Mishimoto 15+ Subaru WRX Front-Mount Intercooler Kit - Black Core

SKU: MISMMINT-WRX-15BK

Intercoolers

MM Intercoolers - Kits...

Mishimoto

Mishimoto 15+ Subaru WRX Front-Mount Intercooler Kit - Black Core

SKU: MISMMINT-WRX-15BK

Intercoolers

MM Intercoolers - Kits...

LAST ONE! Est Ship 3-5 days. LAST ONE! This is the last unit at our distribution centre. Contact us if you need more. The ETA is the approximate time required to prepare your order for dispatch.

We accept

Description

Designed for applications that demand the greatest airflow and cooling capabilities, this Mishimoto WRX Front-Mount Intercooler Kit will provide your Subaru with the ability to make the most horsepower and torque possible. This intercooler features a large 28in core that provides maximum cooling without excessive pressure drop that will wear out any turbocharger over time. The Mishimoto WRX front-mount intercooler features smooth cast end tanks that are CFD tested for maximum airflow with no sharp walls or bends that disrupt airflow. The intercooler provides the best airflow and heat-exchange properties for those time-attack laps, or a 10-second blast down the quarter mile. The Mishimoto Subaru WRX Front-Mount Intercooler also features four mandrel-bent aluminum pipes for optimum airflow. The hot-side pipes are 2.25inin in diameter to keep airflow velocities high, giving your car an instant response without excessive throttle lag that plagues many front-mount intercooler designs. The hot-side pipe also features a CNC-machined flange for a leak free connection to the turbo. The cold side of the system features 2.5in to 2.75in mandrel-bent aluminum tubing for maximum airflow, and to match the diameter of your throttle body. This 2015 WRX front-mount intercooler kit contains everything needed for a worry-free installation, including an application-specific crash bar that both supports the intercooler and mounts to existing points on the vehicle. No cutting of the front bumper or drilling is required to install the crash bar and intercooler. The kit includes all necessary mounting brackets and couplers, including a new bracket for the air intake. Like all Mishimoto products, this WRX front-mount intercooler is backed by our Mishimoto Lifetime Warranty.

Product Overview

"Designed for applications that demand the greatest airflow and cooling capabilities, the Mishimoto WRX Front-Mount Intercooler Kit will provide your Subaru with the ability to make the most horsepower and torque possible. The Mishimoto front-mount intercooler was designed with a large 28"" intercooler core that provides the maximum cooling capability without excessive pressure drops that will wear out any turbocharger over time. The Mishimoto WRX front-mount intercooler features smooth cast end tanks that are CFD tested for maximum airflow with no sharp walls or bends from cut-and-weld end tanks that disrupt airflow. The intercooler provides the best airflow and heat-exchange properties for those time-attack laps, or a 10-second blast down the quarter mile. The Mishimoto Subaru WRX Front-Mount Intercooler also features four mandrel-bent aluminum pipes for optimum airflow. The hot-side pipes are 2.25"" in diameter to keep airflow velocities high, giving your car an instant response without excessive throttle lag that plagues many front-mount intercooler designs. The hot-side pipe also features a CNC-machined flange for a leak free connection to the turbo. The cold side of the system features 2.5"" to 2.75" mandrel-bent aluminum tubing for maximum airflow, and to match the diameter of your throttle body. This 2015 WRX front-mount intercooler kit contains everything needed for a worry-free installation, including an application-specific crash bar that both supports the intercooler and mounts to existing points on the vehicle. No cutting of the front bumper or drilling is required to install the crash bar and intercooler. The kit includes all necessary mounting brackets, including a new bracket for the air intake. Our WRX front-mount intercooler kit also includes every coupler and clamp you need for a clean install, and compliments the Mishimoto Subaru WRX Performance Air Intake for added cooling power. Mishimoto tested this intercooler on our Stage 2 265whp WRX

Features and Benefits

Direct fit for the 2015-2021 Subaru WRX
3.5" Thick intercooler design optimized for maximum flow
Designed to work with Mishimoto Performance Air Intake and stock intake
No modification to front bumper and retains stock fog lights
Includes black powder-coated steel, tubular crash bar
Smooth cast end tanks allow the best possible airflow in and out of the intercooler
Optimal core design for maximum cooling efficiency with minimal pressure drop
Includes all necessary couplers, brackets, and accessories
Intercooler available in Sleek Silver, Stealth Black, or Bold Gold
CARB EO #: D-759
Mishimoto Lifetime Warranty

