Msd Ignition

MSD Pro-Billet Distributors 857931 Distributor, Pro-Billet, Magnetic Trigger, Mechanical Advance, Steel Gear, Ford, 289-302, Each

SKU: MSD857931

Distributors
MSD Pro-Billet Distributors 857931 Distributor, Pro-Billet, Magnetic Trigger, Mechanical Advance, Steel Gear, Ford, 289-302, Each

Msd Ignition

MSD Pro-Billet Distributors 857931 Distributor, Pro-Billet, Magnetic Trigger, Mechanical Advance, Steel Gear, Ford, 289-302, Each

SKU: MSD857931

Distributors
A$1,140.67
IN STOCK! Est Ship 3-7 Days days. This item is IN STOCK at one of our warehouses or distribution centres, the ETA is the approximate time required to prepare your order for dispatch.
View cart
We accept
American Express
Mastercard
Visa
PayPal Checkout
Direct Deposit
Afterpay
Apple Pay
Google Pay
Zip Pay

Description

MSD Pro-Billet distributors share the same CNC machining techniques as the rest of the MSD distributor line. They feature a housing that's machined from high-quality 6061-T6 aluminum for durability and show-quality looks. Their oversized shaft receives a QPQ coating for friction reduction and corrosion resistance, with the added strength of two sealed ball bearings that guide the shaft accurately at well over 10,000 rpm. An extra-long sintered bushing replaces the ball bearing at the bottom of Chevrolet models. TIG-welded on top of the polished steel shaft is MSD's accurate mechanical advance assembly. The weights are supported by nylon pads that allow the advance to operate smoothly throughout the rpm range.

For all-out racing, the advance mechanism can also be easily locked out. To accurately trigger the ignition, a high-output magnetic pickup is bolted to the base. This pickup produces a precise trigger signal that will never vary more than one degree at any rpm. A durable gear is installed for performance applications, and an MSD red cap with brass terminals and race rotor is supplied. They're available in standard and small diameter models for applications with limited clearance, and require the use of a separate ignition box such as an MSD 6, 7, 8, or 10 Series ignition.

Part Type

Distributors

Data: v4.2 - Upd: 2026-10-13 18:44:13

Specifications

Product Attributes - Brand
MSD Ignition
Product Attributes - Manufacturer's Part Number
857931
Product Attributes - Part Type
Distributors
Product Attributes - Product Line
MSD Pro-Billet Distributors
Product Attributes - UPC
090127064016
Product Attributes - Distributor Cap Included
Yes
Product Attributes - Distributor Cap Style
Male/HEI
Product Attributes - Distributor Cap Type
Small cap
Product Attributes - Ignition Coil Included
No
Product Attributes - Ignition Module Included
No
Product Attributes - Computer-Controlled Compatible
No
Product Attributes - Trigger Style
Magnetic
Product Attributes - Advance Type
Mechanical
Product Attributes - Ignition Box Required
Yes
Product Attributes - Mechanical Tach Drive
No
Product Attributes - Slip Collar
No
Product Attributes - Distributor Gear Material
Steel
Product Attributes - Distributor Gear Rotation
Standard
Product Attributes - Distributor Cap Color
Black
Product Attributes - Housing Material
Aluminum
Product Attributes - Housing Finish
Black
Product Attributes - Marine Use
No
Product Attributes - Remanufactured
No
Product Attributes - Quantity
Sold individually.
Product Attributes - Notes
Small base diameter for extra clearance. Distributor is 7.0625 in. tall from engine to top of distributor cap.

Reference Information

Brand Name/s Msd Ignition
StreetFX SKU msd857931
SFX Item ID 4974480
Supplier Item Code 4974480
Manufacturer SKU 857931
Manufacturer UPC 90127064016

