BluePrint Builder Series LS376/530HP Standard Edition EFI Crate Engine and 4L65/70E Trans Combos BLS3768K4L7 376 c.i. LS Iron Block Edition, Fuel Injected, Automatic Transmission w/ Polished Pulley Kit
BluePrint Builder Series LS376/530HP Standard Edition EFI Crate Engine and 4L65/70E Trans Combos BLS3768K4L7 376 c.i. LS Iron Block Edition, Fuel Injected, Automatic Transmission w/ Polished Pulley Kit
A$49,746.83
Special Order. Contact for ETA.
This item is out of stock in our warehouse and partner distribution centres. In some cases, this may be due to not having live inventory feeds available for all suppliers. Please contact us before ordering if you need to meet a specific deadline.
We accept
Description
BluePrint Builder Series LS376/530HP Standard Edition EFI crate engine and 4L65/70E transmission combos take the guesswork out of matching up an engine and transmission for your ride. Featuring a fuel injected Chevy LS small block-compatible 376 (c.i.d.) engine that produces 530 horsepower, this standard edition builder series includes a choice of black or polished pulley kits and 4L65/70E automatic transmission. The aluminum BluePrint Engines cylinder heads help produce a nice 10.7:1 compression ratio, with assistance from the hydraulic roller camshaft, hypereutectic pistons, and nodular iron crankshaft. Altogether, this assembly produces 495 lbs.-ft. of torque. When you need or want a new LS powertrain for your ride, go with the authority in crate engines and their BluePrint Builder Series LS376/530HP Standard Edition EFI crate engine and 4L65/70E transmission combos.
Other product features, items, and specifications include:
Block:
* New Cast Iron 6.2L
* Main caps are 6-bolt
* One-piece rear main seal
* Reluctor wheel – 58x
* Cam sensor – 4x (in timing cover)
* Knock sensor provision on side
Rotating Assembly:
* Nodular iron crankshaft
* Stroke – 3.622 in.
* Connecting rods (6.098 in.) with 150,000 psi bolts
* Hypereutectic pistons
* Internally balanced
* Non-weighted harmonic balancer
Cylinder Heads:
* BluePrint PS8015 models
* Chamber – 72cc
* Valves are 2.165 in. intake and 1.600 in. exhaust
* Exhaust runners are 259cc intake and 102cc exhaust
Camshaft:
* Hydraulic roller
* Intake valve lift – 0.612 in.
* Exhaust valve lift – 0.585 in.
* Intake duration at 0.050 in. of lift – 225
* Exhaust duration at 0.050 in. of lift - 238
* Lobe separation angle (LSA) – 113 degrees
* Intake centerline – 110 degrees
Ignition Timing
* Firing order is 1-8-7-2-6-5-4-3
Assembled 4-speed Transmission Package:
* Complete 4L65/70E package with electronic transmission controller
* Torque converter with 2,200–2,400 rpm stall
* Non-weighted flexplate
* Starter
Other Components:
* Holley Terminator X Max Gen IV complete EFI engine management system, and DBW (Drive-By-Wire) pedal kit
* DBW throttle body
* GM Muscle-car Swap oil pan
* Loaded intake manifold
* Fuel injectors (EV6 type) and rail
* Coil packs
* Spark plugs and wires
* Water pump
* Complete front accessory drive includes A/C, power steering, alternator, water pump, belts, and pulleys
* Champion 3015 spark plugs (0.040 in. gap)
Note: BluePrint highly recommends their BPPLS01013 air intake kit to ensure proper MAF calculations (same used on Dyno). Recommended fuel is 91 octane. Recommended oil is BPP710.
Part Type
Engine and Transmission Combos
Specifications
- Product Attributes - Brand
- BluePrint Engines
- Product Attributes - Manufacturer's Part Number
- BLS3768K4L7
- Product Attributes - Part Type
- Engine and Transmission Combos
- Product Attributes - Product Line
- BluePrint Builder Series LS376/530HP Standard Edition EFI Crate Engine and 4L65/70E Trans Combos
- Product Attributes - UPC
- 00887753972484
- Product Attributes - Crate Engine Family
- Chevy LS
- Product Attributes - Engine Assembly Style
- Long block
- Product Attributes - Assembled
- Yes
- Product Attributes - Intake Manifold Included
- Yes
- Product Attributes - Carburetor Included
- No
- Product Attributes - Throttle Body Included
- Yes
- Product Attributes - Cylinder Heads Included
- Yes
- Product Attributes - Cylinder Head Material
- Cast aluminum
- Product Attributes - Distributor Included
- No
- Product Attributes - Oil Pan Included
- Yes
- Product Attributes - Valve Covers Included
- Yes
- Product Attributes - Timing Cover Included
- Yes
- Product Attributes - Water Pump Included
- Yes
- Product Attributes - Harmonic Balancer Included
- Yes
- Product Attributes - Spark Plugs Included
- Yes
- Product Attributes - Spark Plug Wires Included
- No
- Product Attributes - Flexplate Included
- Yes
- Product Attributes - Flywheel Included
- No
- Product Attributes - Transmission Controller Included
- Yes
- Product Attributes - Torque Converter Included
- Yes
- Product Attributes - Wiring Harness Included
- Yes
- Product Attributes - Computer Included
- Yes
- Product Attributes - Quantity
- Sold as a kit.
- Product Attributes - Notes
- Oil pan has a rear sump.
- Product Attributes - Special Attention
- Includes a natural finish accessory drive system with a LT1 water pump, type II power steering pump with reservoir, 150 amp LT1 style alternator, and a compact style air conditioning compressor.
Reference Information
| Brand Name/s | Blueprint Engines |
|---|---|
| StreetFX SKU | mllBLS3768K4L7 |
| SFX Item ID | 5182881 |
| Supplier Item Code | 5182881 |
| Manufacturer SKU | BLS3768K4L7 |
| Manufacturer UPC | 887753972484 |
| Alternative References | LS376/530HP, 4L65/70E |