Product Details

Alternate Part Number:	MMINTWRX15BK
CARB EO Number:	D-759
Color:	Black
Description:	Subaru WRX Front-Mount Intercooler Kit
Finish:	Powder-Coat
Install Difficulty:	4
Installation Difficulty:	4/5
Material:	Aluminum
OptionLabel:	Black
Part Number:	misMMINT-WRX-15BK
SellingPoint01:	Direct fit for the 2015-2021 Subaru WRX
SellingPoint02:	3.5-in Thick intercooler design optimized for maximum flow
SellingPoint03:	Designed to work with Mishimoto Performance Air Intake and stock intake
SellingPoint04:	No modification to front bumper and retains stock fog lights
SellingPoint05:	Includes black powder-coated steel, tubular crash bar
SellingPoint06:	Smooth cast end tanks allow the best possible airflow in and out of the intercooler
SellingPoint07:	Optimal core design for maximum cooling efficiency with minimal pressure drop
SellingPoint08:	Includes all necessary couplers, brackets, and accessories
SellingPoint09:	Intercooler available in Sleek Silver, Stealth Black, or Bold Gold
SellingPoint10:	CARB EO number: D-759
SellingPoint11:	Mishimoto Lifetime Warranty
SellingPoint12:	N/A
SellingPoint13:	N/A
SellingPoint14:	N/A
SellingPoint15:	N/A
TechSpec Applications:	2015-2021 Subaru WRX
TechSpec Centerline Radius:	N/A
TechSpec Chassis Codes:	VA
TechSpec Core Height (in):	8.05
TechSpec Core Length (in):	28
TechSpec Core Thickness (in):	3.5
TechSpec Core Type:	Bar-and-Plate
TechSpec Engine Codes:	FA20DIT
TechSpec Includes:	(1) Bar-and-Plate Intercooler--(1) Steel Crash Bar w/Mounting Hardware--(2) Hot-Side Intercooler Pipes--(2) Cold-Side Intercooler Pipes--(1) Air Intake Bracket--(1) 2.25-in 45-degree Coupler--(1) 2.25-in to 2.75-in 45-degree Transition Coupler--(1) 2.5-in to 2.75-in 55 -degree Transition Coupler--(1) 2.5-in to 2.75-in 65 -degree Transition Coupler--(1) 3.00-in Straight Coupler--(1) BPV Recirculation Hose--(1) BPV Vacuum Hose--(1) 30-45mm Worm Gear Clamp--(2) 1.75-in T-bolt Clamps--(3) 2.5-in T-b
TechSpec Inlet (in):	2.45
TechSpec Installation Notes:	N/A
TechSpec Maximum Recommended Boost Pressure (PSI):	30
TechSpec Maximum Recommended Horsepower:	600
TechSpec Note:	This kit does not fit with fog light equipped vehicles----Mishimoto recommends that this intercooler kit, not be used with the stock ECU programming. It is highly recommended that the customer be able to retune the vehicleâ€™s ECU after installing the intercooler kit. Power gains will vary depending on the size of the turbo, exhaust system, fuel system, and type of ECU tune that is applied to the vehicle.----This kit is rated for approximately 600 whp during normal operating conditions. Maximum
TechSpec Outlet (in):	2.75
TechSpec Overall Height (in):	8.6
TechSpec Overall Length (in):	37.7
TechSpec Overall Width (in):	5.4
TechSpec Pipe Diameter:	N/A
TechSpec Pipe Length:	N/A
TechSpec Pipe Shape:	N/A
TechSpec Weight (lbs):	N/A

Application Summary

2015-2016 Subaru WRX Base 2.0 Liter TY751, 2015-2016 Subaru WRX Limited 2.0 Liter TR690, 2015-2016 Subaru WRX Limited 2.0 Liter TY751, 2015-2016 Subaru WRX Premium 2.0 Liter TR690, 2015-2016 Subaru WRX Premium 2.0 Liter TY751

Part Type

Intercooler Kit

Data: v4.2 - Upd: 2026-09-29 08:29:23

Features

3.5-in Thick intercooler design optimized for maximum flow
Designed to work with Mishimoto Performance Air Intake and stock intake
No modification to front bumper and retains stock fog lights

Specifications

Product Attributes - UPC: 748354021332
Product Attributes - Brand: Mishimoto
Product Attributes - Notes: Front mount intercooler kit.
Product Attributes - Quantity: Sold as a kit.
Product Attributes - Part Type: Intercoolers
Product Attributes - Product Line: Mishimoto Intercoolers
Product Attributes - Intercooler Color: Black
Product Attributes - Intercooler Inlet: Slip fit
Product Attributes - Intercooler Outlet: Slip fit
Product Attributes - Aftercooler Included: No
Product Attributes - Intercooler Material: Aluminum
Product Attributes - Intercooler Core Type: Air-to-air
Product Attributes - Intercooler Inlet Size: 2.450 in.
Product Attributes - Intercooler Pipe Color: Polished
Product Attributes - Intercooler Depth (in.): 5.40 in.
Product Attributes - Intercooler Outlet Size: 2.750 in.
Product Attributes - Intercooler Width (in.): 37.70 in.
Product Attributes - Intercooler Height (in.): 8.60 in.
Product Attributes - Intercooler Pipe Included: Yes
Product Attributes - Intercooler Pipe Material: Aluminum
Product Attributes - Manufacturer's Part Number: MMINT-WRX-15BK
Product Attributes - Intercooler Width Range (in.): 37.00-37.99 in.
Product Attributes - Intercooler Height Range (in.): 8.00-8.99 in.
Product Attributes - Intercooler Mounting Brackets Included: Yes
Product Attributes - Remote Mount Electric Water Pump Included: No
Product Attributes - Aftercooler Remote Water Reservoir Included: No

Reference Information

Brand Name/s	Mishimoto
StreetFX SKU	misMMINT-WRX-15BK
SFX Item ID	4050320
Supplier Item Code	4050320
Manufacturer SKU	MMINT-WRX-15BK
Manufacturer UPC	748354021332
Alternative References	mio-mmintwrx15bk, MIMMMINT-WRX-15BK