Compatibility

Application Data
  • Application NotesSmall base diameter for extra clearance. Distributor is 7.0625 in. tall from engine to top of distributor cap.
    Beginning Year1963
    Ending Year1963
    Engine FamilyFord small block Windsor
    Engine Size4.7L/289
    Engine TypeV8
    MakeFORD
    Model300
    SubmodelBASE
  • Application NotesSmall base diameter for extra clearance. Distributor is 7.0625 in. tall from engine to top of distributor cap.
    Beginning Year1966
    Ending Year1968
    Engine FamilyFord small block Windsor
    Engine Size4.7L/289
    Engine TypeV8
    MakeFORD
    ModelBRONCO
    SubmodelBASE
  • Application NotesSmall base diameter for extra clearance. Distributor is 7.0625 in. tall from engine to top of distributor cap.
    Beginning Year1968
    Ending Year1972
    Engine FamilyFord small block Windsor
    Engine Size5.0L/302
    Engine TypeV8
    MakeFORD
    ModelBRONCO
    SubmodelBASE
  • Application NotesSmall base diameter for extra clearance. Distributor is 7.0625 in. tall from engine to top of distributor cap.
    Beginning Year1974
    Ending Year1974
    Engine FamilyFord small block Windsor
    Engine Size5.0L/302
    Engine TypeV8
    MakeFORD
    ModelBRONCO
    SubmodelBASE
  • Application NotesSmall base diameter for extra clearance. Distributor is 7.0625 in. tall from engine to top of distributor cap.
    Beginning Year1975
    Ending Year1977
    Engine FamilyFord small block Windsor
    Engine Size5.0L/302
    Engine TypeV8
    MakeFORD
    ModelBRONCO
    SubmodelCUSTOM
  • Application NotesSmall base diameter for extra clearance. Distributor is 7.0625 in. tall from engine to top of distributor cap.
    Beginning Year1980
    Ending Year1993
    Engine FamilyFord small block Windsor
    Engine Size5.0L/302
    Engine TypeV8
    MakeFORD
    ModelBRONCO
    SubmodelCUSTOM
  • Application NotesSmall base diameter for extra clearance. Distributor is 7.0625 in. tall from engine to top of distributor cap.
    Beginning Year1985
    Ending Year1996
    Engine FamilyFord small block Windsor
    Engine Size5.0L/302
    Engine TypeV8
    MakeFORD
    ModelBRONCO
    SubmodelEDDIE BAUER
  • Application NotesSmall base diameter for extra clearance. Distributor is 7.0625 in. tall from engine to top of distributor cap.
    Beginning Year1975
    Ending Year1975
    Engine FamilyFord small block Windsor
    Engine Size5.0L/302
    Engine TypeV8
    MakeFORD
    ModelBRONCO
    SubmodelNORTHLAND
  • Application NotesSmall base diameter for extra clearance. Distributor is 7.0625 in. tall from engine to top of distributor cap.
    Beginning Year1975
    Ending Year1975
    Engine FamilyFord small block Windsor
    Engine Size5.0L/302
    Engine TypeV8
    MakeFORD
    ModelBRONCO
    SubmodelRANGER
  • Application NotesSmall base diameter for extra clearance. Distributor is 7.0625 in. tall from engine to top of distributor cap.
    Beginning Year1980
    Ending Year1981
    Engine FamilyFord small block Windsor
    Engine Size5.0L/302
    Engine TypeV8
    MakeFORD
    ModelBRONCO
    SubmodelRANGER XLT
  • Application NotesSmall base diameter for extra clearance. Distributor is 7.0625 in. tall from engine to top of distributor cap.
    Beginning Year1968
    Ending Year1968
    Engine FamilyFord small block Windsor
    Engine Size4.7L/289
    Engine TypeV8
    MakeFORD
    ModelBRONCO
    SubmodelROADSTER
  • Application NotesSmall base diameter for extra clearance. Distributor is 7.0625 in. tall from engine to top of distributor cap.
    Beginning Year1968
    Ending Year1969
    Engine FamilyFord small block Windsor
    Engine Size5.0L/302
    Engine TypeV8
    MakeFORD
    ModelBRONCO
    SubmodelROADSTER
  • Application NotesSmall base diameter for extra clearance. Distributor is 7.0625 in. tall from engine to top of distributor cap.
