Superwinch Winches 1155401 10,000 lbs., 12VDC, 3/8 in x 54 ft. Synthetic rope with soft shackle, ergo handheld remote control, wireless remote, 1.9HP Permanent Magnet Motor with
Superwinch Winches 1155401 10,000 lbs., 12VDC, 3/8 in x 54 ft. Synthetic rope with soft shackle, ergo handheld remote control, wireless remote, 1.9HP Permanent Magnet Motor with
Description
Meet the Scorpion 10SR - Engineered for those who demand uncompromising strength and reliability when the job gets tough. This powerhouse winch packs a full 10,000 lbs. of pulling capacity into a lightweight, compact design that fits where traditional winches can't, reducing stress on your vehicle without sacrificing performance. Equipped with a high-torque permanent magnet motor and instant dynamic braking, the Scorpion 10,000 features a versatile, clockable 4-stage planetary gearbox with dual-range gearing to delivering unstoppable pulling power. Safety comes standard with a full load-holding brake, integrated overload shut-off, and a 3/8" synthetic rope with soft shackle to eliminate metal-to-metal hazards. A patented drum light ensures superior visibility in low-light recoveries, while low-amp efficiency maximizes performance from a single 12V battery. Designed with convenience in mind, it also includes an ergonomic free-spool clutch and both wired and wireless remotes for ultimate control. When the terrain gets demanding, the Scorpion 10,000 is built to strike-delivering unmatched capability and confidence every time.
Part Type
Winches
Features
- 3/8 in. x 54 ft. Synthetic Rope with Integrated Soft Shackle - Eliminates all metal in the winch line for maximum safety.
- 3/8 in. x 54 ft. Synthetic Rope With Integrated Soft Shackle Eliminates All Metal In The Winch Line For Maximum Safety
- 4-Stage Planetary Gear System - Dual-range gearing: low gear (437:1) for maximum pulling power up to 10,000 lbs., high gear (156:1) for fast line speeds up to 3,000 lbs.
- Clock-able Gearbox - Can be positioned in four orientations for flexible installation.
- Clock-Able Gearbox Can Be Positioned In Four Orientations For Flexible Installation
- Compact Design - Fits in tighter spaces than traditional 10,000 lb. winches while reducing stress on the vehicle's suspension.
- Compact Design Fits In Tighter Spaces Than Trad. 10000lbs. Winches While Reducing Stress On The Vehicles Suspension
- Ergonomic Pull-and-Turn Free-Spool Clutch - Enables quick, hassle-free range changes and smooth free-spool operation.
- Ergonomic Pull-And-Turn Free-Spool Clutch Enables Quick; Hassle-Free Range Changes/Smooth Free-Spool Operation
- Full Load-Holding Automatic Brake - Securely holds loads of up to 10,000 lbs.
- Full Load-Holding Automatic Brake Securely Holds Loads Of Up To 10000lbs.
- Internal Control Box - Nothing to relocate with improved radiator airflow and enhanced visibility for camera-equipped vehicles.
- Internal Control Box Nothing To Relocate w/Improved Radiator Airflow/Enhanced Visibility For Camera-Equipped Vehicles
- Lightweight - 49lbs. compared to most recovery winches that weigh over 75lbs.
- Lightweight 49lbs. Compared To Most Recovery Winches That Weigh Over 75lbs.
- Low Amp Draw - Delivers maximum winching performance using a single 12V battery.
- Low Amp Draw Delivers Maximum Winching Performance Using A Single 12v Battery
- Multi-Function Wired Remote - Features an integrated, rechargeable flashlight for added convenience.
- Multi-Function Wired Remote Features An Integrated; Rechargeable Flashlight For Added Convenience
- Overload Interrupter (OLI) - Automatically shuts off the winch at maximum load to prevent potential vehicle damage.
- Overload Interrupter [OLI] Automatically Shuts Off The Winch At Maximum Load To Prevent Potential Vehicle Damage
- Patented Drum Light - Ensures superior visibility in low-light conditions.
- Patented Drum Light Ensures Superior Visibility In Low-Light Conditions
- Permanent Magnet Motor w/Dynamic Braking Provides Instant; No-Load Braking For Enhanced Safety
- Permanent Magnet Motor with Dynamic Braking - Provides instant, no-load braking for enhanced safety.
- Wireless Remote - Ergonomic design with MOLLE loop clip for easy access and storage.
Specifications
- Product Attributes - Brand
- Superwinch
- Product Attributes - Manufacturer's Part Number
- 1155401
- Product Attributes - Part Type
- Winches
- Product Attributes - UPC
- 022705007641
Reference Information
| Brand Name/s | Superwinch |
|---|---|
| StreetFX SKU | suw1155401 |
| SFX Item ID | 6661152 |
| Supplier Item Code | 6661152 |
| Manufacturer SKU | 1155401 |
| Manufacturer UPC | 22705007641 |
| Alternative References | SPW-1155401, 12VDC, 1.9HP |
