Mishimoto 08-10 Ford 6.4L Powerstroke Radiator - Version 2

SKU: MISMMRAD-F2D-08V2

Radiators

MM Radiators - Alum...

Mishimoto

Mishimoto 08-10 Ford 6.4L Powerstroke Radiator - Version 2

SKU: MISMMRAD-F2D-08V2

Radiators

MM Radiators - Alum...

Sale ends in Calculating... Wed 14 Oct, 8:07 am AEST

IN STOCK! Est Ship 3-5 days. This item is IN STOCK at one of our warehouses or distribution centres, the ETA is the approximate time required to prepare your order for dispatch.

We accept

Description

The 6.4L Ford Powerstroke is plagued with radiator and cooling issues, with no effective solution available.Upgrade your truck with the Mishimoto 6.4L Powerstroke aluminum radiator to put an end to puddles of coolant under your truck.Mishimoto radiators are constructed from high-quality aircraft-grade aluminum with a 100% brazed aluminum core.Our 6.4L radiator features strong TIG-welded aluminum end tanks for superior durability and longevity that will keep your Powerstroke on the road and out of the shop.The Mishimoto performance radiator retains factory fitment for an easy installation process and includes a magnetic drain plug to catch any debris in your cooling system.As with all our products, this radiator is protected by the Mishimoto lifetime warranty.

Product Overview

The 6.4L Ford Powerstroke is plagued with radiator and cooling issues, with no effective solution available. Upgrade your truck with the Mishimoto 6.4L Powerstroke aluminum radiator to put an end to puddles of coolant under your truck. Mishimoto radiators are constructed from high-quality aircraft-grade aluminum with a 100-percent brazed aluminum core. Our 6.4L radiator features strong TIG-welded aluminum end tanks for superior durability and longevity that will keep your Powerstroke on the road and out of the shop. The Mishimoto performance radiator retains factory fitment for an easy installation process and includes a magnetic drain plug to catch any debris in your cooling system. As with all our products, this radiator is protected by the Mishimoto lifetime warranty.

Features and Benefits

Version 2 product design
Direct fit for the 6.4L Powerstroke
Co-molded aluminum/rubber mounting pegs to reduce the truck's torque transfer to the radiator
Internally strutted tubes in the top and bottom 8 rows for increased strength against high pressure
Strengthened top and bottom core support plates prevent core torquing and bending

Product Details

Alternate Part Number:	MMRADF2D08V2
Color:	Aluminum
Description:	Ford 6.4L Powerstroke Aluminum Radiator
Feature Bullet 1:	Version 2 product design
Feature Bullet 2:	Direct fit for the 6.4L Powerstroke
Feature Bullet 3:	Co-molded aluminum/rubber mounting pegs to reduce the truck's torque transfer to the radiator
Feature Bullet 4:	Internally strutted tubes in the top and bottom 8 rows for increased strength against high pressure
Feature Bullet 5:	Strengthened top and bottom core support plates prevent core torquing and bending
Finish:	Brushed
Install Difficulty:	3
Installation Difficulty:	3/5
Material:	Aluminum
Part Number:	misMMRAD-F2D-08V2
SellingPoint01:	N/A
SellingPoint02:	Direct fit for the 6.4L Powerstroke
SellingPoint03:	Incorporates co-molded aluminum/rubber mounting pegs to reduce the truckâ€™s torque transfer to the radiator
SellingPoint04:	Internally strutted tubes for increased strength against high pressure and temperature
SellingPoint05:	Strengthened top and bottom core support plates prevent core torquing and bending
SellingPoint06:	Inlet and outlet have CNC-machined factory-style quick-disconnects
SellingPoint07:	100-percent brazed aluminum core
SellingPoint08:	TIG-welded to perfection
SellingPoint09:	Includes magnetic drain plug
SellingPoint10:	Patent numberD717,702
SellingPoint11:	Mishimoto Lifetime Warranty
SellingPoint12:	N/A
SellingPoint13:	N/A
SellingPoint14:	N/A
SellingPoint15:	N/A
TechSpec Applications:	2008-2010 Ford F-250 w/ 6.4L Powerstroke--2008-2010 Ford F-350 w/ 6.4L Powerstroke--2008-2010 Ford F-450 w/ 6.4L Powerstroke--2008-2010 Ford F-550 w/ 6.4L Powerstroke
TechSpec Chassis Codes:	N/A
TechSpec Core Height (in):	37.01
TechSpec Core Length (in):	27.48
TechSpec Core Thickness (in):	2.76
TechSpec DPI:	13022
TechSpec Drain Plug Thread Size:	M12 x 1.5
TechSpec Engine Codes:	N/A
TechSpec Fluid Capacity (gal):	8.36
TechSpec Includes:	Mishimoto Radiator--Magnetic Drain Plug w/ Dowty Oil Seal--(2) Rubber Mounting Pegs--(8) M6 x 1.0 x 14mm Bolts--Mishimoto Lifetime Warranty
TechSpec Inlet (in):	N/A
TechSpec Material:	Aluminum
TechSpec Note:	N/A
TechSpec Outlet (in):	N/A
TechSpec Overall Height (in):	28.7
TechSpec Overall Length (in):	45.7
TechSpec Overall Width (ins):	8.9
TechSpec Rows:	2

