BluePrint Motorsports Pro Series Chevy 632 C.I.D. 815 HP Fully Dressed Long Block Crate Engines PS6320CTCKBX Engines, Blackout c.i. big block GM style proseries engine-Dressed longblock w/carb. 30 month/50,000 warranty & Dyno
BluePrint Motorsports Pro Series Chevy 632 C.I.D. 815 HP Fully Dressed Long Block Crate Engines PS6320CTCKBX Engines, Blackout c.i. big block GM style proseries engine-Dressed longblock w/carb. 30 month/50,000 warranty & Dyno
A$47,109.64
Special Order. Contact for ETA.
This item is out of stock in our warehouse and partner distribution centres. In some cases, this may be due to not having live inventory feeds available for all suppliers. Please contact us before ordering if you need to meet a specific deadline.
We accept
Description
Blueprint Pro Series is for those wanting maximum horsepower and durability.
BluePrint Engines Pro Series Chevy 632 c.i.d. 815 hp fully dressed long block crate engines offer any custom builder, hot rodder, or kit car builder an engine that's been fully dyno tested, passed vigorous inspections, and is ready to power up your project.
Blueprint's Pro Series 632 Stroker GM-style drop-in ready engines are dressed with aluminum heads, forged pistons, forged crankshaft, a hydraulic roller cam, and complete front accessory drive system with a polished or black finish (your choice).
Additional features:
* Tall deck with 4-bolt main (approximately .400 taller/wider than OEM block)
* Forged H-beam connecting rods
* Cylinder head specs:
-- 119cc chamber
-- 2.30 in. intake / 1.88 in. exhaust valves
-- 358cc intake / 125cc exhaust runners
* Camshaft specs:
-- .698 intake / .698 exhaust
-- 272 intake / 282 exhaust duration
-- at .050 - 110-degree lobe separation
* Installed accessory drive with A/C, P/S, alternator, water pump, belts, and pulleys
* Dyno test results shipped with engine
Part Type
Crate Engines
Specifications
- Product Attributes - Brand
- BluePrint Motorsports
- Product Attributes - Manufacturer's Part Number
- PS6320CTCKBX
- Product Attributes - Part Type
- Crate Engines
- Product Attributes - Product Line
- BluePrint Motorsports Pro Series Chevy 632 C.I.D. 815 HP Fully Dressed Long Block Crate Engines
- Product Attributes - UPC
- 00887753802774
- Product Attributes - Crate Engine Family
- Chevy Big Block
- Product Attributes - Actual Engine Displacement
- 10.3L/632
- Product Attributes - Crate Engine Cylinder Head Material
- Aluminum
- Product Attributes - Engine Block Material
- Cast iron
- Product Attributes - Advertised Compression Ratio
- 11.0:1
- Product Attributes - Assembled
- Yes
- Product Attributes - Engine Balance
- Internal
- Product Attributes - Cam Style
- Hydraulic roller, OE roller
- Product Attributes - Rear Main Seal Style
- 1-piece
- Product Attributes - Intake Manifold Included
- Yes
- Product Attributes - Intake Manifold Style
- Carbureted
- Product Attributes - Cylinder Heads Included
- Yes
- Product Attributes - Carburetor Included
- Yes
- Product Attributes - Throttle Body Included
- No
- Product Attributes - Distributor Included
- Yes
- Product Attributes - Oil Pan Included
- Yes
- Product Attributes - Valve Covers Included
- Yes
- Product Attributes - Timing Cover Included
- Yes
- Product Attributes - Water Pump Included
- Yes
- Product Attributes - Harmonic Balancer Included
- Yes
- Product Attributes - Flexplate Included
- No
- Product Attributes - Flywheel Included
- No
- Product Attributes - Air Cleaner Included
- No
- Product Attributes - Spark Plugs Included
- Yes
- Product Attributes - Spark Plug Wires Included
- Yes
- Product Attributes - Computer Included
- No
- Product Attributes - Wiring Harness Included
- No
- Product Attributes - Water Pump Style
- Long
- Product Attributes - Stall Speed Rating RPM Range
- 3,800-4,200
- Product Attributes - Supercharger Included
- No
- Product Attributes - Remanufactured
- No
- Product Attributes - Quantity
- Sold individually.
- Product Attributes - Notes
- Tall deck engine has 4-bolt mains. Cylinder heads feature a 0.300 in. raised exhaust port versus an OEM casting. Blackout Reaper edition includes a 1,250 cfm carburetor and black front accessory drive system.
- Product Attributes - Special Attention
- Included carburetor has a 1,250 cfm flow rate.
Reference Information
| Brand Name/s | Blueprint Engines |
|---|---|
| StreetFX SKU | mllPS6320CTCKBX |
| SFX Item ID | 5182798 |
| Supplier Item Code | 5182798 |
| Manufacturer SKU | PS6320CTCKBX |
| Manufacturer UPC | 887753802774 |
| Alternative References | month/50 |
