Mishimoto 96-00 Honda Civic K-Series Swap Aluminum Radiator

SKU: MISMMRAD-K20-EK

Radiators

MM Radiators - Alum...

Mishimoto

Mishimoto 96-00 Honda Civic K-Series Swap Aluminum Radiator

SKU: MISMMRAD-K20-EK

Radiators

MM Radiators - Alum...

Sale ends in Calculating... Thu 15 Oct, 8:07 am AEST

IN STOCK! Est Ship 3-5 days. This item is IN STOCK at one of our warehouses or distribution centres, the ETA is the approximate time required to prepare your order for dispatch.

We accept

Description

Mishimoto is proud to release a brand new radiator for EK chassis Civics with K-Series engine swaps.Our half size radiator is designed specifically for your swapped vehicle with high performance driving in mind.This radiator is a direct drop in unit that does not require any trimming, drilling or mount alterations.The Mishimoto radiator will simplify a cooling solution for your K-swap and includes ports for the fan switch and coolant temperature sensor. All Mishimoto radiators include a high pressure 1.3 bar Mishimoto radiator cap and a lifetime warranty.

Product Overview

1996-2000 Honda Civic, 1996-2000 Honda Civic CX 2.0 Liter, 1996-2000 Honda Civic CX 2.4 Liter, 1996-2000 Honda Civic DX 2.0 Liter, 1996-2000 Honda Civic DX 2.4 Liter, 1996-2000 Honda Civic EX 2.0 Liter, 1996-2000 Honda Civic EX 2.4 Liter, 1998-2000 Honda Civic GX 2.0 Liter, 1998-2000 Honda Civic GX 2.4 Liter, 1996-2000 Honda Civic HX 2.0 Liter, 1996-2000 Honda Civic HX 2.4 Liter, 1996-2000 Honda Civic LX 2.0 Liter, 1996-2000 Honda Civic LX 2.4 Liter, 1999-2000 Honda Civic Si 2.0 Liter, 1999-2000 Honda Civic Si 2.4 Liter, 1999 Honda Civic Value Package 2.0 Liter, 1999 Honda Civic Value Package 2.4 Liter

Features and Benefits

Designed specifically for the 1996-2000 Honda Civic EK chassis with K-series engine swap
Includes threaded fan switch port to function with stock sensor
Includes 1.3 Bar High-Pressure Radiator Cap which effectively raises the boiling point of engine coolant, providing a safer and more efficient system
Includes Magnetic Drain
Plug to capture any metallic debris/fragments in your cooling system
Mishimoto Lifetime Warranty
Provides a bolt-in cooling solution, simplifying the engine swap process
Full aluminum construction with durable, TIG-welded end tanks
Features a two-row, 1.57-in thick, efficient brazed aluminum core
Substantial fluid capacity and optimal heat dissipation
Provides efficient heat exchange for naturally aspirated and forced induction vehicles

Product Details

Alternate Part Number:	MMRAD-K20-EK
Description:	Honda Civic K-Series Swap Aluminum Radiator
Install Difficulty:	3
Installation Difficulty:	3
Material:	Aluminum
Part Number:	misMMRAD-K20-EK
SellingPoint01:	Designed specifically for the 1996-2000 Honda Civic EK chassis with K-series engine swap
SellingPoint02:	Provides a bolt-in cooling solution, simplifying the engine swap process
SellingPoint03:	Full aluminum construction with durable, TIG-welded end tanks
SellingPoint04:	Features a two-row, 1.57-in thick, efficient brazed aluminum core
SellingPoint05:	Substantial fluid capacity and optimal heat dissipation
SellingPoint06:	Provides efficient heat exchange for naturally aspirated and forced induction vehicles
SellingPoint07:	Includes threaded fan switch port to function with stock sensor
SellingPoint08:	Includes 1.3 Bar High-Pressure Radiator Cap which effectively raises the boiling point of engine coolant, providing a safer and more efficient system
SellingPoint09:	Includes Magnetic Drain
SellingPoint10:	Plug to capture any metallic debris/fragments in your cooling system
SellingPoint11:	Mishimoto Lifetime Warranty
SellingPoint12:	N/A
SellingPoint13:	N/A
SellingPoint14:	N/A
SellingPoint15:	N/A
Size:	15.12in x 17.99in x 4.02in
TechSpec Applications:	1996-2000 Honda Civic EK
TechSpec Chassis Codes:	N/A
TechSpec Core Height (in):	12.82
TechSpec Core Length (in):	14.96
TechSpec Core Thickness (in):	1.57
TechSpec DPI:	N/A
TechSpec Drain Plug Thread Size:	M12 x 1.5
TechSpec Engine Codes:	K20
TechSpec Fluid Capacity (gal):	N/A
TechSpec Includes:	Mishimoto Radiator--Mishimoto Radiator Cap--Magnetic Drain Plug w/ Dowty Oil Seal--Mishimoto Lifetime Warranty
TechSpec Inlet (in):	1.25
TechSpec Material:	Aluminum
TechSpec Note:	N/A
TechSpec Outlet (in):	1.25
TechSpec Overall Height (in):	15.12
TechSpec Overall Length (in):	17.99
TechSpec Overall Width (ins):	4.02
TechSpec Rows:	2

Application Summary

Part Type

Radiator

Data: v4.2 - Upd: 2026-10-14 04:44:19

Features

Designed specifically for the 1996-2000 Honda Civic EK chassis with K-series engine swap
Full aluminum construction with durable, TIG-welded end tanks
Provides a bolt-in cooling solution, simplifying the engine swap process

Specifications

Product Attributes - UPC: 748666001343
Product Attributes - Brand: Mishimoto
Product Attributes - Notes: Includes a radiator cap and a magnetic drain plug. Fits the K20 engines.
Product Attributes - Quantity: Sold as a set.
Product Attributes - Part Type: Radiators
Product Attributes - Fan Included: No
Product Attributes - Product Line: Mishimoto Performance Radiators
Product Attributes - Row Quantity: 2
Product Attributes - Inlet Location: Upper driver side
Product Attributes - Radiator Style: Downflow
Product Attributes - Outlet Location: Lower passenger side
Product Attributes - Radiator Finish: Natural
Product Attributes - Core Width (in.): 12.85 in.
Product Attributes - Core Height (in.): 14.96 in.
Product Attributes - Radiator Material: Aluminum
Product Attributes - Overall Width (in.): 15.12 in.
Product Attributes - Radiator Inlet Size: 1.250 in.
Product Attributes - Transmission Cooler: No
Product Attributes - Core Thickness (in.): 1.57 in.
Product Attributes - Overall Height (in.): 17.99 in.
Product Attributes - Radiator Outlet Size: 1.250 in.
Product Attributes - Radiator Cap Included: Yes
Product Attributes - Overall Thickness (in.): 4.02
Product Attributes - Manufacturer's Part Number: MMRAD-K20-EK
Product Attributes - Trans Cooler Adapter Fittings Included: No

Reference Information

Brand Name/s	Mishimoto
StreetFX SKU	misMMRAD-K20-EK
SFX Item ID	4049418
Supplier Item Code	4049418
Manufacturer SKU	MMRAD-K20-EK
Manufacturer UPC	748666001343
Alternative References	mio-mmrad-k20-ek, MIMMMRAD-K20-EK