Application Summary

2008-2010 Ford F-250 Super Duty 6.4 Liter 5R110W, 2008-2010 Ford F-250 Super Duty 6.4 Liter S6-650, 2008-2010 Ford F-350 Super Duty 6.4 Liter 5R110W, 2008-2010 Ford F-350 Super Duty 6.4 Liter S6-650, 2008-2010 Ford F-450 Super Duty 6.4 Liter 5R110W, 2008-2010 Ford F-450 Super Duty 6.4 Liter S6-650, 2008-2010 Ford F-550 Super Duty 6.4 Liter 5R110W, 2008-2010 Ford F-550 Super Duty 6.4 Liter S6-650

Part Type

Radiator

Data: v4.2 - Upd: 2026-10-13 14:43:16

Features

Dual-molded aluminum/rubber mounting pegs to reduce torque transfer to the radiator
Enhanced second generation product design
Internally strutted tubes for increased strength against high pressure and temperature

Specifications

Product Attributes - UPC: 748354023169
Product Attributes - Brand: Mishimoto
Product Attributes - Notes: Features quick-disconnect inlet/outlet fittings.
Product Attributes - Quantity: Sold individually.
Product Attributes - Part Type: Radiators
Product Attributes - Fan Included: No
Product Attributes - Product Line: Mishimoto Performance Radiators
Product Attributes - Row Quantity: 2
Product Attributes - Inlet Location: Upper driver side
Product Attributes - Radiator Style: Downflow
Product Attributes - Outlet Location: Lower passenger side
Product Attributes - Radiator Finish: Natural
Product Attributes - Core Width (in.): 37.01 in.
Product Attributes - Core Height (in.): 27.48 in.
Product Attributes - Radiator Material: Aluminum
Product Attributes - Overall Width (in.): 45.70 in.
Product Attributes - Transmission Cooler: No
Product Attributes - Core Thickness (in.): 2.76 in.
Product Attributes - Overall Height (in.): 28.70 in.
Product Attributes - Radiator Cap Included: No
Product Attributes - Overall Thickness (in.): 8.90
Product Attributes - Manufacturer's Part Number: MMRAD-F2D-08V2
Product Attributes - Trans Cooler Adapter Fittings Included: No

Reference Information

Brand Name/s	Mishimoto
StreetFX SKU	misMMRAD-F2D-08V2
SFX Item ID	4050370
Supplier Item Code	4050370
Manufacturer SKU	MMRAD-F2D-08V2
Manufacturer UPC	748354023169
Alternative References	mio-mmradf2d08v2, MIMMMRAD-F2D-08V2, 6.4L
