Ridetech 67-69 Camaro Front TQ Coilovers
Ridetech 67-69 Camaro Front TQ Coilovers
A$3,800.25
Special Order. Contact for ETA.
This item is out of stock in our warehouse and partner distribution centres. In some cases, this may be due to not having live inventory feeds available for all suppliers. Please contact us before ordering if you need to meet a specific deadline.
We accept
Description
RideTech TQ coilover kits include everything you need to upgrade your existing suspension for track-quality handling and bolt-on installation. These track quality (TQ) systems provide single rebound and dual compression adjustments for precise tuning capability at all four corners. The high-speed adjustments handle high-speed excursions of the piston rod (abrupt directional transitions, pot holes, etc.). The low-speed adjustment handles ride-quality tuning and general cornering characteristics. RideTech TQ coilover kits are the ultimate choice for autocross, track days, drag racing, and ultra-high performance use.
Some of the many features, items and specs (unless otherwise noted):
* Hyperco coil springs
* All the benefits of a monotube design
* Built-in camber/caster adjustment
* Extruded clamp mount
* Integrated thrust bearing
* Billet upper mounting bracket
Product Overview
Front TQ Coil-Overs 1967-1981 GM F-Body. For use with Ridetech Subframe. Includes a pair of triple adjustable shocks, springs, spring mounts and delrin spring washers.
Product Details
| Description: | Ridetech 67-69 Camaro Front TQ Coilovers |
|---|---|
| Part Number: | rid11163516 |
| Pricing Group: | TQ Coil-Overs |
| Prop 65 Chemicals: | chromium,nickel,nickel_acetate,nickel_compounds,toluene |
| Proposition 65 Warning: | Y |
Application Summary
1967-1981 Camaro & Firebird
Part Type
Coilover Spring and Shock Assembly
Specifications
- Product Attributes - Brand
- RideTech
- Product Attributes - Manufacturer's Part Number
- 11163516
- Product Attributes - Part Type
- Coilover Kits
- Product Attributes - Product Line
- RideTech TQ Coilover Kits
- Product Attributes - UPC
- 840123518385
- Product Attributes - Coilover Kit Position
- Front
- Product Attributes - Adjustable Valving
- Yes
- Product Attributes - Number of Valving Selections
- 72
- Product Attributes - Shocks Included
- Yes
- Product Attributes - Internal Design
- Monotube
- Product Attributes - Coilover Springs Included
- Yes
- Product Attributes - Spring Rate (lbs./in.)
- 750 lbs./in.
- Product Attributes - Suspension Height Adjustment
- 1.0-3.0 in. lowered
- Product Attributes - Gas Charged
- Yes
- Product Attributes - Extended Length (in.)
- 13.03
- Product Attributes - Collapsed Length (in.)
- 9.43
- Product Attributes - Threaded Adjustment Range
- 3.500 in.
- Product Attributes - Upper Mount
- Eyelet
- Product Attributes - Lower Mount
- Eyelet
- Product Attributes - Body Diameter (in.)
- 2.000
- Product Attributes - Shock Body Material
- Aluminum
- Product Attributes - Shock Body Finish
- Silver
- Product Attributes - Bushing Material
- Spherical bearing/PTFE
- Product Attributes - Spring Finish
- Blue
- Product Attributes - Crossmember Included
- No
- Product Attributes - Adjustable Mounting Bracket Included
- No
- Product Attributes - Hardware Included
- Yes
- Product Attributes - Welding Required
- No
- Product Attributes - Quantity
- Sold as a kit.
- Product Attributes - Notes
- Designed for use with RideTech subframe.
Reference Information
| Brand Name/s | Ridetech |
|---|---|
| StreetFX SKU | rid11163516 |
| SFX Item ID | 4135660 |
| Supplier Item Code | 4135660 |
| Manufacturer SKU | 11163516 |
| Manufacturer UPC | 840123518385 |
| Alternative References | ART-11163516 |
Compatibility
1967-1981 Camaro & Firebird
