Mishimoto Carbon Fiber Baffled Oil Catch Can

SKU: MISMMBCC-CF

Oil Catch Cans

MM Baffled Oil Catch - Univ...

Mishimoto

Mishimoto Carbon Fiber Baffled Oil Catch Can

SKU: MISMMBCC-CF

Oil Catch Cans

MM Baffled Oil Catch - Univ...

Available from MFR. This item is available from the manufacturer's distribution centre. The dispatch timeframe shown is an estimate based on historical order processing and release times for this part. This item is not held in our own warehouse, and actual dispatch timing may vary depending on manufacturer workload and logistics at the time of ordering.

We accept

Description

Here at Mishimoto, we don't believe in good enough. In fact It's quite the opposite. We strive in taking our products to the next level, and living by our mantra, Push the Limits. It's this attitude along with months of testing and development that has lead us to our newest patent pending carbon fiber catch can. We've taken every bit of engineering that we put into our compact catch can, and took it to the next level. For starters, we increased the size of the can to a 7.4 fluid ounce capacity. We've also constructed the can's body from 3K carbon fiber, reducing the weight but also maximizing your engine bay's aesthetic. Our carbon fiber catch can doesn't only look the part, it acts the part. We've incorporated a uniquely designed baffled insert which makes short work of separating oil and blow-by contaminates from your PCV system. The clean air is routed through our high-flow filter material, which acts as a safety net against any rogue oil droplets without compromising the improved airflow characteristics, even in freezing temperatures. We've also taken the hassle out of checking the fluid level and servicing your catch can by incorporating a quarter-turn lid. Servicing is now as easy as a flick of the wrist. We also ran several tests to ensure that our improved design would capture harmful blow-by on just about every engine configuration, and put the carbon fiber body to the ultimate test of 100,000 pressurization cycles.The carbon fiber catch can and filter are both fully serviceable, and also includes the Mishimoto Lifetime Warranty to ensure long lasting protection for your vehicle.

Product Overview

Features and Benefits

3K twill weave carbon fiber catch can body reduces weight and improves engine bay aesthetics
1/4 turn lid makes checking levels quick while still providing an air-tight seal
7.4 fluid ounce capacity lengthens service intervals
Patent pending
Mishimoto Lifetime Warranty

Product Details

Description:	Baffled Oil Catch Can; Carbon Fiber
Finish:	Carbon Fiber
Install Difficulty:	N/A
Material:	Carbon Fiber
Part Number:	misMMBCC-CF
Prop 65 (C, R or CR):	CR
Prop 65 - Short Label:	prop65_warning.jpg
Prop 65 Yes/No:	Yes
SellingPoint01:	3K twill weave carbon fiber catch can body reduces weight and improves engine bay aesthetics
SellingPoint02:	1/4 turn lid makes checking levels quick while still providing an air-tight seal
SellingPoint03:	7.4 fluid ounce capacity lengthens service intervals
SellingPoint04:	Cyclone baffle's blades are designed using computational fluid dynamics for improved air-oil separation
SellingPoint05:	High-flow filter adds extra layer of protection without affecting PCV/CCV pressures on high-boost applications
SellingPoint06:	Universal CNC billet bracket mounts the can securely
SellingPoint07:	Safe for pressurized applications
SellingPoint08:	Filter and can are fully serviceable
SellingPoint09:	Optional Mishimoto 90 Swivel Banjo Fitting and available baffled oil catch can petcock drain kit
SellingPoint10:	Click Here to find out which Universal Catch Can is best for you
SellingPoint11:	N/A
SellingPoint12:	N/A
SellingPoint13:	N/A
SellingPoint14:	N/A
SellingPoint15:	N/A
TechSpec Applications:	N/A
TechSpec Catch Can Diameter (in):	N/A
TechSpec Chassis Codes:	N/A
TechSpec Drain Plug Thread Size:	N/A
TechSpec Engine Codes:	N/A
TechSpec Height (in):	N/A
TechSpec Includes:	N/A
TechSpec Inlet:	N/A
TechSpec Installation Notes:	N/A
TechSpec Material:	N/A
TechSpec Note:	N/A
TechSpec Outlet:	N/A
Title:	Mishimoto Carbon Fiber Baffled Oil Catch Can

Part Type

Engine Oil Separator

Data: v4.2 - Upd: 2026-10-13 14:45:05

Features

1/4 turn lid makes checking levels quick while still providing an air-tight seal
3K twill weave carbon fiber catch can body reduces weight and improves engine bay aesthetics
7.4 fluid ounce capacity lengthens service intervals

Specifications

Product Attributes - Brand: Mishimoto
Product Attributes - Manufacturer's Part Number: MMBCC-CF
Product Attributes - Part Type: Oil Catch Cans
Product Attributes - Product Line: Mishimoto Baffled Oil Catch Cans
Product Attributes - UPC: 811580032547
Product Attributes - Separator Tank Shape: Round
Product Attributes - Separator Tank Diameter (in.): 2.25 in.
Product Attributes - Separator Tank Height (in.): 5.50 in.
Product Attributes - Separator Tank Material: Carbon fiber
Product Attributes - Separator Tank Finish: Carbon fiber
Product Attributes - Fitting Attachment 1: Female threads
Product Attributes - Fitting Size 1: M16 x 1.5
Product Attributes - Fitting Attachment 2: Female threads
Product Attributes - Fitting Size 2: M16 x 1.5
Product Attributes - Quantity: Sold individually.
Product Attributes - Notes: Holds 7.4 oz. of fluid. Comes with hose barb fittings. Safe for pressurized applications up to 32 psi.