    Beginning Year1975
    Ending Year1977
    Engine FamilyFord small block Windsor
    Engine Size5.0L/302
    Engine TypeV8
    MakeFORD
    ModelBRONCO
    SubmodelSPORT
  • Application NotesSmall base diameter for extra clearance. Distributor is 7.0625 in. tall from engine to top of distributor cap.
    Beginning Year1968
    Ending Year1968
    Engine FamilyFord small block Windsor
    Engine Size4.7L/289
    Engine TypeV8
    MakeFORD
    ModelBRONCO
    SubmodelWAGON
  • Application NotesSmall base diameter for extra clearance. Distributor is 7.0625 in. tall from engine to top of distributor cap.
    Beginning Year1968
    Ending Year1973
    Engine FamilyFord small block Windsor
    Engine Size5.0L/302
    Engine TypeV8
    MakeFORD
    ModelBRONCO
    SubmodelWAGON
  • Application NotesSmall base diameter for extra clearance. Distributor is 7.0625 in. tall from engine to top of distributor cap.
    Beginning Year1990
    Ending Year1996
    Engine FamilyFord small block Windsor
    Engine Size5.0L/302
    Engine TypeV8
    MakeFORD
    ModelBRONCO
    SubmodelXL
  • Application NotesSmall base diameter for extra clearance. Distributor is 7.0625 in. tall from engine to top of distributor cap.
    Beginning Year1982
    Ending Year1983
    Engine FamilyFord small block Windsor
    Engine Size5.0L/302
    Engine TypeV8
    MakeFORD
    ModelBRONCO
    SubmodelXLS
  • Application NotesSmall base diameter for extra clearance. Distributor is 7.0625 in. tall from engine to top of distributor cap.
    Beginning Year1984
    Ending Year1992
    Engine FamilyFord small block Windsor
    Engine Size5.0L/302
    Engine TypeV8
    MakeFORD
    ModelBRONCO
    SubmodelXLT
  • Application NotesSmall base diameter for extra clearance. Distributor is 7.0625 in. tall from engine to top of distributor cap.
    Beginning Year1994
    Ending Year1996
    Engine FamilyFord small block Windsor
    Engine Size5.0L/302
    Engine TypeV8
    MakeFORD
    ModelBRONCO
    SubmodelXLT
  • Application NotesSmall base diameter for extra clearance. Distributor is 7.0625 in. tall from engine to top of distributor cap.
    Beginning Year1982
    Ending Year1983
    Engine FamilyFord small block Windsor
    Engine Size5.0L/302
    Engine TypeV8
    MakeFORD
    ModelBRONCO
    SubmodelXLT LARIAT
  • Application NotesSmall base diameter for extra clearance. Distributor is 7.0625 in. tall from engine to top of distributor cap.
    Beginning Year1993
    Ending Year1993
    Engine FamilyFord small block Windsor
    Engine Size5.0L/302
    Engine TypeV8
    MakeFORD
    ModelBRONCO
    SubmodelXLT LARIAT
  • Application NotesSmall base diameter for extra clearance. Distributor is 7.0625 in. tall from engine to top of distributor cap.
    Beginning Year1992
    Ending Year1992
    Engine FamilyFord small block Windsor
    Engine Size5.0L/302
    Engine TypeV8
    MakeFORD
    ModelBRONCO
    SubmodelXLT NITE
  • Application NotesSmall base diameter for extra clearance. Distributor is 7.0625 in. tall from engine to top of distributor cap.
    Beginning Year1995
    Ending Year1996
    Engine FamilyFord small block Windsor
    Engine Size5.0L/302
    Engine TypeV8
    MakeFORD
    ModelBRONCO
    SubmodelXLT SPORT
  • Application NotesSmall base diameter for extra clearance. Distributor is 7.0625 in. tall from engine to top of distributor cap.
    Beginning Year1963
    Ending Year1967
    Engine FamilyFord small block Windsor
    Engine Size4.7L/289
    Engine TypeV8
    MakeFORD
    ModelCOUNTRY SEDAN
    SubmodelBASE
  • Application NotesSmall base diameter for extra clearance. Distributor is 7.0625 in. tall from engine to top of distributor cap.
    Beginning Year1968
    Ending Year1974
    Engine FamilyFord small block Windsor
    Engine Size5.0L/302
    Engine TypeV8
    MakeFORD
    ModelCOUNTRY SEDAN
    SubmodelBASE
