year Range	Make	Model	Submodels	Region
1968-1970	American Motors	AMX	Base	US
1968-1974	American Motors	Javelin	Base, SST, SST Mark Donohue, SST Trans Am, AMX	US
1973-1975	Buick	Apollo	Base, SR	US
1970-1972	Buick	GS	Base	US
1973-1988	Buick	Regal	Base, T-Type, Grand National, Custom, Limited	US
1964-1972	Buick	Skylark	Base, Custom, 350	US
1976-1979	Buick	Skylark	Base, S, SR, Sport, Custom	US
1958-1970	Chevrolet	Bel Air	Base	US
1958-1970	Chevrolet	Biscayne	Base, Fleetmaster	US
1967-1992	Chevrolet	Camaro	Base, RS, SS, Z28, LT, Rally Sport, LT Rally Sport, Berlinetta, Sport, Z28 Indianapolis 500 Pace Car, Iroc-Z, RS Heritage Edition, Z28 Heritage Edition	US
1966-1970	Chevrolet	Caprice	Base	US
1964-1966	Chevrolet	Chevelle	300, Malibu, Malibu Super Sport, 300 Deluxe, Super Sport 396	US
1967	Chevrolet	Chevelle	Malibu	CA
1967	Chevrolet	Chevelle	Malibu, Concours, SS 396	US
1967	Chevrolet	Chevelle	300 Deluxe	CA
1967-1974	Chevrolet	Chevelle	300, 300 Deluxe, Concours, Malibu, Nomad, SS 396, Nomad Custom, Concours Estate, Greenbrier, Base, SS, Deluxe, Malibu Estate, Malibu Classic, Malibu Classic Estate	US
1962-1968	Chevrolet	Chevy II	Base, Nova, Nova SS	US
1959-1960	Chevrolet	El Camino	Base	US
1964-1974	Chevrolet	El Camino	Base, Custom, SS	US
1978-1987	Chevrolet	El Camino	Base, Conquista, SS, Royal Knight	US
1958-1970	Chevrolet	Impala	Base, SS	US
1978-1983	Chevrolet	Malibu	Base, Classic, Classic Estate, Classic Landau, Estate, Landau, Police, Sport, Classic Sport	US
1970-1977	Chevrolet	Monte Carlo	Base, Landau, S	US
1969-1979	Chevrolet	Nova	Base	US
1965-1971	Chrysler	300	Base	US
1965-1972	Chrysler	New Yorker	Base, Brougham	US
1965-1972	Chrysler	Newport	Base, Custom, Royal	US
1965-1972	Chrysler	Town & Country	Base	US
1970-1974	Dodge	Challenger	Base, R/T, T/A, Rallye	US
1966-1971	Dodge	Charger	Base, R/T, 500, SE, Daytona, Super Bee	US
1968-1974	Dodge	Coronet	440, 500, Super Bee, Base, Brougham, Crestwood, Custom	US
1965-1972	Dodge	Monaco	Base, 500	US
1965-1972	Dodge	Polara	Base, 500, Custom, Special, Brougham	US
1966-1970	Ford	Fairlane	Base, 500, 500XL	US
1974-1975	Ford	Gran Torino	Elite	US
1965-1973	Ford	Mustang	Base, Shelby GT-350, Shelby GT-350H, Shelby GT-500, Shelby GT-500KR, Boss 429, Boss 302, Grande, Mach 1, Boss 351	US
1966-1979	Ford	Ranchero	Base, Custom, 500, 500 XL, GT, Squire	US
1968-1976	Ford	Torino	GT, Cobra, Base	US
1966-1967	Mercury	Comet	Base	US
1967-1973	Mercury	Cougar	Base, XR-7, Boss 302, Cobra Jet, Boss 429	US
1966-1971	Mercury	Cyclone	Base, CJ, Spoiler, GT	US
1968-1976	Mercury	Montego	Base, MX, MX Brougham, Villager, GT, Brougham, MX Villager	US
1964-1971	Oldsmobile	442	Base	US
1964-1972	Oldsmobile	Cutlass	Base, Holiday, Turnpike Cruiser, S, Cruiser	US
1976-1977	Oldsmobile	Cutlass	Colonnade S, S, Vista Cruiser, 442	US
1978-1988	Oldsmobile	Cutlass Supreme	Base, Brougham, LS, 442, Indy 500 Pace Car, Classic, Classic Brougham, International, SL	US
1973-1979	Oldsmobile	Omega	Base, Salon, SX, Brougham, F85, Deluxe, Brougham LS	US
1966-1974	Plymouth	Barracuda	Base, Gran Coupe	US
1965-1972	Plymouth	Fury	Base, Sport, VIP, Custom Suburban, Sport Suburban, Suburban, GT, Gran Coupe, S-23, Sport GT, Custom, Gran Sedan	US
1967-1971	Plymouth	GTX	Base	US
Note: Displaying first 50 entries.

Please note that this information serves as a fitment guide only. For specific fitment questions or clarifications, please contact us, as manufacturers may introduce variations and modifications during model year or regional revisions. While we strive to provide accurate data, fitment details may vary by region; therefore, compatibility outside the listed region and submodel variant cannot be guaranteed.

Detailed Compatibility

Application Data
Wheel Bolt Pattern (application)	5 x 114.3mm

Wheel Bolt Pattern (application)	5 x 120.65mm

Wheel Bolt Pattern (application)	5 x 4 1/2 in.

Wheel Bolt Pattern (application)	5 x 4 3/4 in.

This may not be an exhaustive list of compatible vehicles. Please reach out to one of our representatives if you are unsure or do not see your vehicle here.
