Mishimoto 01-05 Subaru WRX/STi Oil Cooler Kit

SKU: MISMMOC-WRX-01

Fluid Coolers

MM Oil Cooler - Kits...

Mishimoto

Mishimoto 01-05 Subaru WRX/STi Oil Cooler Kit

SKU: MISMMOC-WRX-01

Fluid Coolers

MM Oil Cooler - Kits...

Sale ends in Calculating... Thu 15 Oct, 8:07 am AEST

IN STOCK! Est Ship 3-5 days. This item is IN STOCK at one of our warehouses or distribution centres, the ETA is the approximate time required to prepare your order for dispatch.

We accept

Description

Mishimoto proudly announces the all-new 2001-05 Subaru WRX/STi Oil Cooler KIt'specially designed for your Subaru WRX and STi, the Mishimoto oil cooler is a direct fit and can be installed in just two hours! Mounted in the front grille for optimal airflow, the Mishimoto Subaru WRX/STi oil cooler kit drops temperatures over 20 degrees.You can be sure that this kit is perfect for keeping your Subaru WRX or STi cool under any driving conditions.The Mishimoto 2001-2005 Subaru WRX/STi Oil Cooler Kit comes with a Lifetime Warranty, so you know quality is guaranteed! Available with either silver or a stealth black cooler this kit is perfect for your street or track Subaru!

Product Overview

Features and Benefits

Provides Dramatic Temperature Drop
2 psi pressure loss
Direct fit for the â€¢06-07 WRX/STI
Thermostatic option available
Stealth black and sleek silver cooler options
Easily replaceable thermostat allows you to customize your fluid temperature
Additional thermostats available in 160Â°F, 185Â°F, and 200Â°F
Mishimoto Lifetime Warranty

Product Details

Alternate Part Number:	MMOC-WRX-01
Color:	Silver
Description:	Subaru WRX and STI Oil Cooler Kit
Install Difficulty:	3
Installation Difficulty:	3
OptionLabel:	Silver Cooler, Non-Thermostatic
Part Number:	misMMOC-WRX-01
SellingPoint01:	Provides Dramatic Temperature Drop
SellingPoint02:	2 psi pressure loss
SellingPoint03:	Direct fit for the 06-07 WRX/STI
SellingPoint04:	Thermostatic option available
SellingPoint05:	Stealth black and sleek silver cooler options
SellingPoint06:	Lifetime Warranty
SellingPoint07:	N/A
SellingPoint08:	N/A
SellingPoint09:	N/A
SellingPoint10:	N/A
SellingPoint11:	N/A
SellingPoint12:	N/A
SellingPoint13:	N/A
SellingPoint14:	N/A
SellingPoint15:	N/A
TechSpec Applications:	2001-2005 Subaru WRX--2004-2005 Subaru STI
TechSpec Caution:	It is the installer's responsibility to check all thermostat plugs, NPT plugs, line fittings, and other connections to assure they are fully tightened before operating the vehicle. Mishimoto recommends that you check all connections at regular intervals, especially during the first few miles after installation.
TechSpec Chassis Codes:	GD
TechSpec Core Construction:	N/A
TechSpec Core Height (in):	2.76
TechSpec Core Length (in):	11
TechSpec Core Thickness (in):	1.97
TechSpec Engine Codes:	EJ205--EJ255
TechSpec Fluid Capacity (qts):	N/A
TechSpec Includes:	Application-Specific Mounting Brackets--10-Row Oil Cooler--3-ft Stainless Steel Braided Hose w/ -10AN Fittings--4-ft 4-in Stainless Steel Braided Hose w/ -10AN Fittings--Oil Sandwich Plate--Stainless Steel Sandwich Plate Adapter, M20--Banjo Fitting w/ Bolt M20 x -10AN, Black--Black Rubber Seal--Mounting Hardware Set--Mishimoto Lifetime Warranty
TechSpec Inlet:	N/A
TechSpec Installation Notes:	Recommended torque specification for all straight fittings and banjo bolts: 15-25 lb-ftDo not exceed the maximum torque rating of 35 ft-lb
TechSpec Note:	Requires trimming of exhaust heat shield for proper installation. Will not fit on vehicles equipped with front mount intercoolers. Fits automatic and manual applications.
TechSpec Outlet:	N/A
TechSpec Overall Height (in):	N/A
TechSpec Overall Length (in):	N/A
TechSpec Overall Width (in):	N/A
TechSpec Rows:	10

Application Summary

2002-2005 Subaru Impreza WRX 2.0 Liter TV1A4, 2002-2005 Subaru Impreza WRX 2.0 Liter TY754, 2004-2005 Subaru Impreza WRX STI 2.5 Liter TY856

Part Type

Engine Oil Cooler

Data: v4.2 - Upd: 2026-10-14 04:44:19

Features

2 psi pressure loss
Provides Dramatic Temperature Drop
Thermostatic option available

Specifications

Product Attributes - UPC: 748356000120
Product Attributes - Brand: Mishimoto
Product Attributes - Notes: Includes mounting brackets, stainless steel braided hoses, oil filter sandwich plate, banjo fitting and mounting hardware.
Product Attributes - Quantity: Sold as a kit.
Product Attributes - Part Type: Fluid Coolers
Product Attributes - Cooler Color: Natural
Product Attributes - Fan Included: No
Product Attributes - Product Line: Mishimoto Oil Cooler Kits
Product Attributes - Cooler Material: Aluminum
Product Attributes - Core Width (in.): 11.00 in.
Product Attributes - Inlet Attachment: Male threads
Product Attributes - Core Height (in.): 2.76 in.
Product Attributes - Fluid Cooler Type: Engine oil
Product Attributes - Outlet Attachment: Male threads
Product Attributes - Cooler Construction: Heat sink
Product Attributes - Overall Width (in.): 12.95 in.
Product Attributes - Core Thickness (in.): 1.97 in.
Product Attributes - Overall Height (in.): 3.80 in.
Product Attributes - Number of Cooling Rows: 10
Product Attributes - Fluid Cooler Inlet Size: -10 AN
Product Attributes - Overall Thickness (in.): 1.97
Product Attributes - Fluid Cooler Outlet Size: -10 AN
Product Attributes - Manufacturer's Part Number: MMOC-WRX-01

Reference Information

Brand Name/s	Mishimoto
StreetFX SKU	misMMOC-WRX-01
SFX Item ID	4049364
Supplier Item Code	4049364
Manufacturer SKU	MMOC-WRX-01
Manufacturer UPC	811580037801
Alternative References	mio-mmoc-wrx-01, MIMMMOC-WRX-01
